MB QUART MBQT-STG2-RAD-1 Installation Instructions Manual

MB QUART MBQT-STG2-RAD-1 Installation Instructions Manual

Honda talon

Advertisement

Quick Links

Installation Instructions
Model:
Description:
Part Number:
Assembly Time:
Before you begin, read through these instructions and check that
all parts are present. Always disconnect negative battery terminal,
prior to installation. Please note that MB Quart cannot assume any
responsibility for damage resulting from incorrect installation.
No.
1
GMR-LED with Housing (MBQT-RAD-1)
2
6.5in Dash Speakers (MBQT-FPOD-1)
3
NA2-400.2
4
MBQT-ACC-1
1
Bojo Tool
2
Panel Clip Pliers
3
10mm open box wrench
4
10mm and 12mm socket
5
½" socket
6
Rachet
7
Small flat head screwdriver
8
Phillips screwdriver
9
3mm and 5mm Allen Wrench
10
¼" and ½" drill bit or stepper bit
11
1" hole saw
12
Drill
13
Rotary tool similar to a Dremel
14
Heat Gun or Lighter
15
Crimper
Honda Talon
Stage 2 Install
MBQT-STG2-RAD-1
120 Min (2-Hours)
Parts List
Component Name
Tools Required
Page 1 of 22
Qty
1
2
1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MBQT-STG2-RAD-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MB QUART MBQT-STG2-RAD-1

  • Page 1 Assembly Time: Before you begin, read through these instructions and check that all parts are present. Always disconnect negative battery terminal, prior to installation. Please note that MB Quart cannot assume any responsibility for damage resulting from incorrect installation. Parts List...
  • Page 2 Disassembly ● Remove hood by turning two latches ● Remove four 10mm bolts, four push pins, and five 5mm allen bolts to remove top of dash ● Remove half mud guard with six push pins Page 2 of 22...
  • Page 3 Disassembly ● Lift up the bottom half of the steering column rubber boot ● Remove the two push pins behind the rubber boot ● Remove the two push pins on the bottom of steering column cover Page 3 of 22...
  • Page 4 Disassembly ● Remove the bottom steering wheel cover ● Remove one 5mm allen bolt and one push pin from the drivers kick area ● Remove two 5mm allen bolts from behind glove box door Page 4 of 22...
  • Page 5 Disassembly ● Remove one push pin in the back of the glove box ● Remove three push pins from below the glove box ● Remove glove box Page 5 of 22...
  • Page 6 Disassembly ● Remove one 5 mm allen bolt and one push pin from passenger kick area Page 6 of 22...
  • Page 7 Front Speaker Pod Installation ● Drill a ½” hole, 5/8” down from the edge and 2 ¼” over (Control the depth of bit to not go to deep) ● Pass the wire from the driver side pod through the hole you drilled ●...
  • Page 8 Front Speaker Pod Installation ● Install the M6 x 40mm bolt and washer through the enclosure into the factory bolt location ● Tighten the 5/16” bolt in the fender area ● Repeat previous steps on passenger side Page 8 of 22...
  • Page 9 Radio & Dash Kit Installation ● Place the metal u-bracket at the top of the pocket and mark the bottom portion to be cut out with a rotary tool ● Drill two ¼” holes using the u-bracket as a guide in the back of the pocket ●...
  • Page 10 Radio & Dash Kit Installation ● Slide the dash panel with the bevel and MB Quart logo facing outward like the image ● Pass the wires from the radio through the hole below the u-bracket in the pocket ● Install four M4 cap head bolts...
  • Page 11 Radio & Dash Kit Installation ● Install covers on each side of radio Page 11 of 22...
  • Page 12: Amplifier Adjustment

    Amplifier Adjustment ● Adjust the NA2-400.2 amplifier gain and crossover settings as pictured NOTE Gains all to the last “L” on Level HPF to 100Hz going just past “P” on LP LPF is turned all the way down X-Over to HP Page 12 of 22...
  • Page 13 Amplifiers and Plate Installation ● Install the NA2-400.2 amplifier as pictured with four M4 Philips screws, washers, and lock nuts ● Install the rubber c-clamp around the tube as pictured ● Slide the top amplifier mount between the frame and top of dash as pictured Page 13 of 22...
  • Page 14 Amplifiers and Plate Installation ● Install the M6 button head bolt through the plate and c-clamp attaching from the bottom with a washer and lock nut Page 14 of 22...
  • Page 15: Wiring Installation

    Wiring Installation ● Connect the speaker harness to the NA2-400.2 amplifier and route the driver and passenger speaker leads to the appropriate kick area ● Connect bullets of amplifier harness with respective front kick pods Page 15 of 22...
  • Page 16 Wiring Installation ● Install power harness to each amplifier (Connector with bullets connects to NA2-400.2) ● Connect bullets from power harness to speaker harness (This is if you want to add optional LED rings at the speaker locations) ● Connect Delphi connector on power harness into the radio harness Page 16 of 22...
  • Page 17 Wiring Installation ● If you don’t already have a buss bar installed you can connect to factory wiring (but we highly recommend a buss bar kit) These are available from many aftermarket companies like XTC Power Products ● Plug RCA into the NA2-400.2 and run to the front RCA outputs of the radio Page 17 of 22...
  • Page 18 Wiring Installation ● Drill a 1” hole in the side of the glovebox 3” from the front for the USB / AUX Port ● Place the glove box back in the vehicle (we will install hardware during assembly portion of the manual) ●...
  • Page 19 Reassembly ● Install three push pins from below the glove box ● Install one push pin in the back of the glove box ● Install two 5mm allen bolts from behind glove box door Page 19 of 22...
  • Page 20 Reassembly ● Install the bottom steering wheel cover ● Install new full mud guard with kit with 6 push pins previously removed and 8 new push pins in ● Install four 10mm bolts, four push pins, and five 5mm allen bolts to remove top of dash Page 20 of 22...
  • Page 21 Reassembly ● Install hood by turning two latches Page 21 of 22...
  • Page 22 The Bluetooth ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use such marks by MB Quart is under license. All product names, logos, and brands are property of their respective owners. All company, product and service names used in this literature are for identification purposes only.
