2021
FW, FW HT
Fifth Wheel Towables
Owner's Manual
0283662.2021
A subsidiary of Thor Industries, Inc.

Advertisement

Table of Contents
loading

Related Manuals for Jayco Eagle FW 2021

Summary of Contents for Jayco Eagle FW 2021

  • Page 1 2021 FW, FW HT Fifth Wheel Towables Owner’s Manual 0283662.2021 A subsidiary of Thor Industries, Inc.

  • Page 3: Table Of Contents

    Weighing Your Tow Vehicle and RV Section 4: Vehicle Operation Towing RV Brake System Electric Brakes Brake Controller (customer supplied) Travel Trailer Breakaway Switch Hydraulic Brakes (if so equipped) Disc Brakes (if so equipped) Towing Behind Your RV 2021 Jayco Eagle FW...
  • Page 4 Table of Contents Factory Installed Hitch Reciever (if so equipped) Entrance Door Step(s) Stowable Entrance Door Step (if so equipped) Entrance Door Rear Backup Camera Prep Campsite Hook-Up LCI 3.0 Leveling System (if so equipped) Auto Leveling Touch Pad OneControl Touch Panel OneControl Touch Panel Linc Remote Linc Remote Control...
  • Page 5 Table of Contents Command Center Command Center Panel Command Center Panel w/Switch Modules GFCI Receptacle LCI One Control® System(if so equipped) LCI One Control® App(If So Equipped) Testing the Campsite Power Connection Connecting the Power Cord Inverter (if so equipped) BMPro RVMASTER SYSTEM (If So Equipped) Power Converter Converter with Charge Wizard (if so equipped)
  • Page 6 Table of Contents Calculating Propane Gas Usage Ensure a supply of fresh air (Canada units only) Cooking / Comfort Heating Label Traveling With Propane Installing Propane Cylinder(s) Refueling Warning Label Single Cylinder Main Supply Hose Double Cylinder Two Propane Cylinders Section 8: Plumbing System Plumbing System Plumbing System Maintenance...
  • Page 7 Table of Contents Section 9: Heating & Cooling Air Conditioner Roof Mount (if so equipped) Wall Mount (if so equipped) Heat Pump Operation (if so equipped) Power Roof Vent (if so equipped) Attic Fan Control Ceiling Fan (if so equipped) Furnace Fireplace (if so equipped) Section 10: Appliances...
  • Page 8 Booth Dinette (if so equipped) Free-Standing Table and Chairs (if so equipped) Pantry or Hutch (if so equipped) Countertops Laminate Countertops (if so equipped) Solid Surface Countertops (if so equipped) Flooring Carpet Vinyl Flooring Murphy Bed (if so equipped) Bed Storage Prop Rod (if so equipped) Loft Sleeping Area (if so equipped) Gas Struts (if so equipped)
  • Page 9 WARNING: Read all instructions in this manual and component manufac- turer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.

  • Page 11: Factory Tours

    Canada may differ to conform to Canadian Codes. Dealer Responsibility At the time of sale of the new recreation vehicle, your Jayco dealer is expected to: Deliver your recreation vehicle in the best condition possible. Your recreation ve- hicle must pass the dealer’s pre-delivery inspection (PDI), including all systems...
  • Page 12 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.

  • Page 13: To Contact Us

    Canada. In addition, the club offers a variety of local and regional activities throughout the year. By belonging to the Jayco Travel Club, you will find new ways to enjoy your RV and make friends all across the country.

  • Page 14: Warranty Packet

    Section 1: Warranty & Service Warranty Packet There are components that are excluded from the vehicle warranty, or are warranted sepa- rately by their own individual manufacturer’s limited warranty. The Warranty Packet con- tains these component manufacturer supplied manuals or information sheets, warranty cards and/or registrations.

  • Page 15: Reporting Safety Defects

    Section 1: Warranty & Service  Indicates a potentially hazardous situation that, if not avoided, may result in death or serious injury. Reporting Safety Defects In the United States: If you believe that your recreation vehicle has an alleged defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying our Cus- tomer Service Department.

  • Page 16: Customer Responsibility

    Section 1: Warranty & Service Customer Responsibility It is important you read and understand all instructions and precautions before operating the recreation vehicle. Even if you are an experienced RV’er we encourage you to thoroughly read this Owner’s Manual, as well as the information contained in your Warranty Packet and Chassis Guide (motorized only).

  • Page 17: Obtaining Service For Separately Warranted Items

    Section 1: Warranty & Service Please be aware that all service shops require notification of any issues with their repairs within a specified time limit. Make sure you are familiar with their repair policies. Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreational vehicle before delivery, and has an interest in your continued satisfaction.
  • Page 18 Canada and used for the intended purpose of recreational travel and camping. If a substan- tial defect in material or workmanship, attributable to Jayco, is found to exist and is reported to Jayco or an authorized servicing dealer during the applicable warranty period, it will be repaired or replaced, at Jayco’s option, without charge to the RV owner, in accordance with...
  • Page 19 RV is delivered to the first retail purchaser by an independent, authorized dealer of Jayco, or, if the dealer places the vehicle in service before retail sale, on the date the RV is first placed in such service.
  • Page 20 Pay any freight or transportation costs, import duties, fees and all incidental expenses associated with obtaining warranty service. If you need assistance, you may contact Jayco, at 903 S. Main Street, P.O. Box 460, Middle- bury, Indiana 46540, Attn: Customer Service, (800) 283-8267.
  • Page 21 • damage, rust, or corrosion due to the environment, theft, vandalism, fire, or other inter- vening acts not attributable to Jayco; • damage caused by unregulated water pressure, tank over fill, or plumbing system modi- fications resulting in flooding of the vehicle;...
  • Page 22 In addition, this warranty is not intended to extend to future performance, and nothing in this warranty, or any action of Jayco, or any agent of Jayco, shall be interpreted as an extension of the warranty period or this limitation period.
  • Page 23 ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE. ALL ACTIONS OF ANY KIND RELATING TO THE RV SHALL BE DECIDED BY A JUDGE RATHER THAN A JURY. JAYCO, INC. 903 S. Main Street * P.O. Box 460 * Middlebury, IN 46540 Telephone: (800)-283-8267...
  • Page 24 Section 1: Warranty & Service Notes:...

  • Page 25: Secondary Means Of Escape (Exit Window)

    Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.

  • Page 26: Fire Safety

    Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper right arrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the window. Push the lever (and window) out to open and exit the vehicle. Fire Safety If a fire does start, follow these basic safety rules: Call 911 and evacuate the vehicle immediately.

  • Page 27: Smoke Alarm

    Section 2: Occupant Safety  Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.

  • Page 28: Combination Carbon Monoxide /Propane Alarm

    Section 2: Occupant Safety When the battery becomes weak, the alarm will “beep” about once a minute indicating a low bat- tery. This warning should last for 30 days. You MUST replace the battery once the alarms low battery warning (beep) starts to assure continued protection.
  • Page 29 Section 2: Occupant Safety  The carbon monoxide detector installed is intended for use in ordinary indoor locations of recreation vehicles. It is not designed to comply with Occupational Safety and Health Administration (OSHA) commercial or industrial standards. Do not disconnect the battery or the alarm. Individuals with medical problems may consider using warning devices that provide audible and visual signals for carbon monoxide concentra- tions under 30 PPM.
  • Page 30 Section 2: Occupant Safety What you should do if the alarm sounds  Actuation of this detector indicates the presence of carbon monoxide which can kill you. Never turn the 12-volt battery disconnect control to the off position and disconnect the battery cable to silence an alarm. The alarm will auto- matically sense when the level of carbon monoxide in the air reaches below dangerous levels.
  • Page 31 Section 2: Occupant Safety Power OFF: Both LEDs and the audible horn will be OFF. Self Test: Green LED OFF, Red LED ON/Flashing, audible horn 4 chirps followed by constant beeps. CO alarm condition: Green LED OFF, Red LED Flashing, audible alarm 4 chirps.

  • Page 32: Formaldehyde

    Section 2: Occupant Safety Formaldehyde Some components in the recreation vehicle contain formaldehyde-based adhesives that may release form- aldehyde fumes into the air for an unknown period of time. Individuals who are allergic to formaldehyde gas fumes may experience irritation to eyes, ears, nose and throat.

  • Page 33: Condensation

    Section 2: Occupant Safety Condensation  Condensation may cause dampness, mildew, mold, staining and, if allowed to continue, it may result in damage to the recreation vehicle (damage caused by condensation is not warrantable). It can also lead to mold or mildew issues, which could be a health hazard.
  • Page 34 Section 2: Occupant Safety Notes:...

  • Page 35: Tow Vehicle

    Section 3: Pre-Travel Information Tow Vehicle If you plan to tow your recreation vehicle with a tow vehicle you already own, or if you plan to purchase a new one, make sure the Gross Vehicle Weight Rating (GVWR) or your recreation vehicle does not exceed your tow vehicles towing rating.

  • Page 36: Occc Label (Yellow)

    Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity The upper portion of this yellow label is feder- ally required and includes the maximum Occu- pant and Cargo Carrying Capacity that may be placed in or on the trailer as it was manufac- tured and weighed before leaving the factory.

  • Page 37: Loading Your Recreation Vehicle

    Section 3: Pre-Travel Information Loading Your Recreation Vehicle  Never load the RV in excess of the GAWR for either axle. Overload- ing your RV may result in adverse handling characteristics and dam- age to the RV. DO NOT EXCEED YOUR GVWR! This means you should weigh your RV as loaded for your normal travel to determine the actual weight.

  • Page 38: Rear Bumper

    Section 3: Pre-Travel Information Rear Bumper The rear bumper of your RV is not designed to carry cargo. Items that extend beyond the bumper OR weigh over 100 lbs. (45kg) will place undo strain on the bumper. The 100 lb. bumper capacity includes the weight of the spare tire (if so equipped).

  • Page 39: Fifth Wheel Pin Box

    Section 3: Pre-Travel Information Your recreation vehicle manufacturer cannot be responsible for the suspension system of any tow vehicle. There are a variety of tow vehicle suspension systems available that will affect the pin box height, stability and levelness of a hooked up RV. Make sure your dealer is aware of the tow vehicle you are using so a compatible hookup is achieved.

  • Page 40: Wire Harness/Connector Plug

    Section 3: Pre-Travel Information Wire Harness/Connector Plug A 7-way wire harness/connector plug is wired into your trailer to connect electrical power from the tow vehicle for travel. This supplies power to the RV brakes, taillights, clearance lights, turn signals, brake lights, etc. Wiring to operate your brakes must be the same size in both the tow vehicle and RV (the RV brake wiring is 12-gauge wire).
  • Page 41 Section 3: Pre-Travel Information To weigh your tow vehicle and RV  Total weight of your tow vehicle and RV must not exceed the GCWR. Do not assume that you can tow a RV that happens to be within the ca- pacity of the tow vehicle hitch.
  • Page 42 Section 3: Pre-Travel Information Notes:...

  • Page 43: Towing

    A caution label has been placed in an area near the battery disconnect switch on your RV. The Jayco luxury fifth wheel models have the battery disconnect switch located in the same compartment with the propane tanks. Depending on the model of RV and manufacturer (Jayco or Highland Ridge) your RV will have one of these two labels shown below.

  • Page 44: Rv Brake System

    Section 4: Vehicle Operation When descending a long hill, drop down into a lower gear or range. Avoid conditions that require excessive and prolonged use of your brakes. Apply and release brakes at short inter- vals to allow them to cool. The tow vehicle transmission and engine will help in controlling downhill speed and can lengthen brake life.

  • Page 45: Brake Controller (Customer Supplied)

    Section 4: Vehicle Operation Brake Controller (customer supplied) The brake controller should be installed in the tow vehicle to work in conjunction with the RV electric brakes. Consult with your dealer or the brake controller OEM to decide what is right for your towing combination.

  • Page 46: Towing Behind Your Rv

    If you do not have a Jayco factory installed hitch receiver, towing items behind your Jayco RV, or overloading the rear, will void the warranty and may result in: damage to the RV or add-on items, towing difficulties, property dam- age and/or personal injury.
  • Page 47 Section 4: Vehicle Operation NOTE: IF YOU DO NOT HAVE A JAYCO FACTORY IN- STALLED HITCH RECEIVER, DO NOT TOW ANYTHING BEHIND YOUR RV. THE RV FRAME AND BUMPER ARE NOT DESIGNED FOR TOWING. The hitch receiver may be used as a weight carrying hitch to tow a boat or other watercraft trailer.

  • Page 48: Entrance Door Step(S)

    Section 4: Vehicle Operation Attach the safety chains. See Safety Chains for additional information. Plug in the wire harness/connector. Walk around the RV and the second trailer making sure all exterior lights are working correctly. Remove the trailer wheel blocks. Wire Harness/Connector Plug A 4-way wire harness/connector plug is wired into your RV to connect electrical...

  • Page 49: Entrance Door

    Section 4: Vehicle Operation  Maximum Weight Capacity 500 lbs. Maintain hold of the steps until lowered all the way to the ground. Prior to use, legs must be adjusted properly to ensure the step is level. Ensure that both latches are engaged when the steps are stored. Failure to follow these instructions could lead to damage to the unit or serious injury.

  • Page 50: Rear Backup Camera Prep

    Section 4: Vehicle Operation  Make sure the entrance door is completely closed and locked when traveling. Locking the door helps prevent it from opening unintentionally and keeps in- truders from your recreation vehicle. The entrance screen door may be equipped with a slide panel that allows access to the en- trance door handle and locks.

  • Page 51: Lci 3.0 Leveling System (If So Equipped)

    Section 4: Vehicle Operation When using full hook-up, connect the sewer hose to the campsite sewer hook-up. If applicable, start the refrigerator and the cooling or heating system. NOTE: For extended dry camping, management of all your resources is essential. Check your battery levels and conserve battery power, use it sparingly LCI 3.0 Leveling System (if so equipped) The LCI Ground Control 3.0 is an electric 4 or 6 point automatic leveling control.

  • Page 52: Auto Leveling Touch Pad

    Section 4: Vehicle Operation Auto Leveling Control Touch Pad A - Red/Green LED indicates system status B - Up Arrow extends front jacks (landing gear) C - Down Arrow retracts front jacks (landing gear) D - Auto Level button places system in the auto level mode E - Hitch Height button initiates the Hitch Rec- ognition feature...

  • Page 53: Onecontrol Touch Panel

    Section 4: Vehicle Operation Each jack will perform a final grounding touch. NOTE: On a 6 point system the 2 middle jacks will be grounded to stabi- lize the trailer. The 2 middle jacks do not level the RV NOTE: If the AUTO LEVEL sequence does not perform as described above, place the system in manual mode and test that the jacks operate correctly by using the OneControl touch panel inside the RV.

  • Page 54: Onecontrol Touch Panel

    Section 4: Vehicle Operation The App will now display all functions. Choose Leveler. The following functions can be operated using the OneControl App. Refer to the Ground Control 3.0 manual for complete instructions. Standard Mode and Menu Basic Jack operation Unhitching Instructions Auto Leveling Linc Remote Control...

  • Page 55: Stabilizer Jacks

    Section 4: Vehicle Operation Stabilizer Jacks  DO NOT USE THE STABILIZER JACKS TO LEVEL THE RV. It is important to remember that the stabilizer jacks are to be used only for support while occupying and moving around the RV. They are not designed to support the weight of the RV.

  • Page 56: Emergency Stopping

    Section 4: Vehicle Operation Emergency Stopping Always carry road flares or reflective warning signs. Pull off the roadway as far as possible for emergency stopping. Turn ON your vehicle hazard warning flashers. If traveling at night, use three red warning indicators such as flares, reflectors or lanterns as required by the Uniform Vehicle Code and Model Traffic Ordinance as follows: Place the first warning indicator on the traffic side of the recreation vehicle, directed at the nearest approaching traffic.

  • Page 57: Wheel Lugs

    Section 4: Vehicle Operation Wheel Lugs After your first trip, check the wheel lug torque periodically for safety. Check the wheel lugs after winter storage, after a wheel removal, before starting a trip or following extensive braking: Use the correct star pattern sequence to attach the recreation vehicle wheels. Start all nuts by hand to prevent cross threading.

  • Page 58: Wheel Lug Nut Torque Values

    Section 4: Vehicle Operation Wheel Lug Nut Torque Values Prior to travel and after excessive braking, wheel lug nuts should be checked for torque. Torque readings must fall within the Final Torque Values in chart above. Torque specifications should be checked using a proper torque wrench. If the torque falls below the Final Torque Values, additional torque is required.

  • Page 59: Tires

    Section 4: Vehicle Operation Torque Wrench Usage Tools should be maintained, in good condition, and stored appropriately. • Avoid dropping or sliding a torque wrench. Dropping it can cause the instrument to lose reliable calibration. • Damaged tools must not be used and must be removed from service for evaluation and either reported and re-calibrated or replaced.
  • Page 60 Section 4: Vehicle Operation  Tire wear should be checked frequently. Once a wear pattern becomes firmly established in a tire it is difficult to stop, even if the underlying cause is cor- rected. Tire Pressure  Failure to follow proper inflation guidelines may result in tire failure, which, under certain circumstances can cause loss of vehicle control or accidents that may result in property damage, bodily injury and/or death.

  • Page 61: Changing A Tire

    Section 4: Vehicle Operation NOTE: Cold tire inflation pressure is defined as a tire that has not been used for three or more hours, or has been driven less than one mile. Tire inflation pressure of a hot tire may show an increase of as much as 6 psi over a cold tire.

  • Page 62: Spare Tire Carrier (If So Equipped)

    Section 4: Vehicle Operation Keep the recreational vehicle attached to the tow vehicle. Block the tire on the opposite side of the recreational vehicle from the tire you are changing. Loosen the wheel lug on the tire you are changing before jacking up the vehicle. DO NOT remove the lug nuts;...

  • Page 63: Bumper Mount

    Section 4: Vehicle Operation NOTE: If the manual crank access port is located in a slideout, the slideout room must be in the travel position to allow the crank to reach the mechanism used to raise or lower the tire. Crank Access Port Securing the spare tire To secure the spare tire in the travel position, put the steel hoist lift...

  • Page 64: Setting Up Your Recreation Vehicle

    Section 4: Vehicle Operation Vinyl Tire Cover (if so equipped) Your tires are manufactured with components that cause “bleeding” onto the tire cover. To prevent this, it is recommended to use a separator (garbage bag, paper, cloth, etc.) between the tire and the cover. Setting Up Your Recreation Vehicle Position the RV as desired.

  • Page 65: Awning Care

    Section 4: Vehicle Operation Awning Care Keep your awnings clean and in good condition to prevent costly repairs. Periodically check that the fasteners are tight. Tighten if necessary. Keep the awning fabric clean. For detailed cleaning information, refer to the manufacturer’s owner information.
  • Page 66 Section 4: Vehicle Operation Notes:...

  • Page 67: Electric Slide Room(S) (If So Equipped)

    Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.

  • Page 68: General Slideout Troubleshooting Checklist

    Section 5: Slideout Systems To retract the slideout, press the in section of the slideout control switch and hold it until the slideout is fully retracted. Operating the switch after the room is fully extended or retracted may damage the switch and motor.
  • Page 69 Section 5: Slideout Systems NOTE: For long-term storage it is recommend the room be closed (retracted). Trouble shooting the flush floor slideout Refer to the general troubleshooting check list before proceeding. Electric Operation NOTE: Install transit bars (if so equipped) on the slideout room during storage and transportation.

  • Page 70: Schwintek In-Wall Slideout System

    Section 5: Slideout Systems Schwintek In-Wall Slideout System The in-wall slideout system requires no maintenance or adjustments. This system has two vertical columns with a drive motor located at the top of each column. The right and left motors are synchronized by a circuit board.Schwintek slideouts are typically used on both towables and motorhomes.
  • Page 71 Section 5: Slideout Systems Trouble shooting the in-wall slideout system Checking Fuses: The in-wall slide requires a minimum 30-amp fuse. Check the load center for blown fuses and replace any if necessary. If the fuse blows immediately upon replace- ment, there is a problem with the wiring to the in-wall slide control box. A qualified service person should be called to check and repair.
  • Page 72 Section 5: Slideout Systems Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diag- nosed.

  • Page 73: Norco Slideout System

    Section 5: Slideout Systems Physically push/ pull the room back into the opening; keep both sides relatively even. The room must be travel locked to keep the room in place for road travel.  DO NOT MOVE THE RV UNLESS THE MOTORS ARE PLUGGED IN TO THE CONTROLLER AND THERE IS BATTERY POWER TO THE RV.

  • Page 74: Power Gear Slideout System

    Section 5: Slideout Systems Norco Slideout Manual Operation Locate the included flexible shaft in your own- er’s packet. Attach flexible shaft to the 1/4” hex fitting on the end of the motor. Attach 1/4” socket & ratchet, or drill to the other end, and turn in the proper direction to move the room.
  • Page 75 Section 5: Slideout Systems If the room does not move when the switch is pressed, check the following: Make sure the slideout system is turned on. Battery is fully charged and connected. Transit bars have been removed (if so equipped). ...

  • Page 76: Power Gear Slim Rack Slideout System

    Section 5: Slideout Systems The room is now free to move. Using either a 5/8” or 3/4” wrench or socket, crank the room either in or out completely. If the slideout system is supplied with a gearbox override (optional), use the crank handle to move the room.
  • Page 77 Section 5: Slideout Systems hold the IN button. There will be a slight delay before the room begins moving. The GREEN LED should be solid ON when room is in motion. Release the OUT button when the room is fully extended or the IN button when fully retracted, and stops moving.
  • Page 78 Section 5: Slideout Systems -Check all connections at control box and motor. -Bad or loose connec- Excessive -Check the harness for bro- tion Major Battery Volt- ken wires. -Defective harness -Put 12.0 VDC direct to -Open or shorted motor the motor. If it does not run replace the motor.
  • Page 79 Section 5: Slideout Systems NOTE: After overriding the system, the room control will need to be re- programmed by an OEM authorized dealer. Emergency Retract Mode Use this procedure when there is NO loss of power or electrical problem with the system. Remove the touchpad (Fig 4) from the wall.
  • Page 80 Section 5: Slideout Systems Repeat steps 1-4 for the other side. Place a socket wrench with a 3-inch extension and a 5/8” deep well socket (Fig 12) through the motor access opening and seat the socket onto the coupler (Fig 13). One person alternating from side to side of the room can retract a 1500 lb.

  • Page 81: Power Gear Ram Slideout System

    Section 5: Slideout Systems Power Gear Ram Slideout System Typically used for Class C motorhomes. Manual Override Procedure The system has been equipped with 3/4” hex override couplers located on the drive compo- nent of the system. Due to the size and weight of some rooms, assistance may be needed to push the room in.
  • Page 82 Section 5: Slideout Systems 12. Return the brake release lever back to the “engaged” position (parallel to the spring lock lever). Pressing the bent end of the spring lock lever will allow the brake le- ver to be moved. 13. Plug the motor connector back in again. 14.

  • Page 83: The Electrical System

    Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.

  • Page 84: Command Center

    Section 6: Electrical System Command Center The command center is typically located inside the entrance door or in the living area of the RV, and contains switches and controls for various electrical functions. Command center applications, con- figurations and components will vary by model. Command Center Panel or Command Center Panel with Switch Modules Items found on these panels may include:...

  • Page 85: Gfci Receptacle

    Section 6: Electrical System GFCI Receptacle There is a ground fault current interrupter (GFCI) engineered into the electrical system. It is designed to reduce the possible injury caused by electric shock. The GFCI will not protect against short circuits or circuit overloads. Test all GFCI receptacles monthly: Push in the GFCI “TEST”...
  • Page 86 Section 6: Electrical System Bluetooth Operation of the One Control® System A Bluetooth control module is typically installed in the basement area of the RV. The Bluetooth control module works in conjunc- tion with the One Control Touchscreen System. Connecting to the system is accomplished through a 6 digit password.
  • Page 87 Section 6: Electrical System operate. When the bedroom door is opened and the catch pieces connect, the Slide 01 notification appears on the touchscreen display and the slide- out can then be operated normally. NOTE: This same safety feature applies to the slide-out switch on the wall or on the Command Center switch panel.

  • Page 88: Lci One Control® App(If So Equipped)

    Section 6: Electrical System Pressing the SLIDES button will open a selec- tion screen showing all the slides on the RV (Fig 14). Selecting one of the slides will open an- other screen which has In and Out buttons (also labeled + and -).
  • Page 89 Section 6: Electrical System NOTE: Not all the functions depicted here will necessarily be available on your model RV. The systems shown are only a possible representation of what you could see on your smart device. If specific apps are not displayed on your device they are not installed and may not be available for your RV.

  • Page 90: Testing The Campsite Power Connection

    Section 6: Electrical System IMPORTANT SAFETY FEATURE: IF SLIDE 01 IS MISSING FROM THE LIST: This indicates there is a problem with the bedroom slide-out. In order for the slideout to function properly, the bedroom door MUST BE OPEN. An electronic door catch has been installed to the wall in the bedroom behind the door (Fig 9).

  • Page 91: Connecting The Power Cord

    Section 6: Electrical System  Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. DO NOT plug the shore power cord into a campsite receptacle(s): That has reverse polarity With non-functioning ground circuits That shows outward signs of heat damage.

  • Page 92: Inverter (If So Equipped)

    Section 6: Electrical System The shore line power cord should be unplugged when the recreation vehicle is left unattended. If something would happen to the electrical system, this may help limit potential damage. When you are ready to leave, reverse the power cord connection process. Use care to pre- vent damaging the power cord electrical connection pins when connecting or disconnecting the shore line power cord.
  • Page 93 Command Control System (If So Equipped) The Command Control System is a name given to encompass several different types of Bluetooth controlled systems now being used in Jayco and Highland Ridge towable RVs. Examples of Bluetooth controlled systems currently in use are listed below.

  • Page 94: Bmpro Rvmaster System (If So Equipped)

    ○ Jayco JayCommand BMPro Mini control system (uses the JayCommand App for Apple/Android) Jayco LCI One Control touchscreen system (with a leveling system installed) ○ Check the Table of Contents in this manual to identify your Bluetooth system and more specific information on system operation.
  • Page 95 Section 6: Electrical System ○ RV Auto Leveling systems ○ Power Jacks and Stabilizers ○ Interior and Exterior Lights ○ RV Slide-out Rooms ○ Power Awnings ○ Generator ○ TV and Bed Lifts ○ HVAC thermostat ○ Gas and Electric water heaters ○...
  • Page 96 Section 6: Electrical System The battery is now accessible on the back of the remote. To replace the remote on the wall bracket: ○ Hook the top of the remote back on the top of the wall bracket. ○ Push the bottom of the remote back in place. You will again hear an audible snap as it attaches to the mount.
  • Page 97 Section 6: Electrical System Menu Display shows A1 or A2 (awnings) Cycle between aw- nings with the arrows. Press and hold EXT or RET to extend or retract the ○ selected awning. ○ Menu Display shows b1 or b2 (bunk lifts) Cycle between bunk lifts with the arrows press EXT or RET to operate.
  • Page 98 Section 6: Electrical System NOTE:after connecting to the app, it automatically locks the RVMaster Motors screen on your smart device to prevent inadvertent operation of the systems in the RV. You must swipe the lockout indicator on the screen to unlock the motor controls.
  • Page 99 Section 6: Electrical System Rotating the tires:  TPMS sensors – DO NOT MOVE WITH THE TIRES! • The TPMS sensor on the front tire (on either side of the trailer) STAYS at • the front tire position when rotating tires. •...
  • Page 100 Section 6: Electrical System Installing tire sensors Tire sensors come already paired to the RVMaster sys- tem from the factory. Sensors come on a card (F) that shows where each sensor should be installed on the RV. The top of the card represents the “hitch” end of the RV.

  • Page 101: Power Converter

    Section 6: Electrical System ○ The app on your smart device automatically locks out the Motors screen on your device. You must swipe to unlock the screen in order to operate motors. ○ Only one motor may be operated at a time ○...
  • Page 102 Section 6: Electrical System • Reverse polarity fuse provides protection for the converter when a battery is used. If the battery is connected backwards to the fuse board this fuse would blow pre- venting damage to the converter. If your lights are dimming or flickering that usually indicates an overloaded con- •...

  • Page 103: Converter With Charge Wizard (If So Equipped)

    Section 6: Electrical System Converter with Charge Wizard (if so equipped) Some converters may be equipped with a charge wiz- ard There are (3) possible charging modes; NORMAL, BOOST and STORAGE. The charge wizard will auto- matically select the best mode to charge your battery. A green LED next to the wizard mode button will indicate by flashes, which mode is currently being used.

  • Page 104: Auxiliary Battery (Customer Supplied)

    Section 6: Electrical System Replacing a Fuse Before replacing a fuse, always turn off the electrical components protected by it. Disconnect the shore power cord. Turn “off” the inverter (if so equipped). Disconnect the house or auxiliary batteries main negative battery cable. Remove the fuse panel cover to check fuses.

  • Page 105: Dry Camping

    Section 6: Electrical System Dry Camping The auxiliary battery should be fully charged prior to dry camping. If the auxiliary battery is not being recharged and power is being drawn from it, it will eventually discharge. A battery will discharge at a faster rate as its energy level becomes depleted. Plan your electrical us- age accordingly.

  • Page 106: Load Center

    Section 6: Electrical System Rotating Dial Disconnect Switch When this switch is ON, there will be a green area showing a “1” along the top of the switch. To turn the switch OFF, turn it counter-clockwise until you see the red area along the left side of the switch showing a “0”...
  • Page 107 Section 6: Electrical System NOTE: Load Centers may not always include a main circuit breaker.  Circuit breakers and fuses will not offer complete protection of the electrical system in the event of power surge or voltage spike. Replacement Only replace circuit breakers with those of the same specified type, voltage, and current rat- ing.

  • Page 108: Approximate Electrical Load Ratings

    Section 6: Electrical System Approximate Electrical Load Ratings 12 VOLT SYSTEM Exterior Entertainment Center 5-7 AMPS 1.5 AMPS Furnace 12.0 AMPS Generator Start 95.0 AMPS* Illuminated Switch .125 AMP Inverter variable Leveling System 95.0 AMPS* LP Detector .125 AMP Light; LED 1.7 AMPS Light;...

  • Page 109: 120-Volt (30 Amp) Ac System (If So Equipped)

    Section 6: Electrical System 120-Volt (30 AMP) AC System (if so equipped) The 30 amp 120-volt 60hz AC electrical system.is designed to operate on 1 leg of 120-volt power at a maximum current flow of 30 amperes. Exposure to voltages higher or lower than a nominal 120-volts will damage or shorten the service life of the electrical system and appliances.

  • Page 110: 120-Volt (50 Amp) Ac System (If So Equipped)

    Section 6: Electrical System Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it. If the ground monitor indi- cates ‘reverse polarity’ or an ‘open ground’ DO NOT connect the power cord. Regularly inspect the shore power cord for cuts, cracks, worn insulation and other damage.

  • Page 111: 50-Amp Power Cord

    Section 6: Electrical System 50-AMP Power Cord:  Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. Polarity indicators can be purchased in most electrical and hardware stores. Do not use any cheater plug, adapter or extension cord to reconfigure incoming AC power or break the continuity of the circuit connected to the grounding pin.

  • Page 112: Solar Prep (If So Equipped)

    Section 6: Electrical System Solar Prep (if so equipped) Your recreation vehicle may be wired with a (exterior) plug in that will allow the batteries to be trickle charged using a free standing solar panel. In most models, the solar panel kit is a customer purchased and installed option.

  • Page 113: Section 7: Fuel & Propane System

    Section 7: Fuel & Propane System Exhaust Gas Fumes  Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a recreation vehicle with either a nearby tow vehicle engine running or the generator (if so equipped) running there is a potential for exhaust fumes to filter back into the recreation vehicle.

  • Page 114: Propane Gas Container

    Section 7: Fuel & Propane System Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year), by a qualified propane service representative as part of your normal maintenance is recommended. Hand tighten the LP gas system valves only, do not use a wrench or pliers as over tightening may damage the valve seals and cause them to leak.

  • Page 115: Servicing Or Filling

    Section 7: Fuel & Propane System Be sure to securely re-install DOT cylinder(s) after they have been removed for filling or replacement. Always close the service valve and install a dust cap or plug when transporting or storing disconnected containers whether full or empty. ASME tanks are permanently mounted to the RV and are commonly used on RV mo- torhomes.

  • Page 116: Do Not Fill To More Than 80%" Label

    Section 7: Fuel & Propane System The position of the propane container(s) and the hoses are critical to proper operation and propane flow. Follow these instructions to make sure your propane container(s) are connected properly. LP Gas Container Overfill Never allow your propane tank to be filled above the maximum safe level as indicated by the fixed liquid level gauge.

  • Page 117: Propane Regulator

    Section 7: Fuel & Propane System Fittings are used to connect the various system components to each other. The P.O.L. fitting at the end of the propane supply hose is made of brass so that pipe sealants are not necessary to prevent leaking.

  • Page 118: Propane Use And Safety

    Section 7: Fuel & Propane System Propane Use and Safety Propane is a colorless and odorless gas that, in the liq- uefied state, resembles water. An odorant (usually a sulfur compound) is added as a warning agent. If you smell propane within the vehicle, quickly and carefully perform the procedure listed on the propane system la- bel.

  • Page 119: Cooking With Propane Gas

    Section 7: Fuel & Propane System If you have double cylinders on your recreation vehicle, use only one at a time. Otherwise, the propane supply will be drawn equally from both cylinders until the supply has been total- ly exhausted. Using one cylinder until it is empty, then using the second cylinder will allow you to fill the empty cylinder at your convenience without running totally out of propane.

  • Page 120: Traveling With Propane

    Section 7: Fuel & Propane System NOTE: Some states prohibit propane appliances to be operated dur- ing travel, especially in underground tunnels. Make sure you know the laws for the areas where you travel. Traveling With Propane Use care when fueling your motor fuel tanks and/or propane containers.

  • Page 121: Main Supply Hose

    Section 7: Fuel & Propane System Double Cylinder Mounted On A-Frame (if so equipped) When a second cylinder is installed, a tee check valve is used to replace the 90° elbow at the top of the regulator and another 1/4” inverted flare x 24” Type 1 pigtail is added.
  • Page 122 Section 7: Fuel & Propane System Notes:...

  • Page 123: Section 8: Plumbing System

    Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, outside shower assembly (if so equipped), water heater, tub/ shower, and water purification system (if so equipped).

  • Page 124: Command Center

    Section 8: Plumbing System Operation Press only one tact switch at a time. As you push either the FRESH, BLK GREY1 or GREY2 switch, one or more LED lights will illuminate (from left to right) indicating the content level for that tank. When pushing the “BATT” switch, the LED lights illuminate from left (lowest) to right (highest) to indicate the estimated auxiliary battery condi- tion.

  • Page 125: Fresh Water System

    Section 8: Plumbing System NOTE: This light will not appear on touchscreens, RV remote controls or on a WiFi app, it will only appear on the Command Center switch panel. Fresh Water System All water contains contaminant and mineral particles that can cause fresh water system odors.

  • Page 126: Draining The Fresh Water System

    Section 8: Plumbing System 12-Volt Water Pump and Switch When you want to use water in your recreation vehicle and it is not hooked up to city water, you will need sufficient 12-volt DC power to run the water pump. Once activated, the water pump (also known as the demand pump) will self-prime, and pro- vide water.

  • Page 127: Utility Center - 2 Valves (6 In 1)

    Section 8: Plumbing System Open the “low point drains” by turning, then pulling the handles up. They are installed at the lowest point of the water lines. A label is placed on the outside of the RV to indicate where the drains are located. The drains will need to be operated from inside the RV.
  • Page 128 Section 8: Plumbing System NOTE: The country fill and sanitizing/winterizing functions are performed from a pair of (2) two way valves plumbed inside the RV; a black valve on the suction line, and a white valve that directs water to the fixtures or the water tank.
  • Page 129 Section 8: Plumbing System Water Valve Configurations NORMAL (CITY WATER): This setting will supply fresh water to all fixtures in the RV from a pressurized water source attached to the utility center panel. Utility center valve should be set to CITY WA- TER position (pointing down).
  • Page 130 Section 8: Plumbing System SANITIZE TANK: This setting is for putting sanitizer into the fresh water tank (refer to sanitize tank and country fill diagram). NOTE: Utility center blue valve position does not matter as it is not used for sanitizing. Black valve should be turned so it points to the clear suction hose.

  • Page 131: Sanitizing The Plumbing System

    Section 8: Plumbing System Bypass Mode operation diverts the flow of water around the water heater keeping water out of the water heater. Hot water bypass valve (B) should point away from water heater and inline with the hot water output.
  • Page 132 Section 8: Plumbing System Turn the black valve (at the pump) so it is pointing to the clear siphon hose. Turn the white valve (at the pump) so it is pointing to the left toward the water tank line (as shown in Sanitize Tank &...
  • Page 133 Section 8: Plumbing System 17. Water valves at the water pump should be in the NORMAL position to allow water into the RV lines. Disconnect any pressurized water source. Turn the water pump ON. You want water to flow from the water tank into the water lines in the RV. 18.

  • Page 134: Winterizing (With Utility Center)

    Section 8: Plumbing System 13. Refill the fresh water system with clean water. Use pressure fill or siphon fill method explained previously. Turn the water heater power ON only when the water heater is full of water. 14. To verify water heater is full, open hot water faucets, turn pump ON, and when water runs in a steady stream from the faucets, the water heater is full.

  • Page 135: Air Pressure Method

    Section 8: Plumbing System Air Pressure Method  If the recreation vehicle is going to be stored in a non-temperature controlled environment with a risk of temperatures reaching 32°F (0°C) or lower, the air pressure method is not adequate, winterizing with RV antifreeze must be used in the plumbing system.

  • Page 136: Winterizing With Antifreeze Method

    Section 8: Plumbing System Run the water pump until it is dry (approximately 15 to 20 seconds). Operating the pump longer than that with no water in it can damage the pump. Open all faucets in the RV. If there is an outside shower, attach the shower hose to the shower, and open the shower faucets (also outside kitchen if equipped).
  • Page 137 Section 8: Plumbing System Replace the water filter cartridge (if so equipped) with the plastic bypass hose. If RV has a canister water filter, turn off water to the filter (valves should be on either side of the filter). Remove the lid, remove the filter, replace the lid. Turn on the water valves.

  • Page 138: Nautilus P2.5 Uni-Dock Utility Center

    Section 8: Plumbing System De-winterize the macerator system: Emptying the black tanks in the spring will flush antifreeze out of the macerator system. When you are finished adding RV antifreeze Turn the water pump OFF. Remove the plastic hose from the container. Leave the black valve pointing to the clear hose.
  • Page 139 Section 8: Plumbing System The Uni-Doc Utility Center is located in an exterior compartment and allows you to per- form the following functions: Power fill the fresh water tank for remote or dry camping Use the pump to supply water to fixtures from the fresh water tank Use the pump to siphon fill or sanitize the fresh water tank from a bucket Connect to city water at the camp site to supply water to RV fixtures Winterize the plumbing lines and fixtures...
  • Page 140 Section 8: Plumbing System The following information details the functions of the utility center water valves as dis- played on the valve operation label. “POWER FILL TANK” (Pressurized fresh water source) Connect the fresh water hose to the City water connection inlet on the utility center. Set the color coded valves to POWER FILL TANK setting: Green handle pointing left Blue handle pointing down...
  • Page 141 Section 8: Plumbing System Connect other end of the hose to the pressurized fresh water source. Turn ON the pressurized water source. Water should now be available to all fixtures in the RV. To disconnect: Turn off water at the pressurized source first, disconnect hose from the water source, (to release pressure off the system) then disconnect the hose at the city water con- nection on utility center last.
  • Page 142 Section 8: Plumbing System Remove and bypass the water filter: Full System Canister water filter (if so equipped): Turn water valves off at the canister. Remove the canister lid, take the filter out of the canister, then replace the lid and turn the water valves back on. Bypass the cartridge water filter (if equipped): Use the clear plastic tube (supplied with RV) to bypass the water filter.
  • Page 143 Section 8: Plumbing System • Power to the water heater is OFF. Water filter has been bypassed or removed (depends on model). • • Sanitizer has been put into the tank. Water tank is full having been topped off with fresh water. •...
  • Page 144 Section 8: Plumbing System When the fresh water tank is full, set the valves to the DRY CAMP- ING setting. Turn the pump ON to send water through the lines. Run water through all faucets (hot and cold, including outside show- er and outside kitchen) until chlorine smell is gone.

  • Page 145: Winterizing The Plumbing System

    Section 8: Plumbing System Open faucets and check that the chlorine smell is gone. 10. Drain the system one more time. 11. Replace the water filter: Canister filter: Turn off water valves at the canister filter. Remove canister lid, put filter back into canister, and replace the canister lid.

  • Page 146: Winterize With Air Pressure

    Section 8: Plumbing System The preferred method to winterize your recreation vehicle is by using RV antifreeze in the plumbing system. It may be easier to winterize the RV with another person to assist you.  If the recreation vehicle is going to be stored in a non-temperature controlled environment with a risk of temperatures reaching 32°F (0°C) or lower, the plumbing system must be winterized with RV antifreeze.

  • Page 147: Winterize The Black Tank Flush

    Section 8: Plumbing System Your RV may have one of two types of filters: Full System Canister Filter: Remove the canister lid, take out the filter and then re- attach the lid on the empty canister. Cartridge Water Filter: Remove the cartridge filter and replace it with a bypass hose (supplied with your RV).

  • Page 148: Draining The Spray Port (If So Equipped)

    Section 8: Plumbing System NOTE: If the RV has a macerator system, you need to open the bypass valve for the macerator under the RV. This will allow the black tank to drain through the 4” sewer hose. Attach a garden hose to the TANK FLUSH inlet at the utility center. Attach the other end of the hose to a pressurized water source.
  • Page 149 Section 8: Plumbing System Level the RV and drain the fresh water plumbing system. Refer to Draining the Fresh Water System. Water heater should be empty after draining the plumbing system. The drain plug must be removed from the water heater (Fig 1). Water heater bypass valve should be set to NORMAL.
  • Page 150 Section 8: Plumbing System Contact your dealer if you require further assistance.  Water can accumulate in the flexible hose and dump connector of the macera- tor system. When winterizing the RV, antifreeze must be added to the macera- tor system. Winterize the Macerator system (if so equipped) Ensure all waste tanks are empty.

  • Page 151: Water Heater

    Section 8: Plumbing System Water Heater  Hydrogen gas may result if you have not used the water heater for two weeks or more. HYDROGEN GAS IS EXTREMELY FLAMMA- BLE. To reduce the risk of injury under these conditions, open the hot water faucet for several minutes at the kitchen sink before you use any electrical appliance connected to the hot water system.

  • Page 152: Anode Rod Replacement Chart

    Section 8: Plumbing System Turn the switch to the “ON” position. If the burner does not light, the system will automatically attempt two more tries for ignition before lock-out occurs. NOTE: Each ignition cycle will have a 15 second purge before spark cycle if the system is a three try system.
  • Page 153 Section 8: Plumbing System To prevent a water leak when replacing the anode rod, a pipe thread sealant approved for potable water (such as Teflon tape) must be applied to the threads of the anode rod. Proper application of a thread sealant will not interfere with the anode’s function. High altitude deration Operation of the water heater at high altitudes may require derating.
  • Page 154 Section 8: Plumbing System Maintenance Do not allow the burner to burn with a yellow flame, or continue to operate the water heater with an improper burner flame. Periodically, inspect the water heater vent for soot. Soot is a sign of incomplete combustion and must be corrected before operating the water heater.

  • Page 155: Outside Shower (If So Equipped)

    Section 8: Plumbing System Open hot water faucet to a medium water flow. It may take a few seconds for the water to travel from the water heater to the faucet. To reduce temperature: ○ Turn GMC dial “counter-clockwise”. ○ Increase hot water flow.

  • Page 156: Faucets

    Section 8: Plumbing System Turn ON the hot and cold faucet knobs, and adjust the water temperature as desired. To activate the handheld shower turn ON the sprayer head attachment (some models). To turn off the water, always close the hot/cold control (faucet) knobs. The lever on the shower head will not completely stop the flow of water;...

  • Page 157: Black/Grey Water System And Tanks

    Section 8: Plumbing System Black/Grey Water System and Tanks Water from the sinks and shower flows into the gray water (or waste water) holding tank. Water from the toilet will flow into the sewage (or black water) holding tank (see Black/Grey Water Holding Tanks).

  • Page 158: Black And Grey Tank Drains

    Section 8: Plumbing System GAWR or RV GVWR. Potential damage to suspension components, such as springs, tires and axles, could result. If you are dry camping and cannot immediately empty your holding tanks, reduce your ve- hicle speed until you reach a dumping station. When connected to the sewer drain line at a campground, keep the “black tank drain”...

  • Page 159: Macerator Pump System (If So Equipped)

    Section 8: Plumbing System Remove, clean and store the sewer hose. Close the sewer hose housing dust cap. You can locate many dump stations throughout the United States and Canada in Woodall’s, Rand McNally Camp Guide, Good Sam Camp Guide, KOA Kampgrounds Camp Guide and various other publications.
  • Page 160 Section 8: Plumbing System  Water can accumulate in the flexible hose and dump connector of the macera- tor system. When winterizing the RV, antifreeze must be added to the macera- tor system. Refer to the Winterizing section. Open the hose compartment and pull out the 1-1/2 inch flexible hose (which can extend to 21 feet) with the at- tached dump connector.

  • Page 161: Black Tank Flush (If So Equipped)

    Section 8: Plumbing System Open the desired black / gray (manual) drain valves, one at a time (black then gray). The macerator bypass valve will be pointing away from you and is attached to the macerator pump. The valve location is by design to prevent acciden- tally engaging the bypass when system is operating normally.

  • Page 162: Black Tank Flush (If So Equipped)

    Section 8: Plumbing System Black Tank Flush (if so equipped) The black tank flush (no fuss flush) inlet is typically located on the utility center panel labeled as “Tank Flush”. The loca- tion may vary depending on your model. Attach a garden hose (connected to a pressurized fresh water source) to the black tank flush inlet.

  • Page 163: Toilet (If So Equipped)

    Section 8: Plumbing System  In order for the 120VAC tank heaters to be in operation, the recreation vehicle MUST be hooked up to shore power or under generator power. If the recreation vehicle is not operating on shore power or generator power, only the +12VDC heaters will operate.

  • Page 164: Spray Port (If So Equipped)

    Section 8: Plumbing System  It is important to prevent solid waste buildup. Follow the toilet manu- facturer’s recommended instructions each time after emptying the black water holding tank. To prevent help toilet blockage, always use RV grade single-ply toilet pa- per.

  • Page 165: Air Conditioner

    Section 9: Heating & Cooling Air Conditioner The air conditioning system is controlled by a thermostat. Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.

  • Page 166: Ceiling Fan (If So Equipped)

    Section 9: Heating & Cooling NOTE: For RV models with touch screens, the powered roof vent(s) may be controlled on one of the selectable screens on the touch screen. Ceiling Fan (if so equipped)  Be careful to avoid placing any object in the path of the ceiling fan blades! Turn the ceiling fan ON/OFF using an interior wall switch.

  • Page 167: Fireplace (If So Equipped)

    Section 9: Heating & Cooling  The furnace should be inspected periodically (monthly during the heat- ing season) for presence of soot on the vent. Soot is formed whenever combustion is incomplete. This is a visual warning that the furnace is op- erating in an unsafe manner.
  • Page 168 Section 9: Heating & Cooling Notes:...

  • Page 169: Microwave

    Section 10: Appliances Microwave  To prevent damage, remove the turntable from the microwave when trav- eling. Make sure you are connected to a 120-volt power source.  Never use the microwave cavity for storage. The microwave cavity should always be empty when not in use. For details on operation, cleaning and safety information, refer to the manufacturer’s user guide.

  • Page 170: Cooktops: Range And Oven (If So Equipped)

    Section 10: Appliances Cooking with Propane (if so equipped) See the Propane System Section for important safety instructions. Refer to the manufactur- er’s owner’s manual for detailed operating and safety instructions for all propane appliances. Cooktops: Range and Oven (if so equipped) For detailed operating and safety information, refer to the manufacturer’s user guide.

  • Page 171: Gas Drop-In Cooktops (If So Equipped)

    Section 10: Appliances  Do not use aluminum foil on the electric range cooktop, as this material will damage the cooktop surface if it melts. Do not use aluminum foil under any circumstances on the electric range cooktop. Gas Drop-In Cooktops (if so equipped) Depending on your model, it may be equipped with either a 2 burner or 3 burner cooktop.

  • Page 172: Gas Bbq Grill (If So Equipped)

    Section 10: Appliances Gas BBQ Grill (if so equipped)  Be sure to read, understand and follow all information supplied with your recreation vehicle concerning the use of propane before operating the BBQ grill. The propane hose must be correctly connected before lighting the grill.

  • Page 173: Attaching The "Quick Coupler" Connection

    Section 10: Appliances Rail Mount (if so equipped) Hang the grill bracket on the aluminum mount- ing strip located on the side of the recreation vehicle. Open the (2) folding arms on the bracket mak- ing sure they lock in position. Slide the grill onto the (2) arms against the stops.

  • Page 174: Range Hood (If So Equipped)

    Section 10: Appliances Range Hood (if so equipped) If your recreational vehicle is equipped with a range hood, it will be connected to an exterior vent. The vent has an inner flap with two snaps. This flap can be snapped shut when the vehicle is in motion, or during storage to keep insects, debris, snow, rain, etc.

  • Page 175: Cleaning The Interior

    Section 10: Appliances  The ice maker (if so equipped) should be turned off and the ice tray emptied when power to your recreation vehicle has been shut off. With no power, the ice will melt and water may “pool” in the refrigerator door. When power is restored, the vibration may cause this water to run out of the door and on to the vehicle floor.

  • Page 176: Cleaning The Exterior

    Section 10: Appliances Remove the base grille. Use a vacuum cleaner with a soft brush to clean the grille, the open areas behind the grille and the front surface area of the condenser. Replace the base grille when finished. Cleaning the Exterior Painted metal exteriors: wash with a clean sponge or soft cloth and a mild detergent in warm water.

  • Page 177: Water Heater - See Plumbing Section Outside Kitchen (If So Equipped)

    Section 10: Appliances Central Vacuum System The following is an overview of the central vacuum system operation. For detailed operat- ing and safety instructions, refer to the manufacturer’s user guide. The central vacuum system installed cleans virtually any surface with no electric cords and has a variety of attachments for many cleaning needs.

  • Page 178: Quick Connect Coupler

    Section 10: Appliances Attaching the “quick coupler” connection The “quick coupler” is directly connected to the RV propane system. The “quick-coupler” connection has a positive shut-off valve as required by code and standards. Place the “quick coupler handle in the OFF position and push back the sleeve.
  • Page 179 Section 10: Appliances  The grill requires proper ventilation. It is designed for RV outdoor use only. NEVER put lava rocks or charcoal or anything else on or under the grate. Grill is designed so it does not require those items. Serious injury or property damage can occur by placing foreign objects on the grate.
  • Page 180 Section 10: Appliances Notes:...

  • Page 181: Winegard Air 360 Plus System (If So Equipped)

    Section 11: Electronics Winegard Air 360 Plus System (If So Equipped) The Winegard Air 360 Plus system is a fixed omnidi- rectional TV/FM antenna, plus Wi-Fi, and 4G extender. The antenna enclosure is 8 inches high and 17 inches in diameter.

  • Page 182: Opening The Router Box

    Section 11: Electronics A second antenna in the rooftop enclosure will also pick up any wireless Wi-Fi signals in the immediate area and distribute those signals through the ceiling mounted Winegard Gateway router box. Presently the system works with the following wireless providers: Winegard, Verizon, T- Mobile, and AT&T.
  • Page 183 Section 11: Electronics Replace the box back in the ceiling mounting plate and slide it towards the plastic lever and it should lock in place without pressing the tab. Bluetooth control: NOTE: You MUST turn the power switch (Fig 3) ON or there will be no cellular or Wi-Fi signals from the 4GLTE/Wi-Fi router box.
  • Page 184 Section 11: Electronics Winegard has two free apps that can be downloaded for Android or IPhone to help locate TV and Satellite signals: TV Signal Finder and HD Tower Finder. These apps will help you determine HDTV tower loca- tions and satellite dish pointing coordinates. It uses the device camera to help set the angle on your satellite dish or show you a graphic representation of the TV towers located in your area.

  • Page 185: Cleaning The Interior

    Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.

  • Page 186: Cabinetry And Tables

    Section 12: Interior Mini Blinds: A simple dry rag may do the trick. If they are especially dirty, you can use cold or warm water to clean them; never use hot water. Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat.

  • Page 187: Abs Plastics

    Section 12: Interior NOTE: Oil based soaps and cleaners are not recommended. No abrasive cleaners or alcohol cleansers should be used. If other cleaner solutions are used, we recommend trying a spot in an inconspicuous area. ABS Plastics Dust and wipe clean with soft, damp cloth or chamois, wiping gently. Do not use gritty or abrasive particle soaps or scouring compound to clean ABS plastic.

  • Page 188: Cube Sofa

    Section 12: Interior Cube Sofa The Cube Sofa functions similar to a residential futon. The slanted back pillows offer nu- merous options as a sofa, along with the ability to extend the cushions for additional sleeping space. Booth Dinette (if so equipped) The dinette is designed to seat up to four adults.

  • Page 189: Pantry Or Hutch (If So Equipped)

    Section 12: Interior Pantry or Hutch (if so equipped) Your recreation vehicle may have a pantry or hutch that you can use for storage. Make sure all items stored in the pantry or hutch are secured to prevent shifting during travel. This cabinetry has been designed to accommodate the normal camping items which may be bulky but not necessarily heavy.

  • Page 190: Flooring

    Section 12: Interior Run cold water when pouring hot/boiling water into the sink. Solid surface sink maintenance Occasionally, clean the solid surface sink by filling one-quarter full with a 50/50 water/ bleach solution. Let soak for 15 minutes, and then wash sides and bottom of sink as solu- tion drains.
  • Page 191 Section 12: Interior  The slide out must be fully extended before putting the Murphy bed in the sleeping position. The Murphy bed must be in the stored position before the slide out can be moved to the in (travel) position. Failure to do so may result in injury or property damage.
  • Page 192 Section 12: Interior  Snap hooks (if present) must be attached to the steel rings on the sofa arms before using the bed. Failure to attach these snap hooks to the steel loops on the sofa can result in serious injury or property damage. MAKE SURE THE SAFETY STRAPS AT EACH SIDE OF THE FOOTBOARD ARE ATTACHED TO THE STEEL LOOPS ON THE SOFA ARMS BEFORE PUT-...

  • Page 193: Bed Storage

    Section 12: Interior  Keep hands and fingers away from the collapsing footboard and struts when pushing the bed back in to the storage position. Secure the two “D” bolts on each side of the bed. Flip the sofa back up into the seated position: •...

  • Page 194: Loft Sleeping Area (If So Equipped)

    Section 12: Interior  Before lifting, be sure there is nothing on the bed that will restrict its movement or add extra weight. Use caution when opening or closing the bed to keep hands and fin- gers at the end ledge provided (not on the side or farther back than necessary).
  • Page 195 Section 12: Interior Bunk Beds (if so equipped) Your recreational vehicle may be equipped with bunk style beds. Bunk bed weight ratings will vary depending on the style of bunk bed. Refer to the warnings for bunk beds below. Bunk Bed Ladder (if so equipped) Your recreational vehicle may be equipped with a ladder to access the upper bunk.
  • Page 196 Section 12: Interior  Exercise extreme care when entering or exiting the bunk beds and using the ladder (if so equipped). Do not allow more than one person on the top bunk. Do not allow children under 6 years of age to use the upper bunk. Do not allow horseplay on or under the bed and prohibit jumping on the bed.

  • Page 197: Cleaning The Exterior

    Section 13: Exterior Cleaning the Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. For recreation vehicles with painted exterior graphics: If desired you may wash and wax your vehicle 60 days after purchase. The exterior paint does need time to cure before any wax is applied to the exterior surface.
  • Page 198 Section 13: Exterior Drying the recreation vehicle is just as important as washing your vehicle. Tap and well water contain many chemicals that could water stain your vehicle’s finish. We suggest using a damp natural or synthetic chamois. There are other drying products such as lint-free micro-fiber towels that work just as well.

  • Page 199: Frame

    Section 13: Exterior Polishing your recreation vehicle If painted surfaces have been severely damaged and have lost their original luster and color tone, polish the surface lightly with a fine polishing compound. Avoid limiting your polish- ing to the damaged surface only; polish a somewhat wider area, moving the polishing cloth in one direction.

  • Page 200: Exterior Roof And Sidewall Vents

    Section 13: Exterior Exterior Roof and Sidewall Vents Inspect the roof vents (including sealants) for cracks and keep them clean. Inspect the re- frigerator and holding tank vents for blockages from bird nests, spider webs, leaves, etc. All exterior access doors and vents need to be kept clean and free of obstructions (i.e., insect nests, mud daubers, etc.) while the appliances are in use.

  • Page 201: Sealants

    Section 13: Exterior  LADDER CAPACITY MAXIMUM 300 LBS (136 KG) DO NOT exceed the ladder maximum weight rating. The maximum rating includes the person’s weight PLUS weight of items carried. When climbing: ○ Always face the ladder. ○ Climb slowly with weight centered between side rails. ○...

  • Page 202: Fifth Wheels - Sealant Diagram

    Section 13: Exterior If you notice water inside the recreation vehicle, immediately have the dealer check for the source of the leak. Failure to correct the leak may result in serious damage to your recreation vehicle; this damage may not be warrantable. Although the following diagrams may not accurately reflect the exact model of your recre- ation vehicle, make sure you inspect all sealants as indicated in the text.

  • Page 203: Travel Checklist

    Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Safety Make sure you follow all safety precautions noted in this owner’s manual and in any manufacturer’s operators manual when preparing to travel.

  • Page 204: Rv Storage

    Section 14: Travel/Camping/Storage Checklists Before leaving the campsite Check the area under the RV after overnight parking and look for water or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks. Empty black and gray holding tanks, rinse as needed (if so equipped).
  • Page 205 Section 14: Travel/Camping/Storage Checklists Close the propane cylinder valve(s). We recommend using a propane cylinder cover, and to make sure the propane regulator is covered. If is equipped with a gas/ electric DSI range, light a range gas burner to consume any gas remaining in the lines.
  • Page 206 Section 14: Travel/Camping/Storage Checklists Notes:...

  • Page 207: Featured Components Quick Reference Chart

    Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice.
  • Page 208 Section 15: Additional Information Thermostat Coleman Mach www.airxcel.com/coleman-mach Toilet Thetford Corp. www.thetford.com See manufacturers’ user guide Winegard Company www.winegard.com TV Antenna King Jack www.kingconnect.com Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Girard Systems www.greenrvproducts.com Water Heater, Tankless Truma AquaGo www.truma.com Shurflo East www.shurflo.com Water Pump, 12V...

  • Page 209: Vehicle Maintenance Record

    Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Service Performed Mileage Work Performed Notes Date...

  • Page 210: Ownership Notification

    Section 15: Additional Information Jayco Ownership Notification Fax Form To: (800) 825-7876 ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ □...
  • Page 211 Section 15: Additional Information Notes:...
