- Page 1 ASSEMBLY GUIDE Mia Co ee Table With Shelf...
- Page 2 Components Upon unpacking your co ee table from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your new table. Item Description Qty. Item Description Qty. Table top Fixed shelf Cross dowel Hex nut M8 x 12 x 30mm...
- Page 3 Lay drawer box unit on a at surface.Insert cross dowels Step 1 into legs & by placing each cross dowel into the hole on top of each leg. Ensure the horizontal marking on each tting is facing as shown. Screw threaded bolt into cross dowel that are already concealed in legs...
- Page 4 Step 2 Attach a leg into place by inserting threaded bolt through the pre-drilled hole of metal corner bracket as shown. Insert in order the at washer lock washer and hex onto threaded bolt (B). Tighten hex nut using spanner until securely fastened as shown.
- Page 5 With help of assistant, slide xed shelf into the slot and Step 3 onto steel dowel on leg as shown. Ensure xed shelf placed completely in the slot of leg. Secure part to part using grub screw as shown. Use a pozi screwdriver to turn screw clockwise to tighten.
- Page 6 Step 5 Attach legs into place by inserting threaded bolts through the pre-drilled hole of metal corner brackets as shown. Ensure the slots and dowels on legs are alligned correctly with xed shelf before attaching. Insert in order the at washers (C), lock washers hex nuts onto threaded bolts (B).
- Page 7 Step 6 Stand the unit upright. Assembly is complete. Enjoy your new table!
