This manual describes the troubleshooting procedures and diagnostic commands that you can use to solve basic problems with the MicroVAX 3100 Model 85, Model 95, and Model 96 systems. This manual supersedes Revision Information: EK–A0719–TM. B01 Digital Equipment Corporation Maynard, Massachusetts...
Page 2
DATE 1995 Digital Equipment Corporation makes no representations that the use of its products in the manner described in this publication will not infringe on existing or future patent rights, nor do the descriptions contained in this publication imply the granting of licenses to make, use, or sell equipment or software in accordance with the description.
Preface This manual describes the troubleshooting procedures and diagnostic commands that you can use to solve basic problems with the MicroVAX™ 3100 Model 85, Model 95, and Model 96 systems. Audience This manual is intended for people who have some experience with computers. Structure of This Manual This manual presents the information you need for solving basic problems with the MicroVAX 3100 Model 85/95/96 system in one chapter.
Page 6
Conventions The following conventions are used in this manual: Convention Description MONOSPACE type Text displayed on the screen is shown in monospace type. italic type Italic type emphasizes important information and indicates the complete titles of manuals. Note A note contains information that is of special importance to the user.
Troubleshooting and Diagnosing Problems This chapter describes the troubleshooting procedures and diagnostic commands that you can use to solve basic problems with the MicroVAX 3100 Model 85, Model 95, and Model 96 systems. It contains information on the following: • Troubleshooting •...
• System unit power cord • Expansion box SCSI cables • Expansion box power cords • ThinWire™ Ethernet cable or standard Ethernet cable 6. Check that the following terminators, if installed, are correctly connected and are not damaged: • SCSI terminators •...
Table 1–1 Basic Troubleshooting Symptom Possible Cause Suggested Solution System Problems The system unit fan is The power cord is not Make sure that all the power cords off or the power light is connected. The power are connected correctly at both off.
Page 10
Table 1–1 (Cont.) Basic Troubleshooting Symptom Possible Cause Suggested Solution System Problems The port to which the Try connecting the terminal to terminal connects may another system. If this solution be faulty. works, the port to which the terminal was connected is faulty. If the terminal still does not operate, it is faulty.
Page 11
Table 1–1 (Cont.) Basic Troubleshooting Symptom Possible Cause Suggested Solution RRD43 Compact Disc Drive Problems The drive does not The disc is upside-down Remove the disc from the tray and accept the disc. in the tray or it is not reinsert it properly.
Page 12
Table 1–1 (Cont.) Basic Troubleshooting Symptom Possible Cause Suggested Solution TZ30 Tape Drive Problems The TZ30 green LED The drive mechanism Press and release the unload flashes rapidly. is faulty or the tape button to clear the fault. If the cartridge is damaged.
Page 13
Table 1–1 (Cont.) Basic Troubleshooting Symptom Possible Cause Suggested Solution TLZ06 and TLZ07 Cassette Tape Drive Problems The system cannot write The write-protect switch If the write-protect LED is on, to the cassette tape. is in the write-protect remove the tape, reset the switch position.
Page 14
Table 1–1 (Cont.) Basic Troubleshooting Symptom Possible Cause Suggested Solution RX™26 Diskette Drive Problems The system cannot read The diskette is not Format the diskette. from or write to the formatted. diskette. The diskette is not Eject the diskette. Try to insert the correctly inserted.
1.3 Diagnostic Tests and Commands There are a number of diagnostic tests and commands that can help you to isolate a problem with the system unit. These tests and commands are as follows: • Power-up tests • Diagnostic tests and utilities •...
1.3.1 Power-Up Tests The system runs the power-up tests each time you turn on the system. After successful completion of tests, the system will either enter console mode or proceed to automatic bootstrap, depending on the HALT action selected by the user.
Page 17
The following example shows a typical display for a system that passes all tests and then enters automatic bootstrap. KA55-A or KA51-A or KA56-A V2.6, VMB 2.15 Performing normal system tests. 74..73..72..71..70..69..68..67..66..65..64..63..62..61..60..59.. 58..57..56..55..54..53..52..51..50..49..48..47..46..45..44..43.. 42..41..40..39..38..37..36..35..34..33..32..31..30..29..28..27.. 26..25..24..23..22..21..20..19..18..17..16..15..14..13..12..11.. 10..09..08..07..06..05..04..03.. Tests completed. Loading system software. (BOOT/R5:0 EZA0) -EZA0 1..0..
Page 18
The following example shows a system with a memory error that only affected one set of memory out of two sets. Because some memory is still usable, the system proceeds to automatic bootstrap if the HALT action is set to a boot condition. KA55-A or KA51-A or KA56-A V2.6, VMB 2.15 Performing normal system tests.
1.3.2 Diagnostic Tests and Utilities The diagnostic tests and utilities are similar to the power-up tests except that the power-up tests enable you to test all the devices in the system, whereas the diagnostic tests and utilities enable you to test single devices and the functions of single devices.
Figure 1–1 (Cont.) Diagnostic Tests A0 User defined scripts A1 Powerup tests, Functional Verify, continue on error, numeric countdown A3 Functional Verify, stop on error, test # announcements A4 Loop on A3 Functional Verify A6 Memory tests, mark only multiple bit errors A7 Memory tests A8 Memory acceptance tests, mark single and multi-bit errors, call A7 A9 Memory tests, stop on error...
Note The following available tests (Table 1–3) are not used on the MicroVAX 3100 Model 85/95/96; they are used only on the MicroVAX 4000 Model 100A/105A, and are listed here to avoid confusion when you see them in the diagnostic test listing (Figure 1–1 ). Table 1–3 MicroVAX 4000-100A/105A Tests Test Name...
Page 23
You can use test 9E with the test number as a parameter to show a list of legal parameters and valid values for the test number. For example, enter T 9E 30 to show a list of legal parameters and valid values for test number 30 (Memory_Init_Bitmap).
1.3.3 Power-Up Error Messages The following are examples of some error messages at power-up. Example 1–1 is a typical example of a failed test. In this case, test E8 failed testing a SYNC (COMM) option. Example 1–1 SYNC Test Failure KA55-A or KA51-A or KA56-A V2.6, VMB 2.15 Performing normal system tests.
Page 25
Example 1–2 represents a case where an additional set of memory SIMMs was added and one of the four SIMMs for the set was not the same type of SIMM as the others. In this example SIMM 1H was either not installed or incorrectly installed.
Page 26
Example 1–3 represents a case where one SIMM of a set was bad. In this example, SIMM 1G was bad or incorrectly installed. Example 1–3 Memory_Count_Pages Test Failure KA55-A or KA51-A or KA56-A V2.6, VMB 2.15 Performing normal system tests. 74..73..72..71..70..69..68..67..66..65..64..63..62..61..60..59..
Page 27
Example 1–4 represents a case where one SIMM of a set is missing or incorrectly installed. In this case, only one set of SIMMs was installed. Since one was missing, there is no usable memory for testing to run to completion. SIMM 1D is missing here.
1.3.4 Configuration Display The configuration display shows the system configuration and the error messages that were detected while the most recent power-up tests, diagnostic tests, and utilities were running. If you add expansion boxes to the system and do not run the power-up tests or appropriate diagnostic test or utility, the configuration display does not recognize the reconfiguration.
Page 29
Note The lines for F0, E8 and EC display only if the applicable option is present. If the system detects errors in the most recent power-up tests and diagnostic utilities, it responds with a configuration display similar to the following: KA55-A or KA51-A or KA56-A V2.6, VMB 2.15 08-00-2B-2B-16-91 80MB...
1.3.5 Error Display You can use the error display to display certain errors detected during the last power-up test or diagnostic utility. To see the error display, enter the following command: >>> SHOW ERROR The system responds with a display similar to the following: ?? 001 CPU_BD 0000 B_Cache Test_35 Subtest_33 Loop_sub_27 Error_type_FF...
1.4 Contacting Digital Services Warning Only authorized service personnel should service the MicroVAX 3100 Model 85/95/96. If you have followed the procedures in this chapter but the problem remains unsolved, your Digital services representative can help you. Before you place your call, follow these steps: 1.
