General notes
1. After unpacking, check all parts for any transport dam-
age. Inform the supplier immediately of any faults.
2. Later complaints cannot be considered.
3. Make sure the delivery is complete.
4. Before putting into operation, familiarize yourself with
the machine by carefully reading these in structions.
5. Use only original scheppach accessories, wearing or re-
placement parts. You can find replacement parts at your
scheppach dealer.
6. When ordering, include our item number and the type and
year of construction of the machine.
Dear customer,
We wish you much pleasure and success with your new
scheppach machine.
NOTE:
In accordance with valid product liability laws, the manu-
facturer of this device shall not be responsible for damage
to and from this device which results from:
1. Improper care.
2. Noncompliance with the Operating Instructions.
3. Repairs made by unauthorized persons.
4. The installation and use of any parts which are not origi-
nal scheppach replacement parts.
5. Improper use and application.
6. Failure of the electrical system as a result of non-
compliance with the legal and applicable electrical di-
rectives and VDE regulations 0100, DIN 57113 / VDE
0113.
We recommend that you read through the entire operating in-
structions before putting into operation.
These operating instructions are to assist you in getting to
know your machine and utilize its proper applications.
The operating instructions contain important notes on how
you work with the machine safely, expertly, and economi-
cally, and how you can avoid hazards, save repair costs,
reduce downtime and increase the reliability and service
life of the machine.
In addition to the safety requirements contained in these
operating instructions, you must be careful to observe your
country's applicable regulations.
The operating instructions must always be near the
machine. Put them in a plastic folder to protect them from
dirt and humidity. They must be read by every operator
before beginning work and observed conscientiously. Only
persons who have been trained in the use of the machine
and have been informed of the various dangers may work
with the machine. The required minimum age must be ob-
served.
In addition to the safety requirements contained in these
operating instructions and your country's applicable
regulations, you should observe the generally recognized
technical rules concerning the operation of woodworking
machines.
Set-up:
Prepare the workplace where the machine is to be placed.
Insure sufficient room to allow safe work without malfunc-
tions. The machine is designed to operate in closed rooms
and must be placed stabily on firm level ground. Stability
is insured by attachment to the ground with 4 screws (Fig.
18).
Transport:
By lifting the machine at the front side it can easily be
moved according to your needs in the workshop.
Tisa 5.0
Supply volume
Circular sawbench Tisa 5.0
2.0 m suction hose 50 mm wide
Longitudinal fence with angle bar
Technical data
Dimensions L x W x
H mm (including table
length extension)
Overall length mm
without table length
extension
Table size mm
Table height mm
Sawblade ø min. –
max. mm
Suction connection
ø mm
Volume flow m 3 /h
static depression pA
(20 m/s)
Weight kg
Cutting data
Cutting height in mm
at 90°
Cutting height in mm
at 45°
Cutting width in mm at
90° angle cut
Sawblade height ad-
justment mm
Sawblade inclination
range
Sawblade speed 1/min
Cutting speed m/sec
Parallel cutting
width mm max.
Cross-cutting gauge
Drive
110/50 230/50
Motor V/Hz
2200
Power input P1 W
Power output P2 W 1500
Speed 1/min
Operating mode
Motor protection
with motor and switch
Feet and braces
Sawblade ø 315 mm
Cross-cutting gauge
Suction piece
Sawblade guard
Riving knife
Table length extension
Sawblade key
Push stick / push handle
Operating instructions
1590 x 590 x 1200
790
790 x 590
850
300 – 315
100
565
560
61 (230V) / 63 (400V)
102
70
260
102
-2° – +48°
4000
65
345
0° – 45°
400/50
2200 3000 4200
1500 2200 3000
2800
S6/40%
yes
9
