CHAPTER 1
CHAPTER 1
The DS511 can work as GSM Pager for any alarm system – either OEM VSS
(Mode 2 OEM Pager) or any aftermarket analogue VSS (Mode 1 Pager).
Operation of DS511, its arming/disarming is in accordance with the manual of
installed security system – OEM or aftermarket.
If DS511 detects alarming of OEM or aftermarket VSS it signalises the alarming
according to description in chapter 3.
When the DS511 monitors an OEM VSS the states of doors, ignition and vehicle
central locking system are available.
When the DS511 monitors any aftermarket VSS, recognition of arm state,
ignition and doors depends on the VSS connection configuration – detailed
information can be provided by installer.
If DS511 operates in Mode 1 or Mode 2 the LED signalises states as follows:
LED is OFF
monitored VSS is not armed,
LED is continuously lit (without audible and visible signalisation)
monitored VSS is being armed,
LED blinks slowly (1x/sec.)
monitored VSS is armed, vehicle is protected,
LED blinks fast (2x/sec.)
alarm state detected, monitored VSS is alarming,
LED blinks very fast (5x/sec.)
monitored VSS was disabled; waiting for doors to be opened otherwise after
30 seconds the rearming procedure starts,
LED is continuously lit (with audible and visible signalisation)
anti-hijack procedure in progress - remote vehicle immobiliser.
CHAPTER 2
Depending on the configuration the DS511 can notify theft attempt by voice
call or SMS to up to 3 programmed phone numbers.
ALARM TRIGGER VOICE CALL NOTIFICATION
Right after the alarm trigger the DS511 attempts to notify up to 3 mobile
phone numbers programmed in device by voice call. DS512 takes 1,2 or 3
attempts to voice call each number. In order to confirm receiving of the alarm
trigger notification and stop the voice call cycle the '*' (asterisk) character must
be pressed within 15 seconds after answering the voice call.
Voice call notification cycle is stopped. Next voice call cycle is possible 30
seconds after the siren signalisation ends.
ALARM TRIGGER SMS NOTIFICATION
After the voice call notification cycle the DS511 attempts to notify up to 3
mobile phone numbers with SMS messages.
SMS notification contains information about alarm source and an
announcement about SMS with vehicle position (only if DS511 is equipped with
additional external GPS module). SMS notification of the siren signalisation is sent
not more often then every 30 seconds.
WARNING! ALARM has been triggered
additional sensor
Localisation will be sent within 90 seconds
The delay may be a result of starting the GPS receiver and fixing vehicle GPS
position. By default the GPS receiver is disabled when device is armed.
ds511 PAGER
OR ANY AFTERMARKET ANALOGUE VSS
MODE 3 (SILENT ALARM) OR MODE 4 (FULL ALARM)
MODE 1 (PAGER) OR MODE 2 (PAGER OEM)
OPERATION AS GSM PAGER
OPERATION AS STAND-ALONE
FOR OEM CAN-BUS VSS
VEHICLE SECURITY SYSTEM
ALARM GSM NOTIFICATION
