Ingics iGS03W User Manual

Beacon gateway
Hide thumbs Also See for iGS03W:
Table of Contents

Advertisement

Quick Links

INGICS
Guide
Ver.01a
iGS03W/E/M is a gateway to bridge the local BLE( Bluetooth® Low Energy) tags,
sensors, or beacons to remote server/cloud by WiFi, Ethernet or LTE-M. Through an
easy web UI interface, user can configure the Internet access to upload reports to
cloud server by TCP, HTTP(S), or MQTT(S). This guide is to help the user to figure out
how to operate and configure the iGS03.
Contents:
Overview
Block Diagram
SIM
WiFi
Ethernet
BLE
GNSS
Example case 1: The device is in fixed position:
Example case 2: The device is moving:
Payload Format
BLE
GPS
Button
Reset to Default
WPS
LEDs
Configuration
Web User Interface
System
Wi-Fi
AP Mode
Station Mode
Network
WiFi Address
DHCP Server (WiFi AP)
Applications
TCP Server
INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM
TECHNOLOGY
Beacon Gateway
iGS03W/E/M User
Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iGS03W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ingics iGS03W

Summary of Contents for Ingics iGS03W

  • Page 1 Ver.01a Manual iGS03W/E/M is a gateway to bridge the local BLE( Bluetooth® Low Energy) tags, sensors, or beacons to remote server/cloud by WiFi, Ethernet or LTE-M. Through an easy web UI interface, user can configure the Internet access to upload reports to cloud server by TCP, HTTP(S), or MQTT(S).
  • Page 2 Payload Whitelist BLE MAC Whitelist Security Device Key/Certification/Server CA Upload LET Settings Auth Username/Password GNSS Settings NTP Setting Certification Bluetooth SIG Qualification Japan MIC Reaulatory FCC Regulatory FCC Statements CE Regulatory Revision History INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 3: Block Diagram

    TCP, HTTP or MQTT server. Users can configure the transmit period and server endpoint through a simple web UI. There are three models, iGS03W, iGS03E and iGS03M, representing different uploading interfaces, WiFi, Ethernet and LTE-M.
  • Page 4 Step 1. Remove external BLE antenna Step 2. Remove the screw from bottom cover Step 3. Use finger to press and hold the arrow Step 4. Pull out the bottom cover part INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
  • Page 5 The interval time between the first and second time positioning, default 1 (1 second) GNSS RPTRATE The interval time for sending GPSR report, default 600 (10 minutes) GNSS INFO To get latest GPS status Example case 1: The device is in fixed position: e.g. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 6: Payload Format

    MAC address of gateway <rssi> RSSI of tag/beacon <raw packet content> Raw packet received by the gateway <unix epoch timestamp> Optional timestamp configured in applications page Report Type: $GPRP BLE4.2 General Purpose Report INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
  • Page 7 One button is located on the back panel. It is used for WPS function or Reset to default settings. Function Trigger Condition WPS (iGS03W/M) short press for over 1sec and release Reset to default settings long press for over 3 sec INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 8: Reset To Default

    Users can use the WPS button to join iGS03W/M to the WiFi Access Point. First press the WPS button on your Access Point, when it is ready, then press the WPS button for over 1 sec on the iGS03M device to join the Access Point.
  • Page 9 If you don’t know the IP address, you may need to use some tool to find it.(For example, “Fing” APP in Android & iOS. Join your smartphone or tablet with “Fing” in the same network. And use it to scan all the devices in this network) INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 10: Web User Interface

    Password: 8-63 characters can be input Channel: 1~11(ch12 and ch13 could be supported by request) Station Mode This mode is used for transferring data by *WiFi. Scan: Click it to scan available APs. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
  • Page 11 255.255.255.0. In case the user wants to change the IP address in AP mode, just set the IP and Netmask here. The corresponding DHCP client address will be changed too. For example, if the DHCP server IP address is changed to 192.168.0.1., the DHCP INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 12: Tcp Server

    Users can simply use https:// in URL to enable HTTPS. And users can also enable Server Root CA/User Client Certificate based on the server requirement. The certificate files can be uploaded on the Security page. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
  • Page 13 Users can enable MQTTS support. And also can enable Server Root CA/Use Client Certificate based on the server requirement. For example, to enable AWS-IOT, the user has to enable MQTTS/ROOT CA/ Use Certificate options and upload certificate and private key in the security page. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 14: Common Settings

    If throttle control is enabled, iGS03 will keep the last record for each TAG/Beacon ID in the given interval (request interval). In this way, one can reduce the data transmission to the server. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
  • Page 15 Click on the “plus” button to add a new pattern. The character ‘X’ in pattern means ignore the character. Also you can click the “magic wand” to select a preset pattern for iBeacon, Eddystone, or INGICS beacons. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
  • Page 16 The APN setting for the carrier setting. Authentication The auth type based on the carrier setting. Username/Password The username/password based on the carrier setting. DNS Servers In case the users want to specify INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 17: Gnss Settings

    NTP. Login Password One can change the login password from the “people” icon on the UI header. Be aware that it changes the login password of the telnet console, too. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 18: Fcc Regulatory

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
  • Page 19 INGICS TECHNOLOGY CE Regulatory iGS03W/M has been tested and complies with the essential requirements of the DIRECTIVE 2014/53/EU and DIRECTIVE 2014/35/EU. Below is the copy of CE Conformity of Declaration. INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
  • Page 20 INGICS TECHNOLOGY INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...

  • Page 21: Revision History

    1. Add FCC/CE regulatory information and FCC statement 2. Add the method of opening the lower cover 3. Modify Button section to make it more clear 4. Update insert SIM card location photo INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM...
