8.6 Evaporator and temperature sensing system
Evaporator in freezing chamber
Evaporator in freezing chamber
Components on the evaporator
Defrost thermostat
Fuse
Defrost sensor
Defrost heater
Evaporator in refrigerating chamber
Evaporator in refrigerating chamber
1）Take down screws and gaskets on the evaporator..
2）Remove the welding on inlet and outlet tubes.
Components on the evaporator
Defrost sensor(不可拆 Not replace)
1）The defrost sensor is located on back of the
evaporator..
Sensor
Sensor in freezing chamber
Service Manual_2018-V1.0
