8. Set the motor brake on the speed controller to "hard
brake"; the procedure is described in the speed
controller instructions.
7. T T
UNING IP
If you would like a stronger rate of climb, you can achieve
this by fitting a larger propeller, but at the cost of reduced
motor run time. Using the alternative folding propeller
blades listed below will increase the current draw and
with it the climb rate. The motor run time will be reduced,
as the motor will be working in an area of poorer
efficiency. Nevertheless, both the motor and the controller
will still be working within their specified limits.
If you wish to use propeller blades even larger than
those stated, you do so at your own risk.
Measure the current drain before flying the model for the
first time. Read the motor / speed controller instructions,
and observe the limits regarding maximum permissible
current for the components you are using.
Typical operational data with alternative folding props:
3S LiPo / Prop: 12" x 8" (alternative):
3S LiPo / Prop: 13.5" x 7" (alternative):
8. H -
IMAX MOTOR
Type:
#
RPM / V:
Cell count, NiXX / LiPo:
Efficient operating current:
Max. current for 15 sec.:
Shaft Ø:
Diameter:
Length:
Weight:
Max. output:
Max. case temperature:
Mounting:
You will find comprehensive operating instructions for the
Himax C 3522-0700
DOWNLOADS INSTRUCTIONS.
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de
Operating Instructions for Power Set "Cularis"
Current drain: approx. 26.0 A
Current drain: approx. 32.0 A
SPECIFICATION
C 3522-0700
33 3025
700
9 - 12 / 3S - 4S
8 A - 29 A
40 A
5.0 mm
35 mm
48 mm
162 g
400 W
65° C
∅ 25 mm / 4 x M3
at www.multiplex-rc.de
9. G
UARANTEE
MULTIPLEX products are covered by the statutory
guarantee regulations. If you wish to make a claim under
guarantee, please contact the model shop where you
purchased the product in the first instance.
The guarantee does not cover damage and malfunctions
caused by:
• Improper handling, incorrect connections, reversed
polarity
• Use of accessories other than genuine MULTIPLEX
items
• Modifications or repairs not carried out by MULTIPLEX
or an authorised MULTIPLEX Service Centre
• Accidental or deliberate damage
• Defects due to normal wear and tear
• Use outside the technical specifications
10. CE A
PPROVAL
This product satisfies all the relevant statutory
harmonised EU directives.
You are therefore the owner of a product whose design
fulfils the protective aims of the European Community
relating to the safe operation of equipment.
You are entitled to obtain a copy of the conformity
declaration for this product by contacting MULTIPLEX
using the information at the foot of the page.
11. D I
ISPOSAL NFORMATION
Electrical equipment marked with the cancelled
waste bin symbol must not be discarded in the
standard household waste; instead it must be
taken to a suitable specialist disposal system.
In the countries of the EU (European Union), electrical
equipment must not be discarded via the normal domestic
refuse system (WEEE – Waste of Electrical and
Electronic Equipment, directive 2002/96/EG). You can
take unwanted equipment to your nearest local authority
waste collection point or recycling centre, where the items
will be disposed of correctly and at no cost to you.
By returning your unwanted equipment you can make an
important contribution
environment.
to the protection of
