- Page 1 ARC-1532-C1 15" 6th Gen Intel® Core™ BGA Processor i7/i5/i3 Fanless Rugged Touch Panel PC with IET Expansion Quick Reference Guide Ed – 10 April 2019 Copyright Notice Part No. E2017A520A0R...
-
Page 2: Table Of Contents
1.4 System Overview ....................11 1.4.1 I/O View ..........................11 1.5 System Dimensions ....................12 Hardware Configuration ..................13 2.1 ARC-1532-C1 connector mapping ................14 2.1.1 Serial port 1 connector (COM1) ..................... 14 2.1.2 Serial port 2 connector (COM2) ..................... 14 2.2 Installing Hard Disk &... - Page 3 3.1 Introduction ......................42 3.2 Starting Setup ......................42 3.3 Using Setup ......................43 3.4 Getting Help ......................44 3.5 In Case of Problems ....................44 3.6 BIOS setup ......................45 3.6.1 Main Menu ..........................45 ARC-1532-C1 Quick Reference Guide...
- Page 4 3.6.3.2.2 USB Configuration ......................67 3.6.3.2.3 HD Audio Configuration ....................67 3.6.4 Security ..........................68 3.6.4.1 Secure Boot menu ......................69 3.6.4.1.1 Key Management ......................70 3.6.5 Boot ............................70 3.6.6 Save and exit ........................71 4 ARC-1532-C1 Quick Reference Guide...
- Page 5 Quick Reference Guide 3.6.6.1 Save Changes and Reset ....................72 3.6.6.2 Discard Changes and Reset ..................... 72 3.6.6.3 Restore Defaults ........................ 72 3.6.6.4 Launch EFI Shell from filesystem device ................72 ARC-1532-C1 Quick Reference Guide...
-
Page 6: Getting Started
1.2 Packing List 1 x ARC-1532-C1 1 x Driver/Utility DVD-ROM 1 x Power Adapter 4 x screws for VESA 6 ARC-1532-C1 Quick Reference Guide... -
Page 7: System Specifications
HDD LED, Power LED (Green for Power, Yellow for HDD) 2* mini PCIe full size (support half size) Expansion Slots 1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe ARC-1532-C1 Quick Reference Guide... - Page 8 EMI Test CE/ FCC class B Dust and Rain Test Front Panel IP65, Rear IP41 except I/O Random Vibration Operation: 1. PSD: 0.03622G²/Hz , 2.0 Grms Vibration Test 2. operation mode 3. Test Frequency : 5-500Hz 8 ARC-1532-C1 Quick Reference Guide...
- Page 9 Operating Humidity 0 ~ 90% Relative Humidity, Non-condensing Storage Temperature -20 ~ 60 degree Compliant with following Flexible Expansion Modules ARC-BYT DB-A 4 x USB3.0 module ARC-BYT DB-B 3 x Audio Jack (Line in/Line out/Mic in)+HDMI ARC-1532-C1 Quick Reference Guide...
- Page 10 2 x COM Isolation module ARC-BYT DB-G 3 x COM (w/o isolation, RS-232 only) ARC-BYT DB-H 2COM (RS-232) + 1USB 2.0 ARC-BYT DB-K 2COM (RS-232) + 1LAN Note: Specifications are subject to change without notice. 10 ARC-1532-C1 Quick Reference Guide...
-
Page 11: System Overview
Label Function Note DC Power-in connector DC IN COM1/2 Serial port 1/2 connector DB-9 male connector 4 x USB 3.0 connector LAN1/2 RJ-45 Ethernet 1/2 HDD indicator System power indicator Power Switch Power on button ARC-1532-C1 Quick Reference Guide 11... -
Page 12: System Dimensions
ARC-1532-C1 1.5 System Dimensions (Unit: mm) 12 ARC-1532-C1 Quick Reference Guide... -
Page 13: Hardware Configuration
Quick Reference Guide 2. Hardware Configuration For advanced information, please refer to: 1- ARC-SKLU, ARC-BYT DB-A/B/C/D/G/H/K included in this manual. ARC-1532-C1 Quick Reference Guide 13... -
Page 14: Arc-1532-C1 Connector Mapping
PIN PIN Signal TxD- TxD+ Please set BIOS & JCOM2_SEL2 RxD+ RxD- Please set BIOS & JCOM2_SEL2 2.1.2 Serial port 2 connector (COM2) Signal PIN PIN Signal NDCDB# NDSRB# NRXDB NRTSB# NTXDB NCTSB# NDTRB# NRIB# 14 ARC-1532-C1 Quick Reference Guide... -
Page 15: Installing Hard Disk & Memory
Memory Installation: Remove 3 screws to release the chassis cover, and remove it. Step 2.1 Insert the SODIMM into the memory socket. Step 2.2 Re-assemble your system back through previous steps to complete the installation. ARC-1532-C1 Quick Reference Guide 15... - Page 16 ARC-1532-C1 Step 3. HDD Installation: Insert the HDD into the Drive Bay and fasten 2 screws. 16 ARC-1532-C1 Quick Reference Guide...
-
Page 17: Installing Arc-Byt Db
Quick Reference Guide 2.3 Installing ARC-BYT DB Step 1. Unfasten 2 screws of the HDD bracket and take it off. Step 2. Remove 4 screws to release the chassis cover, and remove it. ARC-1532-C1 Quick Reference Guide 17... - Page 18 ARC-1532-C1 Step 2.1 Insert the ARC-BYT DB into the socket and fasten 3 screws. Step 2.2 Re-assemble your system back through previous steps to complete the installation 18 ARC-1532-C1 Quick Reference Guide...
-
Page 19: Arc-Sklu Overviews
Quick Reference Guide 2.4 ARC-SKLU Overviews ARC-1532-C1 Quick Reference Guide 19... -
Page 20: Arc-Sklu Jumper And Connector List
JPWR1 JSPI1 SPI connector 4 x 2 header, pitch 2.00mm EC Debug connector 2 x 1 header, pitch 2.00 mm JEC1 SATA1 Serial ATA connector 2 x 1 wafer, pitch 2.00mm SATAPW1 SATA Power connector 20 ARC-1532-C1 Quick Reference Guide... -
Page 21: Arc-Sklu Jumpers & Connectors Settings
Quick Reference Guide 2.6 ARC-SKLU Jumpers & Connectors settings 2.6.1 Clear CMOS (JCOMS1) Protect* Clear CMOS *Default 2.6.2 Serial port 1/2 pin9 signal select (JRI1/JRI2) Ring* +12V JRI2 JRI1 * Default ARC-1532-C1 Quick Reference Guide 21... -
Page 22: Lcd Backlight Brightness Adjustment (Jbklsel1)
ARC-1532-C1 2.6.3 LCD backlight brightness adjustment (JBKLSEL1) PWM Mode* DC Mode * Default 2.6.4 AT/ATX Input power select (JAT1) ATX* * Default 22 ARC-1532-C1 Quick Reference Guide... -
Page 23: Serial Port 1 In Rs-232/422/485 Mode (Jcom1_Sel1)
NDTRA# 485_422TX1+ COM1-2 NRXDA 422RX1+ COM1-3 NTXDA 485_422TX1- COM1-1 NDCDA# Note: This connector is available after modify the mode of COM1 in BIOS setting. * Default 2.6.6 LCD Inverter connector (JBKL1) Signal LVDS_BKLT_CTL LVDS_BKLT_EN +12V ARC-1532-C1 Quick Reference Guide 23... -
Page 24: On-Board Header For Usb2.0 (Jusb1)
ARC-1532-C1 2.6.7 On-board header for USB2.0 (JUSB1) Signal +5VSB USB_z_PN10 USB_z_PP10 2.6.8 On-board header for USB2.0 (JUSB2) Signal PIN PIN Signal +5VSB +5VSB USB_z_PN6 USB_z_PN5 USB_z_PP6 USB_z_PP5 24 ARC-1532-C1 Quick Reference Guide... -
Page 25: Battery Connector (Jbat1)
Quick Reference Guide 2.6.9 Battery connector (JBAT1) Signal +RTCBAT 2.6.10 LCD backlight brightness adjustment (JBLK_CTRL1) Signal Note BLK_VR_MOD VR must select 10K/1% Low pulse button for BLK_BRI_UP backlight brighter Low pulse button for BLK_BRI_DN backlight dim ARC-1532-C1 Quick Reference Guide 25... -
Page 26: Lvds Connector (Jlvds1)
LVDS_DATA1_P LVDS_DATA0_N 12 11 LVDS_DATA1_N LVDS_DATA2_P 16 15 LVDS_DATA3_P LVDS_DATA2_N 18 17 LVDS_DATA3_N LVDS_DATA4_P 22 21 LVDS_DATA5_P LVDS_DATA4_N 24 23 LVDS_DATA5_N LVDS_DATA6_P 28 27 LVDS_DATA7_P LVDS_DATA6_N 30 29 LVDS_DATA7_N LVDS_CLK1_P LVDS_CLK2_P LVDS_CLK1_N LVDS_CLK2_N +12V +12V 26 ARC-1532-C1 Quick Reference Guide... -
Page 27: Amplifier_R (Jspr1)
Quick Reference Guide 2.6.12 AMPLIFIER_R (JSPR1) Signal SPK_R- SPK_R+ 2.6.13 AMPLIFIER_L (JSPL1) Signal SPK_L- SPK_L+ ARC-1532-C1 Quick Reference Guide 27... -
Page 28: Spi Connector (Jspi1)
ARC-1532-C1 2.6.14 SPI connector (JSPI1) Signal PIN PIN Signal +3.3VSB SPI0_CS0# SPI_CLK SPI_SO SPI_SI HOLD# 2.6.15 EC Debug connector (JEC1) Signal EC_SMCLK_DEBUG EC_SMDAT_DEBUG 28 ARC-1532-C1 Quick Reference Guide... -
Page 29: B2B Connector (Jb2B1)
PCIE_RXP8 HDMI1_CLKN Signal PIN PIN Signal HDMI1_CLKP CLK_B2BPCIE_N2 CLK_B2BPCIE_P2 +12V MIC_RIN +12V MIC_LIN MIC1_JD LPC_SERIRQ 46 +5VSB LINEOUT1_JD LINE1_JD LPC_LFRAME# 47 +5VSB LINEOUT_R LINE1_RIN CLK3_LPC_B2B 48 +5VSB LINEOUT_L LNE1_LIN LPC_AD0 49 +5VSB LPC_AD1 50 +5VSB ARC-1532-C1 Quick Reference Guide 29... -
Page 30: Touch Panel Connector (Jtp1)
ARC-1532-C1 2.6.17 Touch panel connector (JTP1) Signal SENSE 2.6.18 General purpose I/O connector (JGPIO1) Signal PIN PIN Signal +3.3V SMB_DATA SMB_CLK DIO_GP23 DIO_GP13 DIO_GP22 DIO_GP12 DIO_GP21 DIO_GP11 DIO_GP20 DIO_GP10 30 ARC-1532-C1 Quick Reference Guide... -
Page 31: Sata Power Connector (Satapw1)
Quick Reference Guide 2.6.19 SATA Power connector (SATAPW1) Signal ARC-1532-C1 Quick Reference Guide 31... -
Page 32: Arc-Byt Db-A/B/C/D/G/H/K Overviews
ARC-1532-C1 2.7 ARC-BYT DB-A/B/C/D/G/H/K Overviews 2.7.1 ARC-BYT DB-A 2.7.2 ARC-BYT DB-B 2.7.3 ARC-BYT DB-C 32 ARC-1532-C1 Quick Reference Guide... -
Page 33: Arc-Byt Db-D
Quick Reference Guide 2.7.4 ARC-BYT DB-D 2.7.5 ARC-BYT DB-G 2.7.6 ARC-BYT DB-H ARC-1532-C1 Quick Reference Guide 33... -
Page 34: Arc-Byt Db-K
Line-in audio jack B_MIC_IN1 Mic-in audio jack B_JHDMI1 HDMI connector B2B connector B_JB2B1 2.8.3 ARC-BYT DB-C Connectors Label Function Note C_JPCIE1 Mini PCI Express connector C_JSIM1 SIM card slot (Push-push) C_JHDMI1 HDMI connector B2B connector C_JB2B1 34 ARC-1532-C1 Quick Reference Guide... -
Page 35: Arc-Byt Db-D
H_JUSB1 USB3.0 connector H_COM1/2 Serial Port 1/2 connector DB-9 male connector B2B connector H_JB2B1 2.8.7 ARC-BYT DB-K Connectors Label Function Note I_JLAN1 RJ-45 Ethernet I_COM1/2 Serial Port 1/2 connector DB-9 male connector I_JB2B1 B2B connector ARC-1532-C1 Quick Reference Guide 35... -
Page 36: Arc-Byt Db-D Connectors Settings
Serial Port 1 connector (D_COM1) Signal PIN PIN Signal NDCD#_3_D NDSR#_3_D NRXD_3_D NRTS#_3_D NTXD_3_D NCTS#_3_D NDTR#_3_D NRI#_3_D 2.9.2 Serial Port 2 connector (D_COM2) Signal PIN PIN Signal NDCD#_2_D NDSR#_2_D NRXD_2_D NRTS#_2_D NTXD_2_D NCTS#_2_D NDTR#_2_D NRI#_2_D 36 ARC-1532-C1 Quick Reference Guide... -
Page 37: Arc-Byt Db-G Connectors Settings
Serial Port 1 connector (G_COM1) Signal PIN PIN Signal NDCD#_3_G NDSR#_3_G NRXD_3_G NRTS#_3_G NTXD_3_G NCTS#_3_G NDTR#_3_G NRI#_3_G 2.10.2 Serial Port 2 connector (G_COM2) Signal PIN PIN Signal NDCD#_2_G NDSR#_2_G NRXD_2_G NRTS#_2_G NTXD_2_G NCTS#_2_G NDTR#_2_G NRI#_2_G ARC-1532-C1 Quick Reference Guide 37... -
Page 38: Serial Port 3 Connector (G_Com3)
ARC-1532-C1 2.10.3 Serial Port 3 connector (G_COM3) Signal PIN PIN Signal NDCD#_1_G NDSR#_1_G NRXD_1_G NRTS#_1_G NTXD_1_G NCTS#_1_G NDTR#_1_G NRI#_1_G 2.11 ARC-BYT DB-H Jumpers settings 2.11.1 USB Power selector (H_USB_PWR_SEL1) +5VSB* *Default 38 ARC-1532-C1 Quick Reference Guide... -
Page 39: Arc-Byt Db-H Connectors Settings
Serial Port 1 connector (H_COM1) Signal PIN PIN Signal NDCD#_1_H NDSR#_1_H NRXD_1_H NRTS#_1_H NTXD_1_H NCTS#_1_H NDTR#_1_H NRI#_1_H 2.12.2 Serial Port 2 connector (H_COM2) Signal PIN PIN Signal NDCD#_2_H NDSR#_2_H NRXD_2_H NRTS#_2_H NTXD_2_H NCTS#_2_H NDTR#_2_H NRI#_2_H ARC-1532-C1 Quick Reference Guide 39... -
Page 40: Arc-Byt Db-K Connectors Settings
Serial Port 1 connector (I_COM1) Signal PIN PIN Signal NDCD#_1_I NDSR#_1_I NRXD_1_I NRTS#_1_I NTXD_1_I NCTS#_1_I NDTR#_1_I NRI#_1_I 2.13.2 Serial Port 2 connector (I_COM2) Signal PIN PIN Signal NDCD#_2_I NDSR#_2_I NRXD_2_I NRTS#_2_I NTXD_2_I NCTS#_2_I NDTR#_2_I NRI#_2_I 40 ARC-1532-C1 Quick Reference Guide... -
Page 41: Bios Setup
Quick Reference Guide 3.BIOS Setup ARC-1532-C1 Quick Reference Guide 41... -
Page 42: Introduction
If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. 42 ARC-1532-C1 Quick Reference Guide... -
Page 43: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. ARC-1532-C1 Quick Reference Guide 43... -
Page 44: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 44 ARC-1532-C1 Quick Reference Guide... -
Page 45: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. ARC-1532-C1 Quick Reference Guide 45... -
Page 46: System Language
Use the system time option to set the system time. Manually enter the hours, minutes and seconds. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 46 ARC-1532-C1 Quick Reference Guide... -
Page 47: Trusted Computing
Item Options Description Enables or Disables BIOS support for Disable, security device. O.S. will not show Security Device Support Enable[Default] Security Device. TCG EFI protocol and INT1A interface will not be available. 3.6.2.2 APCI Settings ARC-1532-C1 Quick Reference Guide 47... - Page 48 AC loss resume. Last state Disabled[Default], 30 sec 40 sec 50 sec Watch Dog Select WatchDog. 1 min 2 min 10 min 30 min Disabled Enabled/Disabled USB Standby Power USB Standby Power Setting Enabled[Default], during S3/S4/S5. 48 ARC-1532-C1 Quick Reference Guide...
-
Page 49: Amt Configuration
Disabled Intel AMT always enabled. This option just controls the BIOS Enabled[Default], extension execution. If enabled, this requires additional firmware in the SPI device. Disabled[Default] Un-Configure ME OEMFlag Bit 15: Un-Configure ME without password. Enabled, ARC-1532-C1 Quick Reference Guide 49... -
Page 50: Pch-Fw Configuration
You can use this item to set up or change the IT8528 Super IO configuration for serial ports. Please refer to 3.6.2.5.1~ 3.6.2.5.5 for more information. Item Options Description DB-A/C/E/J DB board A-K. DA-A/B/C/E/J w/o UART DB-G w/t DB board DB-B 3UART DB-D/H/K w/t 2UART DB-F w/t 1UART. DB-F 1COM 50 ARC-1532-C1 Quick Reference Guide... -
Page 51: Serial Port 1 Configuration
Set Parameters of Serial Port 5 (COME). 3.6.2.5.1 Serial Port 1 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled UART 232[Default] UART 232 422 485 UART 422 Change the Serial Port UART 485 ARC-1532-C1 Quick Reference Guide 51... -
Page 52: Serial Port 2 Configuration
ARC-1532-C1 3.6.2.5.2 Serial Port 2 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.5.3 Serial Port 3 Configuration 52 ARC-1532-C1 Quick Reference Guide... -
Page 53: Serial Port 4 Configuration
Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.5.4 Serial Port 4 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.5.5 Serial Port 5 Configuration ARC-1532-C1 Quick Reference Guide 53... -
Page 54: H/W Monitor
ARC-1532-C1 Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.6 H/W Monitor 3.6.2.7 S5 RTC Wake Settings 54 ARC-1532-C1 Quick Reference Guide... -
Page 55: Serial Port Console Redirection
Select Dynamic Time, System will wake on Dynamic Time the current time + Increase minute(s). 3.6.2.8 Serial Port Console Redirection Item Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled 3.6.2.8.1 Legacy Console Redirection Settings ARC-1532-C1 Quick Reference Guide 55... -
Page 56: Cpu Configuration
Select a COM port to display redirection of Legacy Serial Redirection Port COM1[Default], Legacy OS and Legacy OPROM Messages. 3.6.2.9 CPU Configuration Use the CPU configuration menu to view detailed CPU specification and configure the CPU. 3.6.2.10 Intel TXT Configuration 56 ARC-1532-C1 Quick Reference Guide... -
Page 57: Sata Configuration
Disabled state. Enabled[Default] Port 1/2 Enable or Disable SATA Port. Disabled, Hard Disk Drive [Default] Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. ARC-1532-C1 Quick Reference Guide 57... -
Page 58: Network Stack Configuration
ARC-1532-C1 3.6.2.12 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 3.6.2.13 CSM Configuration 58 ARC-1532-C1 Quick Reference Guide... -
Page 59: Usb Configuration
Interrupt transfers. 20 sec[Default] 10 sec 20 sec[Default] USB mass storage device Start Unit command Device reset time-out 30 sec time-out. 40 sec Device power-up delay Auto[Default] Maximum time the device will take before it ARC-1532-C1 Quick Reference Guide 59... -
Page 60: Chipset
1100 Forced FDD format. Optical drives are emulated as ‘CDROM’, drives with no media will be Hard Disk CD-ROM emulated according to a drive type. 3.6.3 Chipset 3.6.3.1 System Agent (SA) Configuration 60 ARC-1532-C1 Quick Reference Guide... -
Page 61: Graphics Configuration
Active Internal LVDS (eDP->Ch7511- Active LVDS (CH7511) Disabled to-LVDS). BIOS[Default] LVDS Brightness Control Method. BR Button Brightness Control Method 1.BIOS 2.Brightness Button 3.Variable Resistor 4.OS Driver. OS Driver LVDS Back Light PWM Select LVDS back light PWM duty. ARC-1532-C1 Quick Reference Guide 61... -
Page 62: Memory Configuration
Onboard Touch Setting Enable/Disable USB Touch. Disabled 3.6.3.1.2 Memory Configuration Item Option Description Maximum Value of TOLUD. Dynamic Dynamic[Default] assignment would adjust TOLUD Max TOLUD 1GB/1.25GB/1.5GB/1.75GB automatically based on largest MMIO length /2GB/2.25GB/2.5GB/2.75GB of installed graphic controller. 62 ARC-1532-C1 Quick Reference Guide... -
Page 63: Pch-Io Configuration
Quick Reference Guide 3.6.3.2 PCH-IO Configuration Item Option Description Disabled PCH LAN Controller Enable or disable onboard NIC. Enabled[Default] 3.6.3.2.1 PCI Express Configuration ARC-1532-C1 Quick Reference Guide 63... -
Page 64: Pci Express Root Port5 (I210/211)
L0s State AUTO – BIOS auto ASPM Support configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2[Default], Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 64 ARC-1532-C1 Quick Reference Guide... -
Page 65: Pci Express Root Port8 (B2B Mpcie)
L0s State AUTO – BIOS auto ASPM Support configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2[Default], Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 ARC-1532-C1 Quick Reference Guide 65... -
Page 66: Pci Express Root Port12 (Mpcie)
L0s State AUTO – BIOS auto ASPM Support configure DISABLE – Disables ASPM. L0sL1 Auto Disabled L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2[Default], Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 66 ARC-1532-C1 Quick Reference Guide... -
Page 67: Usb Configuration
Option to disable Compliance Mode. Default FALSE[Default], XHCI Disable Compliance Mode is FALSE to not disable Compliance Mode. TRUE Set TRUE to disable Compliance Mode. 3.6.3.2.3 HD Audio Configuration ARC-1532-C1 Quick Reference Guide 67... -
Page 68: Security
Enabled disabled Enabled = HDA will be Auto[Default], unconditionally enabled Auto = HDA will be enabled if present, disabled otherwise. 3.6.4 Security Administrator Password Set setup Administrator Password User Password Set User Password 68 ARC-1532-C1 Quick Reference Guide... -
Page 69: Secure Boot Menu
Secure Boot User mode with enrolled Platform Key(PK) 2.CSM Enabled function is disabled. Secure Boot mode selector. ‘Custom’ Mode enables Standard Secure Boot Mode users to change Image Execution policy and manage Custom[Default] Secure Boot Keys. ARC-1532-C1 Quick Reference Guide 69... -
Page 70: Key Management
ARC-1532-C1 3.6.4.1.1 Key Management Item Option Description Enabled, Install Factory default Secure Boot Keys Provision Factory Default keys Disabled[Default] when System is in Setup Mode. 3.6.5 Boot 70 ARC-1532-C1 Quick Reference Guide... -
Page 71: Save And Exit
Fast Boot Enabled required to launch active boot option. Has no effect for BBS boot options. Boot Option #1 Set the system boot order. 3.6.6 Save and exit ARC-1532-C1 Quick Reference Guide 71... - Page 72 This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. 72 ARC-1532-C1 Quick Reference Guide...
