Ingics iGS03W User Manual

Beacon gateway
Hide thumbs Also See for iGS03W:
Table of Contents

Advertisement

Quick Links

Download this manual
INGICS​






Guide
Ver.01a
iGS03W/E/M is a gateway to bridge the local BLE( Bluetooth® Low Energy) tags,
sensors, or beacons to remote server/cloud by WiFi, Ethernet or LTE-M. Through an
easy web UI interface, user can configure the Internet access to upload reports to
cloud server by TCP, HTTP(S), or MQTT(S). This guide is to help the user to figure out
how to operate and configure the iGS03.

Contents:
Overview
Block Diagram
SIM
WiFi
Ethernet
BLE
GNSS
Example case 1: The device is in fixed position:
Example case 2: The device is moving:
Payload Format
BLE
GPS
Button
Reset to Default
WPS
LEDs
Configuration
Web User Interface
System
Wi-Fi
AP Mode
Station Mode
Network
WiFi Address
DHCP Server (WiFi AP)
Applications
TCP Server

​
​
I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM

​
T ECHNOLOGY
Beacon Gateway
iGS03W/E/M User

Manual

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iGS03W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ingics iGS03W

Summary of Contents for Ingics iGS03W

  • Page 1 Manual    iGS03W/E/M is a gateway to bridge the local BLE( Bluetooth® Low Energy) tags,  sensors, or beacons to remote server/cloud by WiFi, Ethernet or LTE-M. Through an  easy web UI interface, user can configure the Internet access to upload reports to ...
  • Page 2 APN  Auth  Username/Password  GNSS Settings  NTP Setting  Certification  Bluetooth SIG Qualification  Japan MIC Reaulatory  FCC Regulatory  FCC Statements  CE Regulatory  Revision History            ​ ​ 2  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...

  • Page 3: Block Diagram

    TCP, HTTP or MQTT server. Users can configure the transmit period  and server endpoint through a simple web UI. There are three models, iGS03W, iGS03E and iGS03M,  representing different uploading interfaces, WiFi, Ethernet and LTE-M. ...
  • Page 4 Step 2. Remove the screw from bottom cover      Step 3. Use finger to press and hold the arrow  Step 4. Pull out the bottom cover  part        ​ ​ 4  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
  • Page 5 GNSS FIXCOUNT Number of attempts for positioning, 0 indicates continuous positioning.  default 0  GNSS FIXRATE The interval time between the first and second time positioning, default 1 (1  second)    ​ ​ 5  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...

  • Page 6: Payload Format

    Different report type to distinguish the source of the report.   <tag id>  MAC address or ID of tag/beacon  <gateway id>  MAC address of gateway  <rssi>  RSSI of tag/beacon    ​ ​ 6  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
  • Page 7 One button is located on the back panel. It is used for WPS function or Reset to default settings.    Function  Trigger Condition  WPS (iGS03W/M)  short press for over 1sec and release  Reset to default settings  long press for over 3 sec    ​ ​ 7  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...

  • Page 8: Reset To Default

    WPS  Users can use the WPS button to join iGS03W/M to the WiFi Access Point. First press the WPS  button on your Access Point, when it is ready, then press the WPS button for over 1 sec on the iGS03M ...
  • Page 9 After connection, enter IP address ​ 1 92.168.10.1​ in your browser. The default account/password  are both “​ a dmin​ ” . The following sections describe details of the web UI.            ​ ​ 9  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...

  • Page 10: Web User Interface

    Channel: ​ 1 ~11(ch12 and ch13 could be supported by request)   Station Mode  This mode is used for transferring  data by *WiFi.  Scan:​ Click it to scan available APs.    ​ ​ 10  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
  • Page 11 IP and Netmask here. The  corresponding DHCP client address  will be changed too. For example, if  the DHCP server IP address is  changed to 192.168.0.1., the DHCP    ​ ​ 11  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
  • Page 12 Users can simply use https:// in URL to enable HTTPS. And users can also enable Server  Root CA/User Client Certificate based on the server requirement. The certificate files can  be uploaded on the Security page.        ​ ​ 12  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
  • Page 13 Certificate based on the server requirement. For example, to enable AWS-IOT, the user has  to enable MQTTS/ROOT CA/ Use Certificate options and upload certificate and private key  in the security page.        ​ ​ 13  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...

  • Page 14: Common Settings

    If throttle control is enabled, iGS03 will keep the last record for each TAG/Beacon ID in the  given interval (request interval). In this way, one can reduce the data transmission to the  server.    ​ ​ 14  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
  • Page 15 The character ‘X’ in pattern  means ignore the character. Also you  can click the “magic wand” to select a  preset pattern for iBeacon, Eddystone,  or INGICS beacons.    ​ ​ 15  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
  • Page 16 Authentication  The auth type based on the carrier  setting.  Username/Password  The username/password based on the  carrier setting.  DNS Servers  In case the users want to specify    ​ ​ 16  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...

  • Page 17: Gnss Settings

    One can change the login password from the  “people” icon on the UI header. Be aware that  it changes the login password of the telnet  console, too.          ​ ​ 17  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...

  • Page 18: Fcc Statements

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:  (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including  interference that may cause undesired operation      ​ ​ 18  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
  • Page 19 ​   INGICS​ T ECHNOLOGY CE Regulatory  iGS03W/M has been tested and complies with the essential requirements of the DIRECTIVE  2014/53/EU and DIRECTIVE 2014/35/EU. Below is the copy of CE Conformity of Declaration.      ​ ​ 19  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
  • Page 20 ​   INGICS​ T ECHNOLOGY           ​ ​ 20  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...

  • Page 21: Revision History

    2. Add the method of opening the lower cover   3. Modify Button section to make it more clear  4. Update insert SIM card location photo      ​ ​ 21  I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM   ...
