Dear Customer
Thank you for purchasing this Trend product,
we hope you enjoy many years of creative and
productive use.
Please remember to return your guarantee card
within 28 days of purchase.
CONTENTS
TECHNICAL DATA ____________________ 1
SAFETY PRECAUTIONS _______________ 2
ITEMS ENCLOSED ___________________ 3
POCKET HOLE CONCEPT _____________ 3
DESCRIPTION OF PARTS ______________ 4
- Setting up the Jig ____________________ 5
- Fitting the Slide Adjusters _____________ 5
- Screw Chart ________________________ 5
- Setting the Drill Bit Depth ______________ 6
- Adjusting the Position _________________ 7
- Setting the Slides For Timber Thickness __ 7
- Drilling the Pocket Holes _____________ 8-9
- Clamping Arrangements _______________ 9
- Drilling the Pocket Holes _____________ 10
APPLICATIONS ___________________ 11-13
ACCESSORIES _____________________ 14
MAINTENANCE _____________________ 15
ENVIRONMENTAL PROTECTION_______ 15
GUARANTEE _______________________ 15
PARTS
- Spare Parts List ____________________ 16
- Spare Parts Diagram ________________ 17
TROUBLE SHOOTING ________________ 18
PH/JIG/BK
PH/JIG/AK
TECHNICAL DATA
Material thickness: Min.
Max.
Material width:
Min.
Screw length:
Drill bit size
Hole pitch
The following symbols are used throughout this
manual:
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
Denotes risk of electric shock.
Refer to the instruction manual of
your power tool.
This unit must not be put into service until it has
been established that the power tool to be
connected to this unit is in compliance with
2006/42/EC (identified by the CE marking on the
power tool).
INTENDED USE
This accessory is to be used with a drill with
minimum 10mm chuck capacity to allow pocket
hole jointing of softwoods and hardwoods.
%
If you require further safety advice,
technical information or spare parts,
please call Trend Technical Support
or visit www.trend-uk.com
-1-
12.7mm
38mm
38mm
25mm-63mm
9.5mm
30mm
50mm
Advertisement
Table of Contents
Related Manuals for TREND PH/JIG/BK
Summary of Contents for TREND PH/JIG/BK
-
Page 1: Table Of Contents
PH/JIG/AK PH/JIG/BK Dear Customer TECHNICAL DATA Thank you for purchasing this Trend product, Material thickness: Min. 12.7mm we hope you enjoy many years of creative and Max. 38mm productive use. Material width: Min. 38mm Please remember to return your guarantee card within 28 days of purchase. - Page 2 PH/JIG/AK PH/JIG/BK SAFETY 5. Consider working environment. Do 17. Don’t abuse the cable. Never carry not use the product in the rain or power tool or accessory by cord or in a damp environment. Keep work pull it to disconnect from the socket.
-
Page 3: Pocket Hole Concept
PH/JIG/AK PH/JIG/BK POCKET HOLE CONCEPT 2 x Pocket hole jig body A pocket hole involves clamping one piece of the material to be joined to the jig and boring one or 2 x Slide Adjusters two counter-bored holes with a special stepped 1 x Single jig clamping pad drill. -
Page 4: Description Of Parts
PH/JIG/AK PH/JIG/BK DESCRIPTION OF PARTS Pocket hole jig body Solid bush drill guide hole Material thickness side scale Guide block workpiece thickness scale Between centres setting scale Drill depth setting scale Single jig clamping pad Twin jig clamping pad Jig placement slide adjuster Hex shank quick release stepped drill Square drive screwdriver bit No.2 x 150mm... -
Page 5: Assembly & Adjustment
PH/JIG/AK PH/JIG/BK ASSEMBLY & ADJUSTMENT Setting up the Jig For Single Column Set-Up For Two Column Set-Up Fitting The Slide Adjusters... -
Page 6: Measuring The Thickness Of Workpiece
PH/JIG/AK PH/JIG/BK Measuring the Thickness of Workpiece Setting the Drill Bit Depth... -
Page 7: Adjusting The Position
PH/JIG/AK PH/JIG/BK Adjusting the Jig Position New Set-Up Repair Set-Up Sliding Adjusters Faced Down Sliding Adjusters Faced Up Setting The Sliding Adjusters For Timber Thickness... -
Page 8: Operation
PH/JIG/AK PH/JIG/BK OPERATION Pocket Hole Spacing Check the collar position is correct before When boring framing material, two pocket holes drilling. If the depth collar is set too deep the should be used to keep the timber from twisting. screw may protrude through the face of the When working with long pieces of timber to jointing piece. -
Page 9: Drilling The Pocket Holes
PH/JIG/AK PH/JIG/BK Drilling the Pocket Holes Do not push hard on the drill until the drill pilot tip of the Boring the counter-bored hole involves drilling drill bit is fully into the work with a stepped drill into one of the joint pieces. - Page 10 ” quick change shank and can be used directly into a drill chuck or more conveniently into a Trend Snappy quick change drill chuck Ref. SNAP/QC. If a torque control screwdriver is not available start to screw with a conventional drill and then...
-
Page 11: Applications
PH/JIG/AK PH/JIG/BK Square Corner Joints – faster and stronger APPLICATIONS than dowel and biscuits. Self clamping whilst Frame Corner Joints – faster and stronger than glue is drying. dowel and biscuits. Self clamping whilst glue is drying. T- Joints – faster and stronger than dowel and biscuits. - Page 12 PH/JIG/AK PH/JIG/BK Angled Joints – eliminates difficult clamping Curved Joints – this uses the same technique up. The joint is created not by cutting each mitre as the angled joint, but the angles will be to half the angle but by cutting angle on one shallower (5°...
- Page 13 PH/JIG/AK PH/JIG/BK Edge to Edge Joints – allows narrow strips Edging of countertops or shelving – quick and to be jointed to create wider boards such as a easy way to join edging onto plywood, MDF or table top. Particle board shelves.
-
Page 14: Accessories
PH/JIG/AK PH/JIG/BK ACCESSORIES MAINTENANCE Please use only Trend original accessories. Please use only Trend original spare parts and accessories. Self Tapping Screws Square Drive The accessory has been designed to operate Fine Thread over a long period of time with minimum of maintenance. - Page 15 PH/JIG/AK PH/JIG/BK WP-PHB/01 WP-PHB/02 WP-PHB/03 Jig placement slide adjuster WP-PHB/04 WP-PHB/06 MANU/PH/BK -15-...
-
Page 16: Spare Parts Diagram
PH/JIG/AK PH/JIG/BK PH/JIG/BK - SPARE PARTS DIAGRAM v1.0 08/2018 -16-... -
Page 17: Trouble Shooting
PH/JIG/BK PH/JIG/AK TROUBLE SHOOTING Fault Cause Remedy n Screw protrudes through Depth collar set too high causing Adjust height of collar on face of mating piece. drill bit to drill too deep. drill bit. Can occur on very hard woods,... - Page 18 RECYCLABLE www.trend-uk.com © Copyright Trend 2019. No part of this publication may be reproduced, stored or transmitted in any form without prior permission. Our policy of continuous improvement means that specifications may change without notice. Trend Machinery and Cutting Tools...
- Page 19 3-in-1 POCKET HOLE JIG Please read these instructions before use. t o o l t e c h n o l o g y...
