TrailBlazer

Traverse HEX

Installation and Instruction Manual

For models from August 2017 onwards

Rugged Interactive

Unit 1, Callywith Court,

Callywith Industrial Estate,

Bodmin, Cornwall, UK

PL31 2RQ

+44 (0) 1726 981 123

www.rugged-interactive.co.uk

hello@rugged-interactive.co.uk

2019

Table of Contents

Need help?

Do you have a question about the TrailBlazer Traverse and is the answer not in the manual?

Questions and answers

Summary of Contents for Rugged Interactive TrailBlazer Traverse

Page 1 TrailBlazer ® Traverse HEX Installation and Instruction Manual For models from August 2017 onwards Rugged Interactive Unit 1, Callywith Court, Callywith Industrial Estate, Bodmin, Cornwall, UK PL31 2RQ +44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk © Rugged Interactive 2019...
Page 2: Table Of Contents
Section 1 – Safety Guidelines Section 2 – Installation Section 3 – Grip Installation and Removal Section 4 – How to Use Section 5 – Programs Guide TrailBlazer Traverse HEX System Specifications TrailBlazer Traverse HEX Installation Checklist © Rugged Interactive 2019...
Page 3: Section 1 - Safety Guidelines
Tidy back loose cables that could become a tripping hazard. ▪ Ensure that the playing area is clear. ▪ Immediately inform Rugged Interactive for maintenance advice if you have concerns. ▪ Don’ts: Do not wear shoes with leather soles or high heels.
Page 4 Section 1 – Safety Guidelines TrailBlazer Traverse HEX Installation and Instruction Manual: 1.2 In Play Safety Guidelines Please ensure you read the following points before using the equipment: Dos: Before beginning any exercise program, it is recommended that you consult with your doctor.
Page 5 Section 1 – Safety Guidelines TrailBlazer Traverse HEX Installation and Instruction Manual: Do not attempt to use any of the equipment without undertaking instruction / training carried out by ▪ an appropriate instructor. Do not participate if you are unwell or have any pre-existing medical conditions including heart, ▪...
Page 6: Section 2 - Installation
+44 (0) 1726 981 123 www.rugged-interactive.co.uk hello@rugged-interactive.co.uk Section 2 – Installation Read this manual before installing the TrailBlazer Traverse HEX climbing wall. Installation Guidelines: Please complete a Site Survey form prior to delivery and/or installation. ▪ Please send a completed Installation Checklist after any installation to Rugged Interactive.
Page 7 A waiting / spectating area positioned nearby is advised. ▪ A leaderboard to go with each unit is highly recommended. ▪ IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON +44 (0) 1726 833 882 Section 2 © Rugged Interactive 2019...
Page 8 Section 2 – Installation TrailBlazer Traverse HEX Installation and Instruction Manual: Installation Instructions 1. Interlock bottom mouldings 1B and 2B as close to 120° as possible. Sections are labelled in the bottom left-hand corner of the graphics panel. Insert a plastic tube without the aluminium top through the holes in the corner piece to connect mouldings.
Page 9 Section 2 – Installation TrailBlazer Traverse HEX Installation and Instruction Manual: 4. Ensure mouldings are level and square to one another. Ensure that any loose cables are not trapped between the mouldings. 5. One person to get into the middle of the TrailBlazer HEX via the remaining opening. I.e. step over moulding 1B.
Page 10 Section 2 – Installation TrailBlazer Traverse HEX Installation and Instruction Manual: 10. Use a stepladder to view the top of one corner piece. Position a top jointing plate on top of the corner piece and secure. (See Figure 2.5.) Repeat for each corner.
Page 11: Section 3 - Grip Installation And Removal
Retain all screws & washers. NOTES: Ensure CAT5 cable is not strained or trapped. Do not overtighten grip screws. Power on the TrailBlazer Climbing wall and check operation. Removing the Grips Section 3 © Rugged Interactive 2019...
Page 12: Section 4 - How To Use
On power up, the TrailBlazer will sound a ‘laugh’ and will turn to its idle state. Initially the dot matrix will display the Hub Software Version Number for the TrailBlazer. The TrailBlazer Traverse Climb has four programs: 1. Cascade – 3 minutes 2.
Page 13 Section 4 – How to Use TrailBlazer Traverse HEX Installation and Instruction Manual: TrailBlazer Traverse Trampoline The TrailBlazer Traverse Trampoline has two programs: 1. Cascade – 1 minute 2. Chaser X4 – 1 minute red pods shown in Figure 4.2 are QuickStart programs. Hit a QuickStart button to start the program.
Page 14: Section 5 - Programs Guide
+1 point for each pod hit Duration: 2 minutes NOTE: At any time, if the CardioWall behaves unexpectedly during gameplay, wait for at least 30 seconds of inactivity for the unit to reset to its idle state. Section 5 © Rugged Interactive 2019...
Page 15 Section 5 – Programs Guide TrailBlazer Traverse HEX Installation and Instruction Manual: Cascade Summary: A high intensity challenge of speed and visual awareness. Ideal for developing and challenging physical coordination, hand-eye coordination, core stability and reaction time and speed. A fast and high scoring game.
Page 16 Section 5 – Programs Guide TrailBlazer Traverse HEX Installation and Instruction Manual: Chaser X4 Summary: A pure speed and reaction challenge which also tests peripheral vision and spatial awareness. A mental and physical test, encouraging competition, cooperation and social interaction. A game that requires accuracy, problem solving and patience to reach a high score.
Page 17 Section 5 – Programs Guide TrailBlazer Traverse HEX Installation and Instruction Manual: Free Play Summary: An unlimited game of Cascade, allowing children to play without any timeouts. A high intensity challenge of speed and visual awareness. Ideal for social interaction and teamwork.
Page 18: Trailblazer Traverse Hex System Specifications
Regulatory Requirements: CE Approved. Operating Environment: Indoors: keep dry and out of direct sunlight. Area required clear in front of the TrailBlazer Traverse: depth of 1 m minimum. Optimum ambient temperature: 5°C to 30°C. Avoid extreme fluctuations of temperature. Other: All parts designed for easy maintenance.
Page 19 TrailBlazer Traverse HEX Installation and Instruction Manual 1090 Figure 1: Mounting Points (Dimensions in mm) Figure 2: Panel Orientations TrailBlazer Traverse HEX System Specifications © Rugged Interactive 2019...
Page 20 TrailBlazer Traverse HEX Installation and Instruction Manual 1100 R 170 120 2540 2245 Figure 3: Hex Footprint TrailBlazer Traverse HEX System Specifications © Rugged Interactive 2019...
Page 21: Trailblazer Traverse Hex Installation Checklist
Check 2: Plug into a mains socket and power up. ☐ All pods light up. ☐ Text appears on the hub display and is as expected. E.g. TrailBlazer Traverse. ☐ Sound volume is at a suitable level*. Check 3: Select Cascade via Quick Start.
Page 22 ☐ Instruction / training carried out by an appropriate instructor to all new users. If anything unexpected occurs or problems persist after troubleshooting, call Rugged Interactive directly on +44 (0) 1726 833 882. * The volume can be adjusted on the main hub. The volume control (a small blue control) can be seen through the score window on the bottom left of the PCB.
