REMOTE CHECK OF VEHICLE AND DEVICE STATE
The system allows to check the vehicle and device state remotely by simple
SMS command:
{DSPIN} status
e.g.:
12345 status
The device sends a return status SMS with information about the vehicle and
state of VSS. This status SMS can be sent as simple or full form.
In specific case when DS511 works as PAGER to 3rd party VSS, which does not
allow to get the information about alarm state, the SMS is sent only in simple
form.
Both forms of status SMS contain information about DS511 version and
firmware version, in order to facilitate technical support.
Full version of status SMS with possible system information:
System:
Door, trunk, bonnet:{closed / opened}
Ignition:
Vehicle battery voltage = 12.08V
Power source:
DS512 FW:xxxx yyyy
Meaning of each state:
disarmed: VSS is disabled, vehicle is not protected,
armed: VSS is enabled, vehicle is protected,
armed w/o sensors:
VSS is enabled, additional sensors are disabled (e.g. ultrasonic
sensor, tilt sensor),
armed w/o trunk and sensors:
VSS is enabled, trunk compartment temporary not protected
and sensors temporary disabled due to the use of 3rd button on
OEM remote transmitter,
ALARM in progress!:
VSS is alarming; audible and visible signalisation enabled,
disarming: system was disarmed with OEM remote transmitter, waiting for
door to be opened or ignition to be turned on,
service mode: DS511 was set into service / valet mode thus the vehicle is not
protected,
ANTI-HIJACK: DS511 received a command to immobilise the vehicle (anti-
hijack) function); vehicle is not immobilised yet,
ANTI-HIJACK vehicle stopped:
DS511 received a command to immobilise the vehicle (anti-
hijack) function); vehicle is immobilised.
'ALARM was triggered' is displayed only if at the moment the VSS is armed and
is currently not alarming, but since the systems was armed the alarm was
triggered at least one time.
Simple version of status SMS:
system:
{ALARM in progress! / ready / service mode / ANTI-HIJACK! /
ANTI-HIJACK vehicle stopped}
ds511 PAGER
{disarmed / armed / armed w/o sensors /
armed w/o trunk and sensors / ALARM in
progress! / disarming / valet mode /
ANTI-HIJACK / ANTI-HIJACK vehicle stopped}
{ALARM was triggered!}
{on / off}
{vehicle battery / internal backup battery}
