- Page 1 Suction Wave Massage Unit NEOSERV 114 NEOSERV 114-H User Manual gbo Medizintechnik AG 2004 Version 1.5...
- Page 2 NEOSERV 114 The gbo Medizintechnik AG has taken care in preparation of this manual, but makes no expressed or implied warranty of any kind and assume no responsibility for errors or omissions. All rights reserved. No part of this manual may be reproduced, in any form or by any means (electronic, mechanical, or otherwise) without the prior written permission of the gbo Medizintechnik AG.
- Page 3 NEOSERV 114 Warnings and safety precautions Warning! Warnings which have to be observed by all means! Caution! Observe the instructions for use! Note! Information that will facilitate your work. gbo Medizintechnik AG 2004 Version 1.5...
-
Page 4: Table Of Contents
6.1 Safety Controls 6.2 Cleaning, Disinfection and Care 6.2.1 Cleaning and Disinfecting the Unit 6.2.2 Cleaning and Maintaining the Electrodes and Sponges WARNINGS AND SAFETY PRECAUTIONS EXPLANATION OF THE SIGNS USED TECHNICAL DATA 10 ACCESSORIES gbo Medizintechnik AG 2004 Version 1.5... -
Page 5: Introduction
Introduction 1.1 Intended Use The NEOSERV 114 is a suction-wave therapy unit designed for use with 1 - 4 suction electrodes. The device is specially useful for a combination with DUODYNATOR 119 and in the combined operation “stimulation current with ultrasound“ additionally, with the ultrasound therapy devices SONOSTAT 133 and SONOSTAT 135. -
Page 6: Short Instructions
NEOSERV 114 1.2 Short Instructions Figure 1: NEOSERV 114 Figure 2: NEOSERV 114 in combination with DUODYNATOR 119 gbo Medizintechnik AG 2004 Version 1.5... - Page 7 NEOSERV 114 (e.g., SONOSTAT 135). Switch on the NEOSERV 114 (switch located at the back of the device). The green LED of the will be flashing. Standby key Connect all needed electrodes to the appropriate connectors by means of the electrode hoses (red = channel I;...
- Page 8 10. Clean the sponges on a daily basis. 11. Observe the Operating Instructions relating to any unit used in combination with the NEOSERV 114 (for example DUODYNATOR 119, SONOSTAT 135). gbo Medizintechnik AG 2004...
-
Page 9: Start Of Operation
Then connect the suction electrode to the other end of the flexible tube. Warning! 2.2 Connection The NEOSERV 114 has been designed for a power supply of 95 - 264 V. Permissible mains frequencies: 50/60 Hz. Connect the unit to a grounded socket using the three-wire mains cable provided. -
Page 10: Description Of Function
5 seconds. Standby key Note! The vacuum pressure indicator flashes, i.e. the NEOSERV 114 is in the cleaning mode. 7. The pump will press all liquids out of the water separator. 8. Switch off the NEOSERV 114 or press the Standby key 9. -
Page 11: Suction Connector Jacks
3.7 Connector Unit The NEOSERV 114 has a permanent cable connected for transmitting the therapy current to the suction cup electrodes. Connect the plugs from these cables to the patient lead socket I on the electrotherapy unit (for example DUODYNATOR 119). -
Page 12: Operating The Unit
NEOSERV 114 Operating the Unit Warning! 4.1 Switching on the Unit Switch on the NEOSERV 114. The green LED of the will be flashing. Standby key 4.2 Select Channels Press the of setting the unit into operation. The pump will work now. -
Page 13: Applying The Suction Electrodes
"0". Switch off the NEOSERV 114 or put it into standby mode. Then take the electrodes off the patient’s skin. For this, lift the edge of suction electrode. The electrode will now come off. -
Page 14: Troubleshooting
– Stimulation current too low – Sponges dry – In any other case of trouble or failure contact immediately gbo Medizintechnik AG or one of the service agencies authorized by gbo Medizintechnik AG. gbo Medizintechnik AG 2004 Version 1.5... -
Page 15: Maintenance
(disinfection by wiping over surfaces). It has to be observed that no liquids enter the device. Never shall the plug or socket get wet. For cleaning or disinfection the device must not be dizzled. gbo Medizintechnik AG 2004 Version 1.5... -
Page 16: Cleaning And Maintaining The Electrodes And Sponges
Dry sponges should be immersed in lukewarm tap water for about 5 minutes prior to treatment. This will ensure that the sponges recover the required elasticity and size. Warning! gbo Medizintechnik AG 2004 Version 1.5... -
Page 17: Warnings And Safety Precautions
Please keep a distance of 3 m. • A simultaneous connection of the patient to a high-frequency surgery device can lead to burns under the electrical stimulus electrodes. gbo Medizintechnik AG 2004 Version 1.5... -
Page 18: Explanation Of The Signs Used
Observe the instructions for use ! Application part ungrounded, protection degree Type BF This product complies with WEEE Directive 2002/96/EG (waste electrical and electronic equipment). Separate collection for electrical and electronic equipment. Water level Temperature Standby gbo Medizintechnik AG 2004 Version 1.5... -
Page 19: Technical Data
Transport and Temperature range +5 °C ... +50 °C storage : Relative humidity < 90 %, none condensing gbo Medizintechnik AG reserves the right to modify the design and specification without prior notice. 10 Accessories Article Article number with user manuals... - Page 20 Notes in accordance with EC directive and Medical Devices Directive (MDD) The NEOSERV 114/114-H is a line-powered suction wave massage unit of protection class I. Normally it serves as an suction application aid for current stimulation therapy. The device is in accordance with the EC directive for medical devices (93/42/EWG) and therefore carries the CE sign with the registration number of the notified body for medical devices.
- Page 21 IEC 61000-4-8 location in a typical commercial or hospital environment. Note: U is the a.c. mains voltage prior to application of the test level. τ gbo Medizintechnik AG 2004 Version 1.5...
- Page 22 150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2,5 GHz d=1,2√ √ √ √ P d=1,2√ √ √ √ P d=2,3√ √ √ √ P 0,01 0,12 0,12 0,23 0,38 0,38 0,73 gbo Medizintechnik AG 2004 Version 1.5...
- Page 23 NEOSERV 114 gbo Medizintechnik AG 2004 Version 1.5...
- Page 24 NEOSERV 114 Art.No. 014-7-0054 gbo Medizintechnik AG 2004 Version 1.5...
