WARNING - IT IS IMPORTANT FOR SAFETY OF
PERSONS TO FOLLOW THESE INSTRUCTIONS. SAVE
THESE INSTRUCTIONS FOR FUTURE REFERENCE
►
Specifications/Precautions and safety
warnings for installation and operation
►
Accessories and required tools
►
Installation procedure
►
Operation instructions
►
Maintenance
►
Name list of parts
D: Nachdruck, auch auszugsweise, nicht gestattet! GB: Reproduction, even in extracts, is not permitted! NL: Nadruk, ook slechts gedeeltelijk, niet toegestaan!
Anleitung Nr.: 20180903023000
Contents
Einziehbare Markise
BW23000
Gebrauchsanleitung
Installation Instruction
Advertisement
Related Manuals for Konifera BW23000
Summary of Contents for Konifera BW23000
- Page 1 WARNING - IT IS IMPORTANT FOR SAFETY OF PERSONS TO FOLLOW THESE INSTRUCTIONS. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE Contents ► Einziehbare Markise Specifications/Precautions and safety BW23000 warnings for installation and operation ► Accessories and required tools ► Installation procedure ►...
- Page 2 ► Liste der Bauteilbezeichnungen ........9 Spezifikation Artikelnummer Neigungswinkel Tuch Windwiderstandsklasse BW23000 0° 45° Polyester Klasse 1 (28Km/h) - 2 -...
- Page 3 Spezifikationen/Vorsichtsmaßnahmen und Sicherheits- hinweise zum Einbau und zur Bedienung Specification Specification LESEN SIE ZUERST DIE BEDIENUNGSANLEITUNG, BEVOR SIE DAS GERÄT BENUTZEN. Net weight Specification Inclination angle Net weight Fabric Wind resistance class Artical number Inclination angle Artical number Fabric Wind resistance class (Kg) (Kg) Achtung!
- Page 4 Zubehörteile und erforderliche Werkzeuge Accessories and required tools Awning (amount: 1) Markise (Stückzahl: 1) Swing hand hook Handkurbel (Stückzahl: 1) (amount: 1) Instruction (amount: 1) Anleitung (Stückzahl: 1) Achtung! Attention! The expansion bolts provided in the product is Die Dehnschrauben, die im Lieferumfang des Produkts for concrete or brick wall.
- Page 5 Einbauvorgang Installation procedure Installation procedure Vor dem Einbau Prior to installation Packen Sie die Artikel vorsichtig aus und lösen Sie die Verschnürungen. Es werden zwei Personen benötigt, um Carefully unpack and release the bindings. Need two persons to handle the product. das Produkt zu verarbeiten.
- Page 6 Einbau der Wandhalterungen Installation of wall brackets Die Löcher jeder Gruppe müssen in transversaler und in vertikaler Richtung auf derselben Linie sein. The holes of each group must be on the Markieren Sie die Höhe an der Wand und ermitteln same line in transversal direction and Sie die Lage der Bohrlöcher für die Wandhalterun- vertical direction.
- Page 7 Einbau der Markise in die Wandhalterungen Entfernen Sie die Schrauben an der Vorderseite der Wandhalterungen. Bringen Sie die Markise an den Wand- Installation of awning to wall brackets halterungen an, indem Sie den quadratischen Drehstab an den Wandhalterungen anbringen. Befestigen Sie die Markise, indem Sie die Wandhalterungen wieder mit den Schrauben und Muttern verschrauben.
- Page 8 Fehlerbeschreibung Description of mistake Description of mistake Tuch Fallstange Tuch Warnung: Wenn die Fallstange wie angezeigt den Rollkasten berührt, versuchen Sie nicht, sie näher Warning: When the front bar touches the roller as shown in the figure, don't try to make zueinander zu bringen, da es sonst zu Schäden am Produkt kommen könnte.
- Page 9 Name list of parts Liste der Bauteilbezeichnungen Name list of parts ◆arm Kassette Armhalterung cassette ◆end cap Endkappe shoulder ◆fabric Tuch ◆roller Rollkasten ◆torsion bar Drehstab ◆arm stand ◆gear-box Schwenkarm Getriebekasten ◆front bar Fallstange swing Handkurbel handhook ※ Note： Anmerkung: Wenn die Zubehörteile mit 1.When the parts with ◆...
- Page 10 EINZIEHBARE Name • Nome • Nom • Naam Name • Nome • Nom • Naam MARKISE Nr. • No. • n° Nr. • No. • n° BW13000 Typ • Type • Tipo Typ • Type • Tipo Produktberatung: 01806/ 63 06 30 Festnetz 20 Cent/Anruf, Mobilfunk max. 60 Cent/Anruf Produktberatung: 01806/ 63 06 30 Festnetz 20 Cent/Anruf, Mobilfunk max.
- Page 11 WARNING - IT IS IMPORTANT FOR SAFETY OF PERSONS TO FOLLOW THESE INSTRUCTIONS. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE Contents ► Retractable Awning Specifications/Precautions and safety BW23000 warnings for installation and operation ► Accessories and required tools ► Installation procedure ►...
-
Page 12: Table Of Contents
► Name list of parts ..........19 Specification Artical number Inclination angle Fabric Wind resistance class BW23000 0° 45° Polyester Class 1 (28Km/h) - 12 -... - Page 13 Precautions and safety warning for installation and operation Specification READ THE INSTRUCTION BEFORE USING THE PRODUCT Net weight Inclination angle Fabric Wind resistance class Artical number (Kg) Attention! Before opening the awning, make sure all the fixing bolts and secu- BW13000 Polyester 18-24...
-
Page 14: Accessories And Required Tools
Accessories and required tools Accessories and required tools Awning (amount: 1) Swing hand hook (amount: 1) Instruction (amount: 1) Attention! The expansion bolts provided in the product is for concrete or brick wall. If you are installing the awning on support other than for concrete or brick wall, please make sure the wall is of sufficient support and use the correct hardware Expansion bolt... -
Page 15: Installation Procedure
Installation procedure Installation procedure Prior to installation Carefully unpack and release the bindings. Need two persons to handle the product. Remove and store the hardware in a safe place to avoid losing. Beware of the sudden unfolding of any parts, especially the folding arms. Read the assembly instructions carefully before installation. - Page 16 Installation of wall brackets The holes of each group must be on the same line in transversal direction and vertical direction. Mark the height on the wall and locate the drill hole positions for the wall brackets.Drill the holes with masonry drill of 12mm diameter,The depth of the hole is above 100mm.
-
Page 17: Operation Instructions
Installation of awning to wall brackets Remove the bolts on the front of the wall brackets.Install the awning to the wall brackets by attaching the square torsion bar to the wall brackets.Lock the awning in place by replacing the bolts and nuts on wall brackets.Tighten the nuts to ensure the awning is attached to wall brackets securely. -
Page 18: Maintenance
Description of mistake Description of mistake Warning: When the front bar touches the roller as shown in the figure, don't try to make them closer, otherwise the product might be damaged. Wrong operation Correct operation Warning： Fabric should not be sunken during operation .Otherwise water will be accumulated on fabric.Please operate in correct method as shown in above figure. -
Page 19: Name List Of Parts
Name list of parts Name list of parts ◆arm cassette ◆end cap shoulder ◆fabric ◆roller ◆torsion bar ◆arm stand ◆gear-box ◆front bar swing handhook ※ Note： 1.When the parts with ◆ are damaged, don't use the product before they are replaced. - 19 -... - Page 20 RETRACTABLE Name • Nome • Nom • Naam Name • Nome • Nom • Naam AWNING Nr. • No. • n° Nr. • No. • n° BW13000 Typ • Type • Tipo Typ • Type • Tipo Produktberatung: 01806/ 63 06 30 Festnetz 20 Cent/Anruf, Mobilfunk max. 60 Cent/Anruf Produktberatung: 01806/ 63 06 30 Festnetz 20 Cent/Anruf, Mobilfunk max.
