- Page 1 VAXstation VLC to DEC 3000 Model 300/300L AXP Upgrade Instructions MLO-010693 Order Number: EK–VSAXP–UP. A01...
-
Page 2: Options You Can Upgrade
Options You Can Upgrade Cannot Upgrade Upgrade Expansion SZ03 Boxes: SZ12 SZ16 Hard Disks: RZ23L RZ57 RZ24L RZ24* RZ25* RZ26* RZ55* RZ56* RZ58* Removable TZK10 RX23 Media:* TZ30 RX33 TLZ04 TLZ06 RRD42 RX26 Memory Option: None * Available only in expansion boxes... - Page 3 Options You Can Upgrade Cannot Upgrade Upgrade Monitors VRC16-Cx/Hx VR262-Ax VRM17-Ax/Hx VR290-Dx VR319-Dx** VR297-Dx VR320-Dx** VR299-Dx VRT16-Hx** VRT16-Dx VRT19-Hx** VRT19-Dx VRT13 VR319-Cx VR320-Cx Input Devices: VSxxx-AB VSxxx-AA VSxxx-FA VSxxx-JA VSxxx-GA LK401 LK201 Ethernet Adapter: DECXM-AA ** Available only on the Model 300.
-
Page 4: Check The Box Contents
Check the Box Contents System Kit: Mousepad System Unit Universal Strain Relief Monitor Strap Video Cable SCSI Terminator Documentation Keyboard/Mouse Extension Cable Antistatic Wrist Strap Monitor 10BASE-T Loopback Power Cord Connector Modem Loopback Connector System Power Cord Network Cable Screwdriver Accessory Kit: Upgrade Card... - Page 5 Check the SCSI ID Settings If your DEC 3000 system has factory- installed drives, check the SCSI ID settings on the drives you are upgrading. To find out the SCSI ID settings on your VAXstation drives, enter these commands: • To shut down your system software: $ SYS$SYSTEM:SHUTDOWN •...
- Page 6 Turn Off/Open the VAXstation Turn off the VAXstation system unit by pressing O on the On/Off switch. Caution: After you turn off the system, wait 15 seconds before unplugging the power cord. Unplug all the cables. To open the cover, press firmly on the latches located on the side of the system unit.
- Page 7 Remove/Prepare the Disk Drive Your VAXstation may have an RZ23L or an RZ24L fixed disk drive installed. Locate the small metal clip attached to the disk mounting bracket. • Push in on the metal clip to unlock the bracket, then slide the drive away from the power supply.
- Page 8 Set the SCSI ID on the Drives You need change a SCSI ID setting only if two or more drives have the same setting. Check the SCSI ID setting for the VAXsta- tion drives, which you noted previously. If you need to change a SCSI ID on a drive that is not covered here, see the DEC 3000 Model 300/300L AXP System Hardware Reference Guide.
- Page 9 Set the SCSI ID on the Drives RZ24L Drive SCSI ID Settings: A0 A1 SCSI Settings: MLO-010732...
- Page 10 Insert a Drive Into a Bracket If you are upgrading an RZ23L or RZ24L drive from a VLC to a DEC 3000 300/300L, you must put the drive into either of the brackets included in your accessory kit. • Stand the bracket on its side with the sliding latch up.
-
Page 11: Complete The Upgrade
Complete the Upgrade Follow the instructions in Chapter 2 of the DEC 3000 Model 300/300L AXP Reference Guide to install the fixed disk drive. Follow the instructions in the DEC 3000 Model 300/300L AXP Setting Up Your System card. Test the installation by turning on your system and entering the show device command at the console prompt (>>>). - Page 12 DEC 3000 300/300L pack- ing material. • Attach the return-address label that was in your upgrade kit. • Contact your Digital service representa- tive to upgrade your hardware service contract. © Digital Equipment Corporation 1993. All rights reserved. Printed in U.S.A. S2252...
