- Page 1 ASSEMBLY GUIDE Mita Console Table...
- Page 2 Components Upon unpacking your console table from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new console table. Table top x 1 Leg x 4...
-
Page 3: What You Need
Hardware A x 8 C x 8 B x 1 Spec: Ø12mm x 70mm/Ø8mm Spec: Ø8mm x 19mm x 1.2mm Spec: Ø8mm x 13mm x 1.8mm E x 1 F x 1 D x 1 Spec: M8 Spec: Ø8mm x 110mm Spec: Ø8mm x 88mm x 2mm What you need... - Page 4 Step 1 Insert the cross dowel into the hole at the top of each leg making sure that it is facing the correct direction. A x 4 Step 2 Insert a threaded bolt into the hole on the side of each leg (2), screwing it tightly in place.
- Page 5 Step 3 Align a leg to the underside of the table top making sure the threaded bolt protruding from the leg ts into the hole in the frame. Fit a at washer the bolt followed by a spring washer and a hex (D).
