Summary of Contents for Gigaset N720

  • Page 1: Table Of Contents

    Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Requirements 2.1 Identifying phone model 2.2 Phone firmware 2.3 DHCP server 2.4 PBXware version 3 Installation 3.1 Power adapter 3.2 Power over Ethernet (PoE) 3.3 Find the phone IP address 3.4 Reset to factory settings 4 Registering phone...
  • Page 2 This Configuration Guide is written as general guide on how to configure the Gigaset phone model N720 to work with PBXware 4.1.

  • Page 3: Requirements

    Make sure that your phone is loaded with appropriate firmware version, 70.110.00.000.00. To find out the firmware version of your Gigaset phone model open a new browser window and enter your phone IP address in order to access the phone web administration interface login screen.

  • Page 4: Power Adapter

    Find out your Gigaset phone IP Address. Enter www.gigaset-config.com in the address field of Your web browser. All Gigaset phones will be displayed on the list with IP addresses. Reset to factory settings This step is not required for brand new out-of-the-box phones, however, if the phone has been already used then it is a must.

  • Page 5: Registering Phone

    UAD settings Navigate to Settings:UAD. Make sure Gigaset UAD is enabled. To check the UAD status click on the edit icon corresponding to your Gigaset phone. Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
  • Page 6 Department to which extension will belong to. Example: Sales. Click on the Save button. Registering Phone This chapter describes how to register Gigaset phone using Hostname or IP Address. Hostname or IP Address Login to phone web administration interface Open a new browser window and enter your phone IP address in order to access the phone...
  • Page 7 Login to phone web administration interface with your password. Please note, factory default login password is: admin. Click on VoIP Providers in the left navigation menu. Click on first Edit button. Enter or set the following details into the respective fields. REQUIRED FIELDS: Domain PBXware IP address or domain name.

  • Page 8: Auto Provisioning

    UAD settings. Navigate to Settings:UAD. Make sure Gigaset UAD is enabled. To check the UAD status click on the edit icon corresponding to your Gigaset phone. Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
  • Page 9 Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages. Example: john.smith@bicomsystems.com Auto Provisioning Set to Yes. MAC Address Enter Gigaset phone MAC address. Example: 7C2F80123456. MAC address can be found at the back of the phone. Click on the Save button. Registering Phone...
  • Page 10 This chapter describes how to register Gigaset phone using DHCP or HTTP. The following topics are covered: DHCP HTTP DHCP Configure DHCP Make sure your DHCP router is configured to use option 66 to automatically instruct phones with the URL for auto provisioning. For more information refer to your router documentation or contact your network administrator.
  • Page 11 Example for Hostname using HTTP: http://abc.bicomsystems.com/prov/%MACD Example for IP Address using HTTP: http://192.168.1.10/prov/%MACD Click Set button. Click on Reboot in the left navigation menu. Click Reboot now button and confirm with OK. You'll have to wait couple of seconds for the configuration to be updated. NOTE: Do not power off your phone.
