Operating Instructions
Radar sensor for continuous level
measurement
VEGAPULS C 21
Two-wire 4 ... 20 mA/HART
Document ID: 58341

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGAPULS C 21 and is the answer not in the manual?

Questions and answers

Related Manuals for Vega VEGAPULS C 21

Summary of Contents for Vega VEGAPULS C 21

  • Page 1 Operating Instructions Radar sensor for continuous level measurement VEGAPULS C 21 Two-wire 4 … 20 mA/HART Document ID: 58341...

  • Page 2: Table Of Contents

    Parameter adjustment ....................24 Setup with PC/notebook (VEGACONNECT) ................ 25 Connect the PC ......................25 Parameter adjustment with PACTware ................26 Saving the parameterisation data ................... 27 10 Menu overview ........................28 VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 3 14.1 Technical data ........................ 41 14.2 Dimensions ........................45 14.3 Industrial property rights ....................46 14.4 Hash function acc. to mbed TLS ..................46 14.5 Trademark ........................46 Editing status: 2019-10-10 VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 4: About This Document

    Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, note, tip: This symbol indicates helpful additional infor- mation and tips for successful work.

  • Page 5: For Your Safety

    During work on and with the device, the required personal protective equipment must always be worn. Appropriate use VEGAPULS C 21 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 6: Eu Conformity

    Safety instructions for Ex areas For Ex applications, only devices with corresponding Ex approval may be used. Observe the Ex-specific safety instructions. These are an integral part of the operating instructions and are enclosed with every device with Ex approval. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 7: Product Description

    • Hardware version from 1.0.0 • Software version from 1.0.0 Constituent parts Fig. 1: Components of VEGAPULS C 21 Radar antenna 2 Process fitting Electronics housing Mounting thread Connection cable VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 8: Principle Of Operation

    Enter serial number manually in the VEGA Tools app (available free of charge in the respective stores) Principle of operation VEGAPULS C 21 is a radar sensor for continuous level measurement. Application area It is suitable for liquids and solids in virtually all industries, particularly in the water and waste water industry.
  • Page 9 This is done via an interface converter and a PC/ notebook using DTM/PACTware. Fig. 4: Connecting the PC to the signal cable Sensor 2 HART resistance 250 Ω (optional depending on evaluation) Connection cable with 2 mm pins and terminals Voltage supply Interface adapter VEGACONNECT VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 10: Packaging, Transport And Storage

    The mounting accessories include e.g. bracket and mounting bracket and are used for stable mounting of the sensor at the measuring point. The parts are available in various versions and sizes. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 11: Mounting

    Mounting bracket For a rigid mounting, a mounting bracket with opening for thread G1½, e.g. from the VEGA product range, is recommended. The mounting of the sensor in the bracket is carried out via a G1½ counter nut of plastic. Take note of chapter "Mounting instructions" for the recommended distance to the wall.
  • Page 12 In vessels with conical bottom it can be advantageous to mount the sensor in the centre of the vessel, as measurement is then possible down to the bottom. Fig. 8: Mounting of the radar sensor on vessels with conical bottom VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 13 (0.2 in) out of the socket. Fig. 11: Recommended threaded socket mounting of VEGAPULS C 21 If the reflective properties of the medium are good, you can mount VEGAPULS C 21 on sockets longer than the antenna. The socket end should be smooth and burr-free, if possible also rounded. Note: When mounting on longer sockets, we recommend carrying out a false signal suppression (see chapter "Parameter adjustment").
  • Page 14 Small, inclined sheet metal baffles above the installations scatter the radar signals and prevent direct interfering reflections. Fig. 13: Cover flat, large-area profiles with deflectors Sensor orientation In liquids, direct the sensor as perpendicular as possible to the prod- uct surface to achieve optimum measurement results. Fig. 14: Alignment in liquids VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 15: Measurement Setup - Flow

    Detailed project planning data can be found at the channel manufac- turers and in the technical literature. The measurement can be individually configured for the respective flume via a PC/notebook and PACTware/DTM.The measurement can be individually configured for the respective flume via a PC/notebook and PACTware/DTM. The following examples serve as an overview for flow measurement. At smaller distances the measuring accuracy is reduced, see Technical data. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 16 3 ... 4 h 90° 90° Fig. 16: Flow measurement with rectangular flume: h = max. filling of the max. rectangular flume 1 Overflow orifice (side view) Headwater Tailwater 4 Overfall orifice (view from tailwater) Khafagi-Venturi flume 3 ... 4 x h 90° Fig. 17: Flow measurement with Khafagi-Venturi flume: h = max. filling of the max. flume; B = tightest constriction in the flume Position sensor 2 Venturi flume VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 17: Connecting To Power Supply

    In Ex systems, the grounding is carried out according to the installa- tion regulations. Wiring plan Wire assignment, con- nection cable Fig. 18: Wire assignment in permanently connected connection cable VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 18: Switch-On Phase

    After connection to the power supply, the device carries out a self- test: • Internal check of the electronics • Output signal is set to failure The current measured value is then output on the signal cable. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 19: Access Protection

    The device code is also stored in the adjustment tool. However, it must be re-entered for each unlocking. When using the VEGA Tools app, the stored device code is then suggested to the user for unlocking.
  • Page 20 "Emergency codes". If this document is lost, the emergency device unlock code can be retrieved from your VEGA contact person after legitimation. The storage and transmission of the device codes is always encrypted (SHA 256 algorithm).

  • Page 21: Setup With Smartphone/Tablet (Bluetooth)

    Play Store" or "Baidu Store" to your smartphone or tablet. Connecting Connecting … Start the VEGA Tools app and select the function "Setup". The smart- phone/tablet searches automatically for Bluetooth-capable instru- ments in the area. The message "Searching …" is displayed.

  • Page 22: Parameter Adjustment

    Menu item display The selected menu item can be recognized by the colour change. Fig. 20: Example of an app view - Setup sensor adjustment Enter the requested parameters and confirm via the keyboard or the editing field. The settings are then active in the sensor. Close the app to terminate connection. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 23: Setup With Pc/Notebook (Bluetooth)

    Older systems do not always have an integrated Bluetooth LE. In these cases, a Bluetooth USB adapter is required. Activate the Bluetooth USB adapter via the VEGA project assistant (see supplementary instructions "Bluetooth USB adapter"). After activating the integrated Bluetooth or the Bluetooth USB adapt- er, devices with Bluetooth are found and created in the project tree.

  • Page 24: Parameter Adjustment

    (DTM) according to FDT standard are required. The latest PACTware version as well as all available DTMs are compiled in a DTM Collec- tion. The DTMs can also be integrated into other frame applications according to FDT standard. Fig. 22: Example of a DTM view - Setup, sensor adjustment VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 25: Setup With Pc/Notebook (Vegaconnect)

    149A, VEGAMET 381, VEGAMET 391. Common Ex separators are also usually equipped with a sufficient current limiting resistance. In such cases, the interface converter can be connected parallel to the 4 … 20 mA cable (dashed line in the previous illustration). VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 26: Parameter Adjustment With Pactware

    "DTM Collection/PACTware" attached to each DTM Collection and which can also be downloaded from the Internet. Detailed descrip- tions are available in the online help of PACTware and the DTMs. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 27: Saving The Parameterisation Data

    CD from the agency serving you. Saving the parameterisation data We recommend documenting or saving the parameterisation data via PACTware. That way the data are available for multiple use or service purposes. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 28: Menu Overview

    0 % correspond to 0 l Scaling unit 100 % correspond to 100 l Scaling format Display Menu language Displayed value Filling height Backlight Access protection Bluetooth access code Protection of the parameteri- Deactivated zation VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 29 Sensor character- Sensor features from order text istics Simulation Measured value Simulation value Measured value Indication measured value mem- memory (DTM) ory from DTM VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 30: Diagnostics And Servicing

    • Checking the output signal • Treatment of measurement errors A smartphone/tablet with the VEGA Tools app or a PC/notebook with the software PACTware and the suitable DTM offer you further com- prehensive diagnostic possibilities. In many cases, the causes can be determined in this way and the faults eliminated.

  • Page 31: Diagnosis, Fault Messages

    Function check - orange Maintenance - blue Failure: Due to a malfunction in the instrument, a fault message is output. This status message is always active. It cannot be deactivated by the user. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 32 Repeat setup Byte 4, Bit 1 of Byte 0 … 5 Error in the instru- False signal suppression faulty Carry out a reset ment settings Error when carrying out a reset VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 33 Bit 5 of during operation Byte 14 … 24 No echo available Use a more suitable antenna/ Antenna dirty or defective sensor Remove possible false echoes Optimize sensor position and ori- entation VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 34: Treatment Of Measurement Errors

    Liquids: Measurement error at constant level Fault description Cause Rectification Measured value shows a too Min./max. adjustment not correct Adapt min./max. adjustment low or too high level Incorrect linearisation curve Adapt linearisation curve time VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 35 The sensor goes into overfill protection flange socket? mode. The max. level (0 m distance) as Remove contamination on the antenna well as the status message "Overfill pro- tection" are output. time VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 36 (jumps to multiple echo) polarization direction Chose a more suitable installation po- sition Transverse reflection from an extraction Direct sensor to the opposite fun- time funnel, amplitude of the transverse re- nel wall, avoid crossing with the filling flection larger than the level echo stream VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 37: Software Update

    Optimize installation position and sen- the vessel wall (deflection) sor orientation time 11.6 Software update The device software can be updated in the following ways: • HART signal • Bluetooth The following components are required: VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 38: How To Proceed If A Repair Is Necessary

    Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Ask the agency serving you to get the address for the return ship- ment. You can find the agency on our homepage. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 39: Dismount

    12.2 Disposal The device is made of recyclable materials. For this reason, it should be disposed of by a specialist recycling company. Observe the ap- plicable national regulations. VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 40: Certificates And Approvals

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 41: Supplement

    The antenna edge is also the reference plane for the measurement. Fig. 27: Data of the input variable Reference plane Measured variable, max. measuring range Max. measuring range 15 m (49.21 ft) Depending on application and medium VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 42 ≤ 2 mm Deviation with bulk solids The values depend to a great extent on the application. Binding specifications are thus not possible. With bulk solids Default values can be assigned individually. Already included in the meas. deviation VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 43 Ʋ Max. spectral transmission power +34 dBm/50 MHz EIRP density Ʋ Max. power density at a distance of < 3 µW/cm² With operating voltage U ≥ 24 V DC Time span after a sudden distance change from 1 m to 5 m until the output signal reaches 90 % of the final value for the first time (IEC 61298-2). Valid with operating voltage U ≥ 24 V DC. Outside the specified beam angle, the energy level of the radar signal is 50% (-3 dB) less. EIRP: Equivalent Isotropic Radiated Power VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
  • Page 44 < 18 V ≤ 0.7 V (16 … 400 Hz) Ʋ for 18 V < U < 35 V ≤ 1 V (16 … 400 Hz) Load resistor Ʋ Calculation )/0.022 A Depending on the local conditions VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 45: Dimensions

    VEGAPULS C 21 ø 76 mm (2.99") G1; 1NPT R 1½ 1½ - 14 NPT G1½ ø 68 mm (2.68") Fig. 29: Dimensions VEGAPULS C 21 Thread G1½ Thread 1½ NPT Thread R1½ VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...

  • Page 46: Industrial Property Rights

    Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com.
  • Page 47 Notes VEGAPULS C 21 • Two-wire 4 … 20 mA/HART...
