Getting Started; Cable Connection - Elatec TWN4 Palon Compact LEGIC Integration Manual

Elatec GmbH
1. Introduction
The transponder reader TWN4 Palon Compact LEGIC is a device for
reading and writing RFID transponders. There are different versions of
TWN4 devices available, which cover a large range of transponder types
both in the frequency range of 125 kHz and 13.56 MHz.

2. Getting Started

2.1 Cable Connection

In order to start operating a TWN4 Palon Compact LEGIC transponder
reader, it simply has to be connected to a host.
2.2 Power Up
Once a TWN4 Palon Compact LEGIC reader is connected to the host, it
detects the type of communications cable (USB or RS232), with which it is
connected to the host.
Additionally, the RS232 is sending a version string via RS232 to the host.
