BMW R 1200 ST Rider's Manual page 110

7
108
Raise the front wheel, insert
quick-release axle 6 and
tighten to specified torque.
Quick-release axle in
z
axle holder
50 Nm
Tighten axle clamping
screw 5 to the specified
torque.
Quick-release axle
clamp screws
19 Nm
Remove the front wheel
stand.
Slip the brake calipers onto
the brake discs.
with OE BMW Motorrad
Integral ABS:
The cable of the ABS
sensor could chafe
through if it comes into
contact with the brake disc.
Make sure that the ABS
sensor cable is routed snugly
along the front suspension.
Route ABS sensor cable 7
as illustrated here.
Install securing screws 2
and tighten to specified
torque.
Brake caliper to slider
tube
30 Nm
Remove the adhesive tape
from the wheel rim.
