- Page 1 Ultrasound Therapy Device SONOSTAT 135 User manual gbo Medizintechnik AG 2004 Version 1.3...
- Page 2 SONOSTAT 135 The gbo Medizintechnik AG of has taken care in preparation of this manual, but makes no expressed or implied warranty of any kind and assume no responsibility for errors or omissions. All rights reserved. No part of this manual may be reproduced, in any form or by any means (electronic, mechanical, or otherwise) without the prior written permission of the gbo Medizintechnik AG.
- Page 3 - Text appears in the display near the softkey Warnings and safety precautions Warning! Warnings which have to be observed by all means! Caution! Observe the instructions for use! Note! Information that will facilitate your work. gbo Medizintechnik AG 2004 Version 1.3...
-
Page 4: Table Of Contents
SONOSTAT 135 Contents INTRODUCTION 1.1 Intended use 1.2 Device view SONOSTAT 135 1.3 Short instructions INTRODUCTION 2.1 Transport and installation 2.2 Connection and switch-on 2.2.1 Fuses 2.3 Settings DESCRIPTION OF FUNCTION 3.1 Display content 3.2 Operating notes 3.2.1 Optical and acoustical user support 3.2.2 Intensity regulator... -
Page 5: Introduction
The range of application is extended by pulse mode. Inflammatory processes can also be treated purposeful. The SONOSTAT 135 generates the ultrasound frequencies 1 MHz as well as 3 MHz. Basically, as higher the ultrasound frequency, as lower is the penetration of ultrasound. According to this, 3 MHz is recommended for treatments of superficial indications. -
Page 6: Device View Sonostat 135
Ultrasound probe connections Figure 1: SONOSTAT 135 Softkeys Softkeys Ultrasound Ultrasound probe small probe large Therapy time Continuous Impulse Frequency Modification keys Intensity sound sound choice regulator Figure 2: SONOSTAT 135 - front gbo Medizintechnik AG 2004 Version 1.3... -
Page 7: Short Instructions
12. At the end of the treatment the triad gong will sound 3 x. The ultrasound power is automatically switched off. 13. Clean the ultrasound probe from the contact gel. gbo Medizintechnik AG 2004 Version 1.3... -
Page 8: Introduction
3. With a screw driver the box can be pulled out of the receiver by the small slot. The SONOSTAT 135 is switched on by the mains switch on the back of the device. By this arrangement erroneous, unintended disconnection of the device during normal operations shall be avoided. -
Page 9: Settings
8. Move the cursor or change the value with the to the desired value. modification keys 9. Confirm by pressing the softkey [Store] 10. Exit the menu Settings by pressing the soft [Back] 11. On the display the Menu appears again. gbo Medizintechnik AG 2004 Version 1.3... - Page 10 Portuguese* Italian French Russian Reset settings Reset settings? Back / Cont. Put back of all settings on manufacturer setting or delivery condition, with it all individual programs are also deleted. Table 1: Settings gbo Medizintechnik AG 2004 Version 1.3...
-
Page 11: Description Of Function
3 MHz Figure 4: Treatment with self-selected parameters 04:00 1,8 W/cm² Coxarthrosis Figure 5: Treatment with a program from the indication menu 10:18 1,8 W/cm² 1:20 Figure 6: Treatment with a self-configured program gbo Medizintechnik AG 2004 Version 1.3... -
Page 12: Operating Notes
• operation • faulty ultrasound contact • if the unit is ready for use Triad gong • at the end of the therapy. : Acoustical user support Table 4 gbo Medizintechnik AG 2004 Version 1.3... -
Page 13: Intensity Regulator
The setting of the therapy time is done herewith. Figure 8: Modification keys 3.2.5 Ultrasound probes Two ultrasound probes are available for treatment. The SONOSTAT 135 recognises the connected probe. Warning! gbo Medizintechnik AG 2004 Version 1.3... -
Page 14: Therapy Time
3 x. ∗ Parameter modifications of the last therapy are retained. ∗ The therapy can be continued by setting of a new therapy time and turning on the intensity. gbo Medizintechnik AG 2004 Version 1.3... -
Page 15: Continuous Sound
. You are in the function store program. softkey 8. Move the scroll bar/cursor by means of the to the wanted storage location program modification keys 9. Confirm by pressing the softkey [ [ [ [ store] ] ] ] gbo Medizintechnik AG 2004 Version 1.3... - Page 16 4. The function load program will exit and the selected program will start. Note! The functions load program or store program can be left at any time by pressing the softkey [ [ [ [ back] ] ] ] gbo Medizintechnik AG 2004 Version 1.3...
-
Page 17: Therapy
[Ind.] 8. In the display the existing parameters are indicated. If wanted you can modify these before the therapy start. Note! The therapy time can also be set during the therapy. gbo Medizintechnik AG 2004 Version 1.3... - Page 18 • The therapy time runs off only if the ultrasound probe is contacted to the patient, i.e. is coupled. This is indicated by the constantly lit LED in the ultrasound probe. Exception: You changed the linkage in the menu Settings, see chapter 2.3. gbo Medizintechnik AG 2004 Version 1.3...
-
Page 19: Indication Menu
SONOSTAT 135 4.1 Indication menu An indication menu is integrated in SONOSTAT 135. This offers several programs, which suggest certain parameter settings with regards to ultrasound power, therapy time, operation mode and frequency. These parameter recommendations are of orientational character only and are subject to the doctors responsibility. - Page 20 Intercostalneuralgia Ischialgia Lumbalgia 1:10 Meniscopathia 1:10 Morbus Bechterew 1:10 Myalgia Myogelosis 1:10 Neuralgia Omarthrosis 1:10 Periostitis Rheumatoid arthritis Rhizarthrosis Tendopathia Tendovaginitis Trigeminal neuralgia Sudeck’s dystrophy 1:10 Table 6: Programs of the indication menu gbo Medizintechnik AG 2004 Version 1.3...
-
Page 21: Combination Therapy With Attraction Current Or Hitop
Medizintechnik AG´s product liability and warranty. There is a special input socket provided in the device back of the SONOSTAT 135 for connecting such a unit. However, for reasons of safety the current connection is interrupted device-internal if or as long as the intensity value amounts to 0.0 W/cm... - Page 22 SONOSTAT 135. Apply the neutral electrode. In the SONOSTAT 135: 5. Connect the ultrasound probes to the sockets on the right side of the device. 6. The ultrasound probes will be calibrated. The LEDs of the ultrasound probes flash.
-
Page 23: Contraindications
• Do no expose of the epiphysis zones of children. • Note! This list raises no claim to completeness. In the individual case the doctor always decides on contraindications and criteria of treatment. gbo Medizintechnik AG 2004 Version 1.3... -
Page 24: Behaviors In Case Of Failures
If the failure occurs again, the device is out of function. Please contact a service agent authorized by the manufacturer. Attention! To high heatsink temperature ♦ − Let cool down the ultrasound therapy device, i.e. you switch off the ultrasound therapy device and let it cool. gbo Medizintechnik AG 2004 Version 1.3... -
Page 25: Maintenance
Never shall the plug or socket get wet. For cleaning or disinfection the device must not be dizzled. Note! After each treatment session, be sure to thoroughly clean the resonance plate of the treatment probe to prevent oxidation. gbo Medizintechnik AG 2004 Version 1.3... -
Page 26: Warnings And Safety Precautions
This list raises no claim to completeness. In the individual case the doctor always decides on contraindications and criteria of treatment. • In case of all visible failures contact immediately gbo Medizintechnik AG or one of the service agencies authorized by gbo Medizintechnik AG . gbo Medizintechnik AG 2004... -
Page 27: Explanation Of The Signs Used
(e.g., ® DUODYNATOR 119 or HiToP 182). This product complies with WEEE Directive 2002/96/EG (waste electrical and electronic equipment). Separate collection for electrical and electronic equipment. gbo Medizintechnik AG 2004 Version 1.3... -
Page 28: Technical Data
Relative humidity 30... 75% Transport and storage: Temperature range 5 °C... 50 °C Relative humidity < 90 %, not condensing gbo Medizintechnik AG reserves the right to modify the design and specification without prior notice. gbo Medizintechnik AG 2004 Version 1.3... -
Page 29: Accessories
Contact gel, 250 ml 45-39-128EH725 Ultrasound probe 2.5 cm (1 and 3 MHz) 023-0-0140 Ultrasound probe 5 cm (1 and 3 MHz) 023-0-0141 User manual SONOSTAT 135, German 023-7-0003 User manual SONOSTAT 135, English 023-7-0004 gbo Medizintechnik AG 2004 Version 1.3... -
Page 30: Index
Note 7, 9, 13, 14, 16, 17, 18, 22, 23, 25, 26 Grundeinstellungen der Stromformen 11 Safety controls 25 Intensitätregler 13 Warning 8, 13, 21, 23, 25, 26 LED 12 warnings Warnings Main menu gbo Medizintechnik AG 2004 Version 1.3... -
Page 31: Notes In Accordance With Ec Directive And Medical Device Directive
The unit must not be arranged physically close to other devices or stacked with other devices than current stimulation units of the brand gbo. If such an order is necessary nevertheless, the unit must be observed in order to check it for the intentional operation. - Page 32 IEC 61000-4-8 location in a typical commercial or hospital environment. Note: U is the a.c. mains voltage prior to application of the test level. τ gbo Medizintechnik AG 2004 Version 1.3...
- Page 33 150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2,5 GHz d=1,2√ √ √ √ P d=1,2√ √ √ √ P d=2,3√ √ √ √ P 0,01 0,12 0,12 0,23 0,38 0,38 0,73 gbo Medizintechnik AG 2004 Version 1.3...
- Page 34 SONOSTAT 135 Art. No 023-7-0004 gbo Medizintechnik AG 2004 Version 1.3...
