- Page 1 PRODUCT GUIDE & ASSEMBLY INSTRUCTIONS Executive Chair So comfortable, you’ll feel the difference the moment you sit down.
- Page 2 Should you prefer to speak with a customer service representative, you may call toll free: 1-855-372-2315...
- Page 3 Guidelines FAILURE TO FOLLOW THESE WARNINGS WHEN IN USE COULD RESULT IN INJURY Do not stand on the item or use as a step ladder • Do not use this item unless all bolts and screws are • firmly secured and fastened. Check all bolts and screws every 90 days.
- Page 4 WARNING: DO NOT LET CHILDREN PLAY IN OR AROUND THE UNIT DUE TO THE POSSIBLE RISK OF INJURY. Pre-Assembly Preparation: Please read through this instruction booklet before beginning assembly of this item. Two adults are recommended for assembly. Clear out the space for assembly and lay out all •...
-
Page 5: Parts List
Parts List Casters (5) Star Base (1) Gas Lift with Seat Plate (1) Telescoping Cover (1) Arms (2) Seat Cushion (1) Back Cushion (1) 7/8” Screws (2) - Page 6 Parts List 1-5/8” Screws (2) 1-1/4” Screws (4) 2-1/2” Screws with Black Plastic Caps (4) Spring Washers (4) Allen Key (1)
- Page 7 Step 1 Select a smooth surface to avoid scratching the parts. Turn the Star Base (B) upside down. Press the Casters (A) into holes at the end of each leg. Turn the Star Base (B) upright and insert Gas Lift with Telescoping Cover (C) into the central hole of Star Base (B).
- Page 8 Step 2 Attach Seat Plate (D) to the bottom of the Seat Cushion (F) (with the front of the seat plate facing the front of seat cushion). Attach by using 1-5/8” Screws (I) for the front holes of the Seat Plate (D) and 7/8”...
- Page 9 Step 3 Align Back Cushion (G) with Seat Cushion (F) by positioning the back support plate over the Seat Plate (D) with 1-1/4” Screws (J). *Note: Do not tighten the screws completely.
- Page 10 Step 4 Insert 2-1/2” Screws with Spring Washers (K) into arm holes, attaching Arms (E) to sides of Seat Cushion (F) and Back Cushion (G) with the Allen Key (M). *Note: Tighten the screws completely. Remember to tighten the back bar screws also.
- Page 11 Step 5 Position the assembled chair upright with the seat plate facing down. Insert the Gas Lift with Telescoping Cover (C) into the center hole of the Seat Plate (D).
- Page 12 Step 6 Place the Black Plastic Caps (L) into arm holes once screws have been tightened. The chair is now ready for use.
- Page 13 Operating Instructions Function Instruction - 1 To Adjust Seat Height: While seated, lean forward and reach under the right side of the chair to find the handle. Lift the handle and raise your body up slightly to allow the chair to rise to the desired height.
- Page 14 Operating Instructions Function Instruction - 2 To Operate Tilt Lockout: While seated, reach under the left side of the chair to find the handle. When the handle is placed in the level position, leaning back to allow the chair to tilt backwards. Push down the handle to lock the chair angle while the desired position is reached.
- Page 15 Operating Instructions Function Instruction - 3 To Adjust Tension On The Tilt: Reach under the front center of the chair, grasp the round knob (R) and turn it counter - clockwise to stiffen the tilt mechanism for a heavier user. Turn the knob (R) clockwise to loosen the tilt mechanism for a lighter user.
-
Page 16: Limited Warranty
Limited Warranty The manufacturers products are warrantied against defects in material and workmanship while owned by the “Original Purchaser”. The term “Original Purchaser” is defined as the party or entity which purchases this manufacturer’s furniture from an authorized retailer as shown by the original sales receipt. This warranty does not apply to “as is” or previously owned products.
