iGS03W/M is a gateway to bridge the local BLE( Bluetooth® Low Energy) tags,
sensors, or beacons to remote server/cloud by WiFi, or LTE-M. Through an easy web
UI interface, user can configure the Internet access to upload reports to cloud server
by TCP, HTTP(S), or MQTT(S). This guide is to help the user to figure out how to
operate and configure the iGS03.
Contents:
Overview
Block Diagram
SIM
WiFi
BLE
GNSS
Example case 1: The device is in fixed position:
Example case 2: The device is moving:
Payload Format
BLE
GPS
Button
Reset to Default
WPS
LEDs
Configuration
Web User Interface
System
Wi-Fi
AP Mode
Station Mode
Network
WiFi Address
DHCP Server (WiFi AP)
Applications
TCP Server
TCP Client
HTTP Client
HTTPS
MQTT Client
I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM
T ECHNOLOGY
iGS03W/M User Manual
Beacon Gateway
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ingics iGS03W
Summary of Contents for Ingics iGS03W
- Page 1 Ver.01a iGS03W/M is a gateway to bridge the local BLE( Bluetooth® Low Energy) tags, sensors, or beacons to remote server/cloud by WiFi, or LTE-M. Through an easy web UI interface, user can configure the Internet access to upload reports to cloud server ...
- Page 2 APN Auth Username/Password GNSS Settings NTP Setting Certification Bluetooth SIG Qualification Japan MIC Reaulatory FCC Regulatory FCC Statements CE Regulatory Revision History 2 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
-
Page 3: Block Diagram
The iGS03 BLE gateway scans beacons(like iBeacon or Eddystone), proprietary tags, or BLE sensors then sends the payload to TCP, HTTP or MQTT server. Users can configure the transmit period and server endpoint through a simple web UI. There are two models, iGS03W and iGS03M, representing different uploading interfaces, WiFi and LTE-M. ... - Page 4 BLE modes LE 1M PHY: including BLE4.2(Legacy)/BLE5, 1M in 100% duty cycle LE Coded PHY: BLE5, 125K( long range) in 100% duty cycle 4 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
- Page 5 Then GNSS will be enabled and continuously get position with 1 second interval, and it will send a GPSR report every 60 sec. You can also use the "GNSS INFO" command to get the latest coordinates. 5 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
-
Page 6: Payload Format
● "$GPSR,<tag_mac>,<reader_mac>,<rssi>" fields are for compatibility with other reports. The tag_mac is always the same as reader_mac and the rssi is always -127. ● yymmdd,hhmmss.ss is the UTC time when the position is acquired. 6 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ... -
Page 7: Reset To Default
Access Point, when it is ready, then press the WPS button for over 1 sec on the iGS03M device to join the Access Point. 7 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ... - Page 8 To configure the unit, you have to connect it through the WiFi interface. When it is powered on, you could scan its native AP and connect it with the WiFi of your NB/PC/Mac/Tablet/Smartphone. It’s 8 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
-
Page 9: Web User Interface
WPA-PSK/WPA2-PSK are supported. WPA2-PSK is recommended. Password: 8 -63 characters can be input Channel: 1 ~11(ch12 and ch13 could be supported by request) 9 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ... - Page 10 IP” to to assign the IP Address, Netmask, Gateway, and/or DNS servers. DHCP Server (WiFi AP) The default IP address of iGS03 in WiFi AP mode is 192.168.10.1 and the netmask is 10 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
- Page 11 The others may need extra header and value. Users can simply use https:// in URL to enable HTTPS. And users can also enable Server 11 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
- Page 12 Certificate based on the server requirement. For example, to enable AWS-IOT, the user has to enable MQTTS/ROOT CA/ Use Certificate options and upload certificate and private key in the security page. 12 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
-
Page 13: Common Settings
If throttle control is enabled, iGS03 will keep the last record for each TAG/Beacon ID in the given interval (request interval). In this way, one can reduce the data transmission to the server. 13 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ... - Page 14 The character ‘X’ in pattern means ignore the character. Also you can click the “magic wand” to select a preset pattern for iBeacon, Eddystone, or INGICS beacons. 14 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
- Page 15 Authentication The auth type based on the carrier setting. Username/Password The username/password based on the carrier setting. DNS Servers In case the users want to specify 15 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
-
Page 16: Ntp Setting
One can change the login password from the “people” icon on the UI header. Be aware that it changes the login password of the telnet console, too. 16 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ... -
Page 17: Fcc Statements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation 17 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ... - Page 18 INGICS T ECHNOLOGY CE Regulatory iGS03W/M has been tested and complies with the essential requirements of the DIRECTIVE 2014/53/EU and DIRECTIVE 2014/35/EU. Below is the copy of CE Conformity of Declaration. 18 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
- Page 19 INGICS T ECHNOLOGY 19 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
-
Page 20: Revision History
2. Add the method of opening the lower cover 3. Modify Button section to make it more clear 4. Update insert SIM card location photo 20 I NGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM ...
