User Manual
for
Amron International, Inc.
Amron Model 2810E-2001
Single Lock Chamber Communicator
S/N______________________
1380 Aspen Way, Vista California 92081-8349
United States of America
Phone: (760) 208-6500
Fax (760) 599-3857
email: sales@amronintl.com
web: www.amronintl.com
This manual and the information contained herein are provided for use as an operation and
maintenance guide. No license or rights to manufacture, reproduce, or sell either the manual or
articles described herein are given. Amron International, Inc. reserves the right to change
specifications without notice. Copyright© 2013 Amron International, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2810E-2001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amron 2810E-2001

Summary of Contents for Amron 2810E-2001

  • Page 1 This manual and the information contained herein are provided for use as an operation and maintenance guide. No license or rights to manufacture, reproduce, or sell either the manual or articles described herein are given. Amron International, Inc. reserves the right to change specifications without notice. Copyright© 2013 Amron International, Inc.

  • Page 3: Table Of Contents

    CHAMBER COMMUNICATOR CHECK PROCEDURES ..................15 GENERAL MAINTENANCE ..........................17 TROUBLESHOOTING............................. 19 DRAWINGS ..............................22 FRONT PANEL PARTS LOCATOR, MODEL 2810E-2001 .................. 23 MOUNTING DETAIL, MODEL 2810E-2001 ....................24 PARTS LIST GENERAL ............................ 25 MODEL 2810E-2810E TOP ASSEMBLY ......................26 2810A-FS-01 FIELD SPARES KIT ........................

  • Page 5: Introduction And Specifications

    The first new feature is a digital audio power amplifier which significantly reduces the current draw, nearly doubling the battery life. The 2810E-2001 uses a new audio filtering network for improved sound clarity and communications. An auxiliary audio input allows chamber occupants to listen to audio from a MP3 player while remaining in constant communication with the operator.

  • Page 6: Mechanical Specifications

    Weight With Batteries 2810E-2001 ..................... 11.5 Lbs. (5.2kg) MODEL 2810E-2001 FRONT PANEL All of the controls for the Model 2810E-2001 are located on the front panel including the connectors for the operator handheld microphone or headset, tape recorder and auxiliary audio input.

  • Page 7: Model 2810E-2001 Rear Panel

    (115/230 VAC) battery charger. The battery charger has medical grade electrical isolation for maximum safety to the chamber occupants. ACCESSORIES Amron produces a series of accessories designed to operate with the entire line of AMCOM diving communicators. 1.6.1 Amron Heavy-Duty Headset - Model 2401-28 The Model 2401-28 is a heavy-duty headset with boom microphone.
  • Page 8 The Model 2460-31R features an adjustable boom microphone, vinyl cushioned adjustable ear pads and a spiral cord that can be extended up to 8 feet (2.4 meters). It can be plugged into the headset jacks of most models of Amron Chamber Speakers.
  • Page 9 1.6.11 Amron Inner-Lock Combo Box - Model 3125 The Model 3125 features a talk-back speaker with on/off switch and headset jack that operates in the same manner as the Model 3115. It also includes a sound-...

  • Page 10: Warranty And Service Policy

    90 days from date of shipment. Amron’s obligations under this warranty are limited to the repair of, or replacement of materials at Amron’s discretion. This warranty shall not cover defects which are the result of misuse, negligence, accident, repair, or alterations.

  • Page 11: Controls And Connections

    MODEL 2810E-2001 USER MANUAL CONTROLS AND CONNECTIONS Before using the 2810E-2001 chamber communicator, the operator should be familiar with all the controls and connections. While reading this manual, you will find capitalized words such as PANEL SPEAKER. These words are to remind the reader that additional information can be found in this section of the manual.
  • Page 12 LED will turn off and the 2810E will go into shutdown mode to prevent damaging the communicator or rechargeable battery. It is advised that the 2810E-2001 be connected to an AC outlet as soon as possible once the BATTERY CONDITION INDICATOR starts blinking. While there should be enough time to safely complete a normal diving operation, the exact amount of time is dependent on the age and condition of the sealed lead acid battery.
  • Page 13 If both are used at the same time, the PANEL SPEAKER is active as a microphone. This allows another operation crew member to talk to the occupants using the PANEL SPEAKER even if the operator is away from the 2810E-2001 using the Remote Push-to-Talk Module in 2-Wire mode.

  • Page 14: Chamber Connections

    Full Duplex (4-Wire) mode. WARNING! The AUXILIARY AUDIO INPUT is not electrically isolated from the circuitry of the 2810E-2001. Any external equipment connected to the input should not be AC powered or connected to the AC mains indirectly through any equipment without the proper isolation. Failure to follow this warning may result in electrocution or death.
  • Page 15 MODEL 2810E-2001 USER MANUAL 3.2.3 CHAMBER EARPHONE - This is a dual banana jack (color-coded black) that functions as the output for chamber occupant’s earphone. It is only used when the chamber is in Full Duplex (4-Wire) mode. 2810E-2001 UM...

  • Page 16: Operation

    CHARGING THE BATTERY The Model 2810E-2001 is supplied with an internal sealed lead acid battery. To charge the battery, connect the AC power cord located on the back panel to an AC outlet. The internal battery charger is able to operate on 115 and 230 VAC lines without the user having to make any adjustments.

  • Page 17: Modes Of Operation

    These spikes can exceed 1kV! Such spikes can be high enough to cause the input fuses on the 2810E-2001 internal battery charger to blow and, in extreme cases, actually damage the charger circuitry. Amron has designed this battery charger to isolate such faults to ensure that they will not cause a safety issue for the operator or chamber occupants.
  • Page 18 MODEL 2810E-2001 USER MANUAL 4.3.1 2-WIRE Turn power switch to ON, turn speaker switch to ON, and adjust both volume controls to mid-scale. The operator has to depress PUSH-TO-TALK BUTTON in order to talk to chamber occupants. Operator and occupants talk to each other...

  • Page 19: Maintenance

    MODEL 2810E-2001 USER MANUAL MAINTENANCE The following section describes the procedures for checking the operation of your 2810E-2001 chamber communicator, general maintenance procedures, and how to troubleshoot common problems. CHAMBER COMMUNICATOR CHECK PROCEDURES The following are a series of step-by-step procedures to perform a functional check of your 2810E-2001 communicator using only a headset.
  • Page 20 If that does not resolve the problem, then go to the troubleshooting section to determine the cause. Identify the microphone and headset leads. When using an Amron headset, the microphone is the red banana plug and the headset is the black banana plug.

  • Page 21: General Maintenance

    Select a work area where the communicator and wires connecting to it are out of everyone's way so it does not get knocked over. The 2810E-2001 rechargeable battery should be recharged after use or as soon as possible when the BATTERY CONDITION INDICATOR starts blinking.
  • Page 22 MODEL 2810E-2001 USER MANUAL 19. Perform Power On - Battery Check 20. Plug 2810E-2001 into AC power and allow battery to charge for 4 hours (depending of the age of the battery and the surrounding temperature). 5.2.2 RECOMMENDED MAINTENANCE SCHEDULE The following sections outline the recommended scheduled maintenance for the 2810E-2001.

  • Page 23: Troubleshooting

    3.15 Amp, 250V, Fast Acting. Close the front panel; re-install the screws and re-test the communicator. If the communicator still appears dead, contact Amron per section 2.2 for further assistance. 5.3.3 LOW VOLUME Check the volume control settings and adjust if necessary.
  • Page 24 Amron per section 2.2 for further assistance. 5.3.7 FEEDBACK - FULL DUPLEX (4-WIRE) MODE There are two forms of feedback that can affect the 2810E-2001: acoustic feedback and cable crosstalk. Acoustic feedback occurs when an active microphone is close enough to pick up and amplify the signal from a speaker or earphone.
  • Page 25 Common sources are feedback between the operator's headset microphone and the PANEL SPEAKER of the 2810E-2001. If the operator wants to operate with the headset and leave the PANEL SPEAKER on, Amron recommends the operator move away from the 2810E-2001 by using the Amron Model 2822-28 Remote Walk-and-Talk Module.

  • Page 26: Drawings

    The corresponding parts lists for each drawing are detailed in the parts lists section, or are included as part of the drawing. All drawings are at their current revision level as of the date of printing. Amron reserves the rights to revise the documentation without notification. 2810E-2001 UM...

  • Page 27: Front Panel Parts Locator, Model 2810E-2001

    MODEL 2810E-2001 USER MANUAL FRONT PANEL PARTS LOCATOR, MODEL 2810E-2001 2810E-2001 UM REV 3.0...

  • Page 28: Mounting Detail, Model 2810E-2001

    MODEL 2810E-2001 USER MANUAL MOUNTING DETAIL, MODEL 2810E-2001 2810E-2001 UM REV 3.0...

  • Page 29: Parts List General

    MODEL 2810E-2001 USER MANUAL PARTS LIST GENERAL The parts lists include both mechanical and electrical parts. The following information will be useful in interpreting data which is not self-explanatory. REVISIONS The parts lists in this manual are for the current model of chamber communicator as of the printing date.

  • Page 30: Model 2810E-2810E Top Assembly

    MODEL 2810E-2001 USER MANUAL MODEL 2810E-2810E TOP ASSEMBLY Reference Part Number Description 2810E-2001-001 Front Panel, Model 2810E-2001 2001-005 Bracket Support Rail 2820-015 Rail Short Card Support 2001-022 Chassis Battery Box Universal 2001-007 Handle Complete Black 570-1000-03 PCA, Single Chamber Communicator Speaker, 3.5 inch, 8Ω, 16W...

  • Page 31: 2810A-Fs-01 Field Spares Kit

    MODEL 2810E-2001 USER MANUAL Reference Part Number Description 2-520194-2 Terminal, Slide, 0.187 Series, 18-22 AWG 3500 Cable Tie, Nylon, 3/32inX3.5in 2405-28 Microphone, Handheld w/PTT Switch 2810E-2001-UM User Manual, 2810E-2001 TAT-1/8 Heat Shrink Tubing, 1/8in, Black 8/18-22 Terminal, Ring, #8, 18-22 AWG...
