Konifera BW92000 Installation Instruction

Retractable awning
Hide thumbs Also See for BW92000:

Advertisement

Quick Links

DO NOT RELEASE THE HANDLE GRIP WHEN
EXTRACTING/RETRACTING THE FABRIC SCREEN
Specifications/Precautions and safety
warnings for installation and operation
Accessories and required tools
Installation procedure
Operation instructions
Maintenance
Name list of parts
D: Nachdruck, auch auszugsweise, nicht gestattet! GB: Reproduction, even in extracts, is not permitted! NL: Nadruk, ook slechts gedeeltelijk, niet toegestaan!
Anleitung Nr.: 20180903092000
09030-BW92000.indd 1
FOR FUTURE REFERENCE
Contents
Einziehbare Markise
BW92000
Gebrauchsanleitung
Installation Instruction
04.10.18 20:06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BW92000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Konifera BW92000

  • Page 1 Installation procedure Operation instructions Gebrauchsanleitung Maintenance Installation Instruction Name list of parts D: Nachdruck, auch auszugsweise, nicht gestattet! GB: Reproduction, even in extracts, is not permitted! NL: Nadruk, ook slechts gedeeltelijk, niet toegestaan! Anleitung Nr.: 20180903092000 09030-BW92000.indd 1 04.10.18 20:06...
  • Page 2: Table Of Contents

    ► Liste der Bauteilbezeichnungen ........8 Spezifikation Artikelnummer Tatsächliche Schatten- Nettogewicht Tuch Windwiderstands- Ausmaße (cm) größe (cm) (Kg) klasse BW92000 160×300 151×297 Polyester Klasse 1 (28Km/h) - 2 - 09030-BW92000.indd 2 04.10.18 20:06...
  • Page 3: Spezifikationen/Vorsichtsmaßnahmen Und Sicherheitshinweise

    Check the awning every 3 months to ensure all fixing are tightened and no damage on the products. No modification of the awning in any kind is allowed. personal injury. Save enough free space around the awning while rolling or unrolling. 09030-BW92000.indd 3 04.10.18 20:07 Never use it in rainy and windy days. personal injury.
  • Page 4: Zubehörteile Und Erforderliche Werkzeuge

    Please prepare below tools before installation: Einbau vor: Schlagbohrmaschine mit Maßband Schraubenschlüssel Schrauben- Power drill with drilling bit Tape measure Wrench (wrenches of Screwdriver einer Ø 8mm und Ø 10mm zieher M6 ) of Ø8mm and Ø10mm Bohrspitze - 4 - 09030-BW92000.indd 4 04.10.18 20:07...
  • Page 5: Einbauvorgang

    Einbauvorgang Installation Procedure Ø8x4 40mm Ø8x4 Wall 48mm 48mm Make sure to be Vergewissern Sie sich, dass senkrecht eingebaut werden perpendicular to the wall kann Hakenmaul Hook mouth - 5 - 09030-BW92000.indd 5 04.10.18 20:07...
  • Page 6: Bedienungsanweisungen

    2) Schließen / Einfahren i) Halten Sie den Handgriff fest während des gesamten Einfahrvorgangs. ii) Entriegeln Sie den Handgriff von der Befestigungsklammer. iii) Gehen Sie langsam bis zum Markisentuch, bis das gesamte Tuch eingerollt ist. - 6 - 09030-BW92000.indd 6 04.10.18 20:07...
  • Page 7: Instandhaltung

    3. Überprüfen Sie die gesamte Installation und die Befestigungsvorrichtungen regelmäßig, vor allem nach season,to ensure the fasteners are tightened and in good conditions. längerer Nichtverwendung, um sicherzustellen, dass die Befestigungen angezogen und in einem guten Zustand sind. - 7 - 09030-BW92000.indd 7 04.10.18 20:07...
  • Page 8: Liste Der Bauteilbezeichnungen

    ◆ wall bracket Tuch fabric ◆ front bar Fallstange ◆ Fastness bracket Befestigungsklammer ◆ Verbindung ◆ Handle grip Handgriff Anmerkung: Wenn die Zubehörteile mit beschädigt sind, verwenden Sie das Produkt nicht, bevor sie ersetzt wurden. - 8 - 09030-BW92000.indd 8 04.10.18 20:07...
  • Page 9 Quelle CH: 0848 85 85 02 Ackermann CH: 0848 85 85 31, Jelmoli Technik: 0848 858 530 Imported by baumarkt direkt GmbH & Co KG Imported by baumarkt direkt GmbH & Co KG Alter Teichweg 25, 22081 Hamburg, Germany Alter Teichweg 25, 22081 Hamburg, Germany - 9 - 09030-BW92000.indd 9 04.10.18 20:07...
  • Page 10 09030-BW92000.indd 10 04.10.18 20:07...
  • Page 11 Installation procedure Operation instructions Gebrauchsanleitung Maintenance Installation Instruction Name list of parts D: Nachdruck, auch auszugsweise, nicht gestattet! GB: Reproduction, even in extracts, is not permitted! NL: Nadruk, ook slechts gedeeltelijk, niet toegestaan! Instruction No.: 20180903092000 09030-BW92000.indd 11 04.10.18 20:07...
  • Page 12: Specifications/Precautions And Safety Warnings For Installation And Operation

    ►Name list of parts ........... 18 Specification Artical number Actual size (cm) Shade Net weight Fabric Wind resistance Dimension (cm) (Kg) class BW92000 160×300 151×297 Polyester Class 1 (28Km/h) - 12 - 09030-BW92000.indd 12 04.10.18 20:07...
  • Page 13 Check the awning every 3 months to ensure all fixing are tightened and no damage on the products. Do not use the awning if repair is needed.Do not try to repair the product by yourself,contact qaulified person for repairing. - 13 - 09030-BW92000.indd 13 04.10.18 20:07...
  • Page 14: Accessories And Required Tools

    Accessories and required tools Accessories and required tools Please prepare below tools before installation: Power drill with drilling bit Tape measure Wrench (wrenches of Screwdriver M6 ) of Ø8mm and Ø10mm - 14 - 09030-BW92000.indd 14 04.10.18 20:07...
  • Page 15: Installation Procedure

    Installation procedure Installation Procedure Ø8x4 40mm Ø8x4 Wall 48mm 48mm Make sure to be perpendicular to the wall Hook mouth - 15 - 09030-BW92000.indd 15 04.10.18 20:07...
  • Page 16: Operation Instructions

    Hold the handle grip firmly throughout the whole retraction process. ii) Unlock the handle grip from the fastness bracket. iii) Slowly walk toward the folding screen until whole fabric screen be rolled into it. - 16 - 09030-BW92000.indd 16 04.10.18 20:07...
  • Page 17: Maintenance

    2. Pls do not unpick and wash the fabric. If you need replace the fabric,please turn to experts for help. 3. Check the overall installation and all the fasteners regularly,especially at the beginning of a new season,to ensure the fasteners are tightened and in good conditions. - 17 - 09030-BW92000.indd 17 04.10.18 20:07...
  • Page 18: Name List Of Parts

    ◆ end cap ◆ wall bracket fabric ◆ front bar ◆ Fastness bracket ◆ Verbindung ◆ Handle grip Note: When the parts with are damaged, don‘t use the product before they are replaced - 18 - 09030-BW92000.indd 18 04.10.18 20:07...
  • Page 19 Quelle CH: 0848 85 85 02 Ackermann CH: 0848 85 85 31, Jelmoli Technik: 0848 858 530 Imported by baumarkt direkt GmbH & Co KG Imported by baumarkt direkt GmbH & Co KG Alter Teichweg 25, 22081 Hamburg, Germany Alter Teichweg 25, 22081 Hamburg, Germany - 19 - 09030-BW92000.indd 19 04.10.18 20:07...
  • Page 20 09030-BW92000.indd 20 04.10.18 20:07...
