PVL216 / PVL268 / PVL269
Thank you for choosing MB Quart Premium speakers for your car audio sound
system. With proper installation, you are on the path to experiencing your music in
a way you only imagined possible. Here at MB Quart, we call this "Sound In Every
Detail."
The Premium series speakers have been designed for the enthusiast looking for
incredible sound and amazing performance. The Premium series speakers feature
the following:
- Convertible Coax/Component Capability
- 40mm Silk Dome Tweeter
- Gold Plated Speaker Terminals
- Active Crossover With Variable Tweeter Attenuation
And Gold Plated Terminals
- Edge Rolled Steel Basket
- Spider Woven Tinsel Leads
- Motor Damping Magnet Cap
- Progressive Long Travel Spider
- Progressive Grill
- High Energy Magnet
- Polypropylene Cone
www.mbquart.com
Advertisement
Related Manuals for MB QUART PREMIUM PVL216
Summary of Contents for MB QUART PREMIUM PVL216
- Page 1 Thank you for choosing MB Quart Premium speakers for your car audio sound system. With proper installation, you are on the path to experiencing your music in a way you only imagined possible. Here at MB Quart, we call this “Sound In Every Detail.”...
- Page 2 PREMIUM PVL216 / PVL268 / PVL269 .37” .41” .63” 2.76” 1.24” Side View Of PTL-40 2.4” 1.95” 1.58” 2.13” Top View Of PXO 4.72” Side View Of PXO...
- Page 3 PVL216 38 - 32,000 40mm / 1.58” 16cm / 6.5” 2 X-Overs 38 - 32,000 40mm 16cm 7.24” 5.61” 38 - 32,000 40mm / 1.58” 16cm / 6.5” 38 - 32,000 40mm 16cm 38 - 32,000 40mm 16cm 38 - 32,000...
- Page 4 PVL268 8.05” 7.36” 38 - 32,000 40mm / 1.58” 5x7” / 6x8” 2 X-Overs 38 - 32,000 40mm 5x7” / 6x8” 5.81” 5.11” 38 - 32,000 40mm / 1.58” 5x7” / 6x8” 38 - 32,000 40mm 5x7” / 6x8” 38 - 32,000 40mm 5x7”...
- Page 5 PVL269 8.05” 7.36” 32 - 32,000 40mm / 1.58” 2 X-Overs 32 - 32,000 40mm 6x9” 32 - 32,000 40mm / 1.58” 6x9” 32 - 32,000 5.81” 5.11” 32 - 32,000 6x9” 32 - 32,000 40mm 6x9” 40mm 6x9” 40mm 6x9”...
- Page 6 We strongly recommend that you have your new Premium series speakers installed by your authorized MB Quart dealer. The installation professionals employed by your dealer have the necessary tools and experience to disassemble your vehicle, install your new speakers and reassemble everything properly.
-
Page 7: Wiring Diagram
PREMIUM PVL216 / PVL268 / PVL269 Wiring Diagram CLIP INDICATOR CLIP INDICATOR AMBER- AMBER- GREEN- SOFT CLIP GREEN- SOFT CLIP PRE CLIP RED- PRE CLIP RED- HARD CLIP HARD CLIP LEVEL LEVEL 0.2V 0.2V BASS BOOST BASS BOOST 12dB 12dB... - Page 8 PREMIUM PVL216 / PVL268 / PVL269 Tweeter Mounting Options Separate From Mid Bass (Component) Flush Mount Method Mounting Surface Mounting Brackets Mounting Bracket Washers Mounting Bracket Screws Cup Mounting Screws Mounting Surface Tweeter Mounting In The Center Of The Mid Bass (Coaxial)
- Page 9 PREMIUM PVL216 / PVL268 / PVL269 Speaker, Tweeter and Crossover Placement Options: Factory sound systems vary greatly. Some systems have coaxials (tweeter fixed in the center of the midrange) in the door, while others have factory component (tweeter is separate from midrange) systems. If your system has the factory component offering then you will want to locate your factory tweeter mounting location and compare it to the diagram below.
- Page 10 PREMIUM PVL216 / PVL268 / PVL269 car audio PART#U1010...
