READ BEOFRE THE USE AND THE INSTALLATION OF
WARNING - IT IS IMPORTATNT FOR SAFETY OF
PERSONS TO FOLLOW THESE INSTRUCTIONS. SAVE
THESE INSTRUCTIONS FOR FUTURE REFERENCE
● Specifications/Precautions and safety
warnings for installation and operation
● Accessories and required tools
● Installation procedure
● Operation instructions
● Maintenance
● Name list of parts
D: Nachdruck, auch auszugsweise, nicht gestattet! GB: Reproduction, even in extracts, is not permitted! NL: Nadruk, ook slechts gedeeltelijk, niet toegestaan!
Anleitung Nr.: 20180903028000
09030-BW28000.indd 1
THE PRODUCT
Contents
Einziehbare Markise
BW28000
Gebrauchsanleitung
Installation Instruction
04.10.18 20:08
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Konifera BW28000
Summary of Contents for Konifera BW28000
- Page 1 ● Operation instructions Gebrauchsanleitung ● Maintenance ● Name list of parts Installation Instruction D: Nachdruck, auch auszugsweise, nicht gestattet! GB: Reproduction, even in extracts, is not permitted! NL: Nadruk, ook slechts gedeeltelijk, niet toegestaan! Anleitung Nr.: 20180903028000 09030-BW28000.indd 1 04.10.18 20:08...
- Page 2 Nennstrom: 0.86A Nennleistung: 198W Drehzahl: 15 rpm Drehmoment: 40Nm Schutzklasse: IP44 maximaler Dauerbetriebszyklus: 2 Arbeitstemperatur: -20C° bis +80C° Fernbedienung DC90 Batteriebetrieb: 27A 12V Kanal des Senders: 433 MHz Betriebsbereich: Offen 200m, zwei Wände 30m - 2 - 09030-BW28000.indd 2 04.10.18 20:08...
- Page 3 Check the awning every 3 months to ensure all fixing are tightened and no damage on the products. No modification of the awning in any kind is allowed. personal injury. Save enough free space around the awning while rolling or unrolling. 09030-BW28000.indd 3 04.10.18 20:09 Never use it in rainy and windy days. personal injury.
- Page 4 (they are not included in the products) Schraubenschlüssel Schlagbohrmaschine Maßband Schrauben- Hammer Tape Power drill with Screwdriver Mallet Wrench (wrenches of M10 und M12 mit einer zieher drilling bit of Ø12 M10 and M12) Ø 12mm Bohrspitze - 4 - 09030-BW28000.indd 4 04.10.18 20:09...
- Page 5 Anpassungswert durch 0,5 bei einem Neigungswinkel von 60° und durch 0,71 bei figure with 0.5 for inclination angle of 60° and with 0.71 for the maximum inclination einem maximalen Neigungswinkel von 45° ersetzen.) angle of 45°) - 5 - 09030-BW28000.indd 5 04.10.18 20:09...
- Page 6 Sie alle Muttern festziehen. hole ， Check and ensure all wall brackets lies on same horizontal line before tightening all nuts. Höchstgrenze (Die Anzahl der Wandhalterungen wird in der Teileliste auf Seite 4 angegeben.) - 6 - 09030-BW28000.indd 6 04.10.18 20:09...
- Page 7 Öffnen Sie die Schalterbox und nehmen Sie die grauen Gummiauflagen an den oberen und unteren Enden heraus. in the pack. Open the switch box and take out the grey rubber pads at the top and bottom ends. - 7 - 09030-BW28000.indd 7 04.10.18 20:09...
- Page 8 Retract / close the awing Nach oben Einrollen / Einfahren der Markise Stop stop opening/closing process Stopp Stopp Vorgang Ausfahren / Einfahren extract / open the awning Nach unten Down Ausrollen / Ausfahren der Markise - 8 - 09030-BW28000.indd 8 04.10.18 20:09...
- Page 9 4.When maintenance or reparing is made on the electrical parts ,please make sure the awning is 4. Falls Wartung oder Reparaturen der elektrischen Teile durchgeführt werden, vergewissern Sie sich, dass die Markise vom disconnected to the power supply. Strom abgestellt ist. - 9 - 09030-BW28000.indd 9 04.10.18 20:09...
- Page 10 Anmerkung: Wenn die Zubehörteile mit beschädigt sind, verwenden Sie das Produkt nicht, bevor sie ersetzt wurden. ※ Note： 1.When the parts with ◆ are damaged, don't use the product before they are replaced. - 10 - 09030-BW28000.indd 10 04.10.18 20:09...
- Page 11 Quelle CH: 0848 85 85 02 Ackermann CH: 0848 85 85 31, Jelmoli Technik: 0848 858 530 Imported by baumarkt direkt GmbH & Co KG Imported by baumarkt direkt GmbH & Co KG Alter Teichweg 25, 22081 Hamburg, Germany Alter Teichweg 25, 22081 Hamburg, Germany - 11 - 09030-BW28000.indd 11 04.10.18 20:09...
- Page 12 09030-BW28000.indd 12 04.10.18 20:09...
-
Page 13: Specifications/Precautions And Safety Warnings For Installation And Operation
● Operation instructions Gebrauchsanleitung ● Maintenance ● Name list of parts Installation Instruction D: Nachdruck, auch auszugsweise, nicht gestattet! GB: Reproduction, even in extracts, is not permitted! NL: Nadruk, ook slechts gedeeltelijk, niet toegestaan! Instruction No.: 20180903028000 09030-BW28000.indd 13 04.10.18 20:09... -
Page 14: Table Of Contents
Rotational speed: 15rpm Torque: 40Nm Protection class: IP44 Maximum continuous operation cycle: 2 Working temperature: -20C° to +80C° Remote control DC90 Battery operation: 27A 12V Transmitter channel: 433MHz Operation range: Open 200m, two walls 30m - 14 - 09030-BW28000.indd 14 04.10.18 20:09... - Page 15 Check the awning every 3 months to ensure all fixing are tightened and no damage on the products. Do not use the awning if repair is needed.Do not try to repair the product by yourself,contact qaulified person for repairing. - 15 - 09030-BW28000.indd 15 04.10.18 20:09...
-
Page 16: Accessories And Required Tools
Wall base 4.5m～6m Please prepare the following tools before installation (they are not included in the products) Power drill with Tape Screwdriver Mallet Wrench (wrenches of drilling bit of Ø12 M10 and M12) - 16 - 09030-BW28000.indd 16 04.10.18 20:09... -
Page 17: Installation Procedure
0.17 is the adjustment figure at our recommended angle of inclination of 80°. (If you prefer using the awning with smaller inclination angle ,you can replace the figure with 0.5 for inclination angle of 60° and with 0.71 for the maximum inclination angle of 45°) - 17 - 09030-BW28000.indd 17 04.10.18 20:09... - Page 18 ， Check and ensure all wall brackets lies on same horizontal line before tightening all nuts. Ceiling (Wall brackets number please refer to page 2 parts list.) 16 parts list.) - 18 - 09030-BW28000.indd 18 04.10.18 20:09...
- Page 19 1. Open the pack and make sure there is no missing components. Use only the parts provided in the pack. Open the switch box and take out the grey rubber pads at the top and bottom ends. - 19 - 09030-BW28000.indd 19 04.10.18 20:09...
-
Page 20: Operation Instructions
An indicator light is flashing when one of the buttons is pressed. When power off, you can use hand crank to open or close the awning. Stop Down Press button Function Retract / close the awing Stop stop opening/closing process extract / open the awning Down - 20 - 09030-BW28000.indd 20 04.10.18 20:09... -
Page 21: Maintenance
3.Check the overall installation and all the fasteners regularly,especially at the beginning of a new season,to ensure the fasteners are tightened and in good conditions. 4.When maintenance or reparing is made on the electrical parts ,please make sure the awning is disconnected to the power supply. - 21 - 09030-BW28000.indd 21 04.10.18 20:09... -
Page 22: Name List Of Parts
Note: When the parts with are damaged, don‘t use the product before they are replaced ※ Note： 1.When the parts with ◆ are damaged, don't use the product before they are replaced. - 22 - 09030-BW28000.indd 22 04.10.18 20:09... - Page 23 Quelle CH: 0848 85 85 02 Ackermann CH: 0848 85 85 31, Jelmoli Technik: 0848 858 530 Imported by baumarkt direkt GmbH & Co KG Imported by baumarkt direkt GmbH & Co KG Alter Teichweg 25, 22081 Hamburg, Germany Alter Teichweg 25, 22081 Hamburg, Germany - 23 - 09030-BW28000.indd 23 04.10.18 20:09...
