Amron 2810E User Manual

1-diver communicator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
for
Amron International, Inc.
Amron Model 2810E and 2810E-1
1-Diver Communicator
S/N______________________
1380 Aspen Way, Vista California 92081-8349
United States of America
Phone: (760) 208-6500
Fax (760) 599-3857
email: sales@amronintl.com
web: www.amronintl.com
This manual and the information contained herein are provided for use as an operation and
maintenance guide. No license or rights to manufacture, reproduce, or sell either the manual or
articles described herein are given. Amron International, Inc. reserves the right to change
specifications without notice.
Copyright© 2013 Amron International, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2810E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amron 2810E

Summary of Contents for Amron 2810E

  • Page 1 This manual and the information contained herein are provided for use as an operation and maintenance guide. No license or rights to manufacture, reproduce, or sell either the manual or articles described herein are given. Amron International, Inc. reserves the right to change specifications without notice.

  • Page 3: Table Of Contents

    AMRON PUSH-TO-TALK MICROPHONE - MODEL 2405-28 ............5 AMRON REMOTE WALK-AND-TALK MODULE - MODEL 2822-28 ..........5 AMRON REMOTE PUSH-TO-TALK MODULE - MODEL 2821-28 ..........5 AUDIO ADAPTOR CABLE - AMRON PART NUMBER 180-1000-00 ........... 5 CONTROLS AND CONNECTIONS ...................... 6 TENDER AND DIVER CONTROLS ....................6 TENDER CONNECTIONS ......................
  • Page 4 MODEL 2810E USER MANUAL DRAWINGS ............................32 FRONT PANEL PARTS LOCATOR, MODELS 2810E & 2810E-1 ..........33 CASE PARTS LOCATOR, MODELS 2810E & 2810E-1 ............... 34 PARTS LIST GENERAL ........................35 MODEL 2810E TOP ASSEMBLY ....................36 MODEL 2810E-1 TOP ASSEMBLY ....................36 2810A-FS-01 FIELD SPARES KIT ....................

  • Page 5: Introduction And Specifications

    The 2810E uses a new audio filtering network for improved sound clarity and communications. An auxiliary audio input allows the diver to listen to audio from an MP3 player while remaining in constant communication with the tender.

  • Page 6: Mechanical Specifications

    2810E-1 ........................ 7 Lbs. (3.2kg) MODEL 2810E WITH BATTERY CHARGER The Model 2810E comes equipped with a sealed lead-acid rechargeable battery along with the 2823-603 universal input (115/230 VAC) battery charger. The 2823-603 Battery Charger has medical grade electrical isolation for maximum safety to the diver. Carefully read section 4.1 before using any other external power source.

  • Page 7: Model 2810E-1

    MODEL 2810E USER MANUAL MODEL 2810E-1 The Model 2810E-1 comes equipped with two lantern style, 6 Volt alkaline batteries. The unit can be operated using an external power supply as described in the operation section of this manual. Carefully read sections 3.4 and 4.3 before using any external power source.

  • Page 8: Warranty And Service Policy

    90 days from date of shipment. Amron’s obligations under this warranty are limited to the repair of, or replacement of materials at Amron’s discretion. This warranty shall not cover defects which are the result of misuse, negligence, accident, repair, or alterations.

  • Page 9: Accessories

    MODEL 2810E USER MANUAL ACCESSORIES Amron produces a series of accessories designed to operate with the entire line of AMCOM diving communicators. AMRON HEAVY-DUTY HEADSET - MODEL 2401-28 The Model 2401-28 is a heavy-duty headset with boom microphone. It comes equipped with color-coded, dual banana plugs that mate directly to AMCOM diver communicators.

  • Page 10: Controls And Connections

    MODEL 2810E USER MANUAL CONTROLS AND CONNECTIONS Before using the 2810E diver communicator, the tender should be familiar with all the operating controls and connections. While reading this manual, you will find capitalized words such as PANEL SPEAKER. These words are to remind the reader that additional information can be found in this section of the manual.

  • Page 11: Tender Connections

    LED will start blinking at a rate of about once per second. When the battery reaches its end-of-charge, the LED will turn off and the 2810E will go into shutdown mode to prevent damaging the communicator or rechargeable battery. It is advised that the 2810E with rechargeable battery be connected to the charger as soon as possible once the BATTERY CONDITION INDICATOR starts blinking.
  • Page 12 PANEL SPEAKER and the microphone if the tender is near the 2810E. To prevent this, the PANEL SPEAKER can be turned off using the SPEAKER SWITCH. Another option is to move the tender away from the 2810E by using the Amron Model 2822-28 Walk-and-Talk Module accessory.

  • Page 13: Diver Connections

    If both are used at the same time, the PANEL SPEAKER is active as a microphone. This allows a crew member to talk to the diver using the PANEL SPEAKER even if the tender is away from the 2810E using the Remote Push-to- Talk Module in 2-Wire mode.

  • Page 14: Rear Panel Connections

    REAR PANEL CONNECTIONS 4.4.1 EXTERNAL BATTERY JACK - The 2810E can be powered using an external battery or power supply via the two color coded TIP jacks. The red TIP jack is the positive power input and the black is the negative power input. The input voltage must be between 9 and 18 VDC and must be able to supply a peak current of 3 Amps for proper operation.
  • Page 15 MODEL 2810E USER MANUAL WARNING! The EXTERNAL BATTERY input can be used to recharge the 2810E rechargeable sealed lead acid battery. It is strongly advised to use the provided Amron External Charger, Model 2823-603, to charge or operate the communicator. This charger has been designed with the necessary electrical isolation to prevent dangerous currents from the AC lines from reaching the diver.

  • Page 16: Drawing, 2-Wire Connections

    MODEL 2810E USER MANUAL DRAWING, 2-WIRE CONNECTIONS 2810E UM REV 7.0...

  • Page 17: Drawing, Full Duplex (4-Wire) Connections

    MODEL 2810E USER MANUAL DRAWING, FULL DUPLEX (4-WIRE) CONNECTIONS 2810E UM REV 7.0...

  • Page 18: Drawing, Push-To-Talk Microphone Connections

    MODEL 2810E USER MANUAL DRAWING, PUSH-TO-TALK MICROPHONE CONNECTIONS 2810E UM REV 7.0...

  • Page 19: Operation

    MODEL 2810E USER MANUAL OPERATION The 2810E comes in a yellow, rugged plastic case. To gain access to the front panel, open the case by releasing both latches on the front of the unit. To gain access to the battery compartment, turn the unit over and release both latches on the front of the unit.

  • Page 20: Operating On Ac Power

    2810E with an external AC power supply. Review all warnings in this section and section 3.4 before using an AC power supply. It is strongly advised that the 2810E only be operated for AC Power when using the Amron Model 2823-603 Battery Charger. Amron has designed the 2823-603 with medical grade electrical isolation that prevents any possible leakage of AC current into the 2810E communicator.
  • Page 21 To connect the diver in 2-Wire mode, connect the communication umbilical wires to the DIVER MICROPHONE binding post jack on the 2810E as shown in the wiring drawing in section 3.5. If the umbilical uses a banana plug, simply insert the plug into the binding post jack.
  • Page 22 SPEAKER SWITCH should be turned off to prevent acoustic feedback. Acoustic feedback can also be avoided by moving the tender away from the 2810E by using the Amron Model 2822-28 Remote Walk-and-Talk Module. In this way, the PANEL SPEAKER can allow other members of the diving crew to monitor the dive operation or to communicate to the diver by pressing the PUSH- TO-TALK BUTTON and talking into the speaker.
  • Page 23 MODEL 2810E USER MANUAL TENDER TO DIVER VOLUME - While tender is talking, tender adjusts this volume control to a comfortable level for the diver. If the AUXILIARY AUDIO INPUT will be used, the volume level of the external audio device should not be higher than the tender’s voice.

  • Page 24: Maintenance And Troubleshooting

    The following are a series of step-by-step procedures to perform a functional check of your 2810E communicator using only a headset. These steps check all communication functions of the 2810E in both 2-Wire and Full Duplex (4-Wire) mode. If the communicator checks out using these procedures, then any communication problems are probably located somewhere else in the system setup.
  • Page 25 If that does not resolve the problem, then go to the troubleshooting section to determine the cause. Identify the microphone and headset leads. When using an Amron headset, the microphone is the red banana plug and the headset is the black banana plug.

  • Page 26: General Maintenance

    MODEL 2810E USER MANUAL GENERAL MAINTENANCE The 2810E diver communicator is designed to provide years of continuous, failure-free service when properly used and maintained. There are a few important things that the user can do to extend the life of their equipment Handle the diver communicator with care.

  • Page 27: Troubleshooting

    The battery voltage can be measured independently using a Voltmeter by measuring the voltage across the EXTERNAL BATTERY JACK. The voltage has to be 9 Volts or greater for the 2810E with rechargeable battery to operate. It is recommended that the 2810E be recharged for at least 10 hours if the measured voltage is less than 12 Volts (depending on the age of the battery and the surrounding temperature).
  • Page 28 MODEL 2810E USER MANUAL The voltage has to be greater than 6.5 Volts for the 2810E-1 with alkaline batteries to operate. It is recommended that the battery be replaced if the voltage is below 10 Volts. Before replacing either battery, the battery connections should be checked by opening the battery compartment and inspecting the wires.
  • Page 29 Amron per section 2.2 for further assistance. 6.3.8 FEEDBACK - FULL DUPLEX (4-WIRE) MODE There are two forms of feedback that can affect the 2810E: acoustic feedback and cable crosstalk. Acoustic feedback occurs when an active microphone is close 2810E UM...
  • Page 30 Common sources are feedback between the tender's headset microphone and the PANEL SPEAKER of the 2810E. If the tender wants to operate with the headset and leave the PANEL SPEAKER on, Amron recommends the tender move away from the 2810E by using the Amron Model 2822-28 Remote Walk-and-Talk Module.

  • Page 31: Full Duplex (4-Wire) - What, Why And How

    MODEL 2810E USER MANUAL FULL DUPLEX (4-WIRE) - WHAT, WHY AND HOW Amron has designed the AMCOM Full Duplex (4-WIRE) mode from the ground up, taking advantage of state-of-the-art electronics technology to provide a superior hard-wire communication experience. Full Duplex (4-Wire) mode has the following advantages: •...

  • Page 32: What Is Full Duplex (4-Wire)

    On the surface, a tender using a headset may get some acoustic feedback via the PANEL SPEAKER. The solution is to put some distance between the tender and the PANEL SPEAKER by using the Amron Model 2822-28 Walk-and-Talk Module accessory. Alternatively, the PANEL SPEAKER can be turned off using the SPEAKER SWITCH located on the front panel.

  • Page 33: Why Full Duplex (4-Wire)

    Amron Diver Communicator uses an independent microphone amplifier for each diver circuit as well as for the tender. This allows Amron Diver Communicators to use the power of common-mode rejection to cancel any coupled noise for each microphone as well as providing less loading of the microphone than in 2-Wire mode.

  • Page 34: How Do You Use Full Duplex (4-Wire)

    MODEL 2810E USER MANUAL HOW DO YOU USE FULL DUPLEX (4-WIRE) In order to use Amron's Full Duplex (4-Wire) mode, you need the following items:  An AMCOM series diver communicator  A good quality dive communication cable with four wires (two twisted wire pairs) like Amron's CC1 ...
  • Page 35 To revert back to 2-Wire mode, simply remove black banana plug from DIVER EARPHONE (black) jack and plug it on top of DIVER MICROPHONE (red) plug. Things to keep in mind when using Amron's AMCOM diver communicators: With the AMCOM diver communicators you can mix 2-Wire and Full Duplex (4-Wire) modes of operation.

  • Page 36: Drawings

    The corresponding parts lists for each drawing are detailed in the parts lists section, or are included as part of the drawing. All drawings are at their current revision level as of the date of printing. Amron reserves the rights to revise the documentation without notification. 2810E UM...

  • Page 37: Front Panel Parts Locator, Models 2810E & 2810E-1

    MODEL 2810E USER MANUAL FRONT PANEL PARTS LOCATOR, MODELS 2810E & 2810E-1 2810E UM REV 7.0...

  • Page 38: Case Parts Locator, Models 2810E & 2810E-1

    MODEL 2810E USER MANUAL CASE PARTS LOCATOR, MODELS 2810E & 2810E-1 2810E UM REV 7.0...

  • Page 39: Parts List General

    MODEL 2810E USER MANUAL PARTS LIST GENERAL The parts lists include both mechanical and electrical parts. The following information will be useful in interpreting data which is not self-explanatory. REVISIONS The parts lists in this manual are for the current model of diver communicator as of the printing date.

  • Page 40: Model 2810E Top Assembly

    MODEL 2810E USER MANUAL MODEL 2810E TOP ASSEMBLY Reference Part Number Description 570-1000-02 P.C. Card Assembly 2810E-300 Case Assembly 2810E-400 Front Panel Assembly Amcom I 4-40x1/2SSPHP Screw 4-40 1/2" SS PHP 4NUTSSL Nut Locking 4-40 S/S 2890-05 Battery Rechargeable 12v 7amp...

  • Page 41: 2810A-Fs-01 Field Spares Kit

    MODEL 2810E USER MANUAL 2810A-FS-01 FIELD SPARES KIT Reference Part Number Description Quantity 105-0603-001 Jack, Tip Black 105-0602-001 Jack, Tip Red 1498-103 Jack, Banana Black 1498-102 Jack, Banana Red 1498-107 Jack, Banana Yellow 14002B 5-Way Binding Post Black 14002R 5-Way Binding Post Red...

  • Page 42: 2810E-300M Case Assembly Components

    MODEL 2810E USER MANUAL 2810E-300M CASE ASSEMBLY COMPONENTS Reference Part Number Description 1120-101-240 Case 1120-PANEL-FRAME Frame 105-0602-001 Jack Tip Red 105-0603-001 Jack Tip Black 1498-103 Jack Banana Black 1498-107 Jack Banana Yellow 1498-102 Jack Banana Red 14002R 5-Way Binding Post (Red)

  • Page 43: 2810E-400M Front Panel Assembly Components

    MODEL 2810E USER MANUAL 2810E-400M FRONT PANEL ASSEMBLY COMPONENTS Reference Part Number Description 2810E-001 Panel Front Amcom 100-0000-00 Speaker 3.5" 1w 8 Ohm 16w 7580K6 Switch Toggle SPST . 5168 Seal Half Boot Toggle Gray LEDGREEN Led Green Bright 6-32x3/8HSBHC Screw 6-32 3/8"...
