IMPORTANT: placing fixed panels on the top of the cabinet is advised against, as this
part must be accessible for servicing purposes.

5. ELECTRICAL CONNECTION

IMPORTANT: ahead of the case there must be a MEANS FOR DISCONNECTION FROM
THE SUPPLY MAINS HAVING A CONTACT SEPARATION IN ALL POLES THAT PROVIDE
FULL DISCONNECTION UNDER OVERVOLTAGE CATEGORY III CONDITIONS (see fig.
17). The position of the cut-out switch must enable its actuation in any emergency
situation (maximum distance 3 m). Show the position of the cut-out switch to any pro-
spective operator.
The refrigerator must be installed by professionally qualified personnel, in accordance
with the instructions provided by the manufacturer and local regulations. Incorrect in-
stallation may cause harm to persons, animals and property. The manufacturer assu-
mes no responsibility for such damage.
A supply cable of type HO5VV-F 1mm² or higher must be used for the main supply.
Make sure that the system power supply voltage corresponds to the values appearing
on the rating plate of the equipment. Consider also that the maximum allowable power
voltage variation is +/-6%.
BEFORE CONNECTION, CHECK THAT THE POWER SOURCE IMPEDANCE IS EQUAL TO
OR LOWER THAN 0,383 OHM.
IMPORTANT: THE EQUIPMENT MUST BE PROPERLY EARTHED. The manufacturer as-
sumes no responsibility for any damage resulting from non-observance of this safety
principle. If the cabinet must be installed far from electric power source, make certain
that the connection complies with the standards in force.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
THE MANUFACTURER DISCLAIMS ALL RESPONSIBILITY FOR ANY PERSONAL INJURY
OR PROPERTY DAMAGE ARISING FROM INCORRECT INSTALLATION.
6. TECHNICAL SPECIFICATIONS
The built-in electrical installation is composed of control devices lodged in the lower part
of the refrigerated cabinet. The technical details, which are also reported on the rating
plate, inside the display case (see fig. 8 on page 13) are shown in table III, page 13.
A-weighted sound pressure level is less than 70 dB (A). This refrigerated cabinet gene-
rates no harmful vibrations.
