Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury, death
and/or property damage! Retain instructions for future reference.
CAMPBELL
HAUSFELD
Description
This nailer is designed for trimwork, interior molding, baseboards, paneling and
cabinet assembly and installation. Features include: convenient side loading maga-
zine which holds up to 100 nails, no-mar tip, adjustable exhaust, single cycle trig-
ger and quick clear nose.
General Safety Information
This manual contains safety, operational
and maintenance information.
Read this manual and
understand all safety
warnings and instruc-
tions before operating
the nailer. Contact your
Campbell Hausfeld rep-
resentative if you have any questions.
The operator of this nailer must take
the necessary precautions to prevent
unsafe conditions outlined in this manu-
al from occurring. The operator is also
required to read and understand this
instruction manual and all safety warn-
ings, labels, etc.
Any employer allowing the use of this
nailer in their field of work must dis-
tribute this instruction manual to all
users. The employer must also ensure
all users read, understand and follow
the instructions as described in the
manual, safety warnings, labels, etc.
Danger indicates
an imminently
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Do not use any type
of flammable gases
or oxygen as a power
source for the nailer.
Use filtered, lubricat-
ed, regulated com-
pressed air only. Use
of a compressed gas instead of
compressed air may cause the nailer
to explode and cause death or
serious personal injury.
Do not exceed maxi-
mum operating pres-
sure of the nailer
(110 PSI). The nailer
will not function
Campbell Hausfeld Nailers meet or exceed Industries' Standards as set forth by the American
National Standard/International Staple, Nail and Tool Association in ANSI/ISANTA SNT-101-1993.
© 1996 Campbell Hausfeld
properly. Do not use a compressed
air source capable of more than 200
PSI. The nailer could explode and
cause death or serious personal
injury.
Never use gasoline or
other flammable liq-
MANUAL
uids to clean the nail-
er. Never use the nail-
er in the presence of
flammable liquids or
gases. Vapors could ignite by a spark
and cause an explosion which will
result in death or serious personal
injury.
Always place
yourself in a
firmly balanced
position when
using or han-
dling the
nailer.
Do not modify
or disable the
Work Contact
Element (WCE)
in a depressed
position or tape
or modify the
trigger in a pulled position. Death or
serious personal injury will occur.
Never keep the
trigger pulled
when carrying
O
or holding the
CO
2
nailer. Make
sure not to pull
the trigger or
depress the
work contact element (WCE) trip
mechanism when connecting the
nailer to an air compressor. Death or
110 PSI
serious puncture wounds will occur
if the work contact element (WCE)
bumps something.
Finishing Nailer
ardous situation which, if not avoided,
COULD result in death or serious
injury.
Disconnect the
nailer from air
supply before
adjusting, clear-
ing jams, servic-
ing, relocating
and during non-
operation. Remember it is possible
for the nailer to eject a fastener
after servicing the tool. ALWAYS
reconnect the air lines before load-
ing any fasteners. Death or serious
personal injury could result.
Protect your eyes and
ears. Wear Z87 safety
glasses, with side
shields. Wear hearing
protection. Employers
and users are respon-
sible for ensuring the
user or anyone near
the nailer wears this
CAMPBELL
HAUSFELD safety protection.
PROFESSIONAL
Serious eye injury or
permanent hearing
loss could result.
Do not use a
check valve or
any other fit-
ting which
allows air to
remain in the
nailer. Serious
personal injury
could occur.
Model NB0050
Model NB0050
Warning indicates
a potentially haz-
IN247201AV 1/97
