Amron 2830R/24 Series User Manual

Three diver rack mount communicator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
For
Amron International, Inc.
Model 2830R/24/XX
Three Diver Rack Mount Communicator
S/N ____________________
1380 Aspen Way, Vista California 92081-8349
United States of America
Phone: (760) 208-6500
Fax (760) 599-3857
Email:
sales@amronintl.com
Web:
www.amronintl.com
This manual and the information contained herein are provided for use as an operation and maintenance
guide. No license or rights to manufacture, reproduce, or sell either the manual or articles described
herein are given. Amron International, Inc. reserves the right to change specifications without notice.
Copyright© 2015 Amron International, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2830R/24 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Amron 2830R/24 Series

Summary of Contents for Amron 2830R/24 Series

  • Page 1 This manual and the information contained herein are provided for use as an operation and maintenance guide. No license or rights to manufacture, reproduce, or sell either the manual or articles described herein are given. Amron International, Inc. reserves the right to change specifications without notice. Copyright© 2015 Amron International, Inc.

  • Page 3: Table Of Contents

    2830R THREE DIVER COMMUNICATOR USER MANUAL TABLE OF CONTENTS INTRODUCTION AND SPECIFICATIONS ..................1 Introduction ............................ 1 Electrical Specifications ........................ 1 Mechanical Specifications ......................1 Amcom III Model 2830R/24 Diver Communicator................. 2 WARRANTY AND SERVICE POLICY ....................3 Limited Warranty ........................... 3 Service Policy ..........................
  • Page 4 2830R THREE DIVER COMMUNICATOR USER MANUAL DRAWINGS ............................35 Parts Identifier, Front Panel Model 2830R/24 ................36 Parts Identifier, Options /26DSP3, /28A, -4002 ................37 PARTS LIST GENERAL ........................38 Amcom III Rackmount Model 2830R/24 ..................39 Amcom III Rack Mount, Unscrambler 2830R/24/26DSP3 ............39 Amcom III Model –...

  • Page 5: Introduction And Specifications

    2830R THREE DIVER COMMUNICATOR USER MANUAL INTRODUCTION AND SPECIFICATIONS Introduction The 2830R/24 AMCOM III Rack Mount Diver Communicator is a full featured, three-diver, hardwire communicator that uses state-of-the-art electronics to provide clear and reliable communications. The 2830R24 is designed for integration into a standard 19 inch equipment rack and all necessary connections can be made via the front panel jack or rear mounted MS connector.

  • Page 6: Amcom Iii Model 2830R/24 Diver Communicator

    2830R THREE DIVER COMMUNICATOR USER MANUAL Amcom III Model 2830R/24 Diver Communicator The front panel contains all the controls and connections required to operate the communicator. It is intended that the divers will be connected to the communicator using the rear chassis MS connector but the front panel 5-way binding post allows for ad-hoc connections when required.

  • Page 7: Warranty And Service Policy

    Amron literature covering this product. Amron’s obligation under this warranty is limited to the repair of or replacement, at Amron’s option, of defective material. This warranty shall not cover defects which are the result of misuse, negligence, accident, repair or alterations.

  • Page 8: Options And Accessories

    2830R THREE DIVER COMMUNICATOR USER MANUAL OPTIONS AND ACCESSORIES The following options are available to customize the AMCOM communicator. Options have to be ordered at the time of purchase or the communicator has to be returned to AMRON for the option to be installed. Options Model /26DSP3 –...
  • Page 9 2830R THREE DIVER COMMUNICATOR USER MANUAL Model 2822-28 – Amron Remote Walk-And-Talk Module 3.2.4 Designed for Full Duplex (4-Wire) applications, the Model 2822-28 provides the tender with mobility around the dive site while maintaining communications with the diver. It comes equipped with a small clip-on belt module that contains the connectors for the headset, and 25 feet (7.6 meters) of lightweight flexible cable.
  • Page 10 2830R THREE DIVER COMMUNICATOR USER MANUAL wiring, chamber environmental conditioning unit wiring and electrical penetrator adaptor all together in a single pre-wired, pre-tested housing. Model 3126 – Amron Outer-Lock Combo Box 3.2.11 The Model 3126 features a talk-back speaker with on/off switch and headset jack that operates in the same manner as the Model 3115.

  • Page 11: Tender And Diver Controls And Connections

    2830R THREE DIVER COMMUNICATOR USER MANUAL TENDER AND DIVER CONTROLS AND CONNECTIONS Before using the 2830R/24 diver communicator, the tender should be familiar with all the operating controls and connections. While reading this manual, you will find capitalized words such as PANEL SPEAKER.

  • Page 12: Tender Connections

    If the tender requires more mobility at the dive site, the Amron Model 2821-28 Remote Push-to-Talk Module can be used to extend the headset cable. It includes a push-to-talk button on a clip- on belt module and comes standard with 25 feet (7.6 meters) of cable (custom...

  • Page 13: Diver Controls

    2830R THREE DIVER COMMUNICATOR USER MANUAL – This is a dual banana jack (color-coded red) that Tender Microphone Jack 4.2.2 functions as the microphone input from the tender's headset. It is only used if the tender is in Full Duplex (4-Wire) mode. On the 2830R/24, the TENDER MICROPHONE VOLUME control adjusts the sensitivity of the input.

  • Page 14: Other Connections

    2830R THREE DIVER COMMUNICATOR USER MANUAL SPEAKER unless the PUSH-TO-TALK BUTTON or PUSH-TO-TALK JACK is activated. – This is a dual 5-way binding post jack (color-coded black) that Diver Earphone 4.4.2 functions as the output for the diver's earphone. It is only used when the diver is in Full Duplex (4-Wire) mode.

  • Page 15: Option Controls: Helium Speech Unscrambler /26Dsp3

    2830R THREE DIVER COMMUNICATOR USER MANUAL Option Controls: Helium Speech Unscrambler /26DSP3 The controls for the DSP3 Helium Speech Unscrambler (HSU) are located in the section immediately right of the DIVER 3 controls on the front panel. – Allows the selection of air (OFF) or helium (ON) operation. In On/Off Switch 4.7.1 the OFF position, the divers’...
  • Page 16 2830R THREE DIVER COMMUNICATOR USER MANUAL – Adjusts the listening volume and turns the unit “OFF” On/Off-Volume Control 4.8.3 when it is turned completely upwards. Talk Push Button – 4.8.4 This button is located on the top of the unit and is labeled TALK.

  • Page 17: Drawing, 2-Wire Connections

    2830R THREE DIVER COMMUNICATOR USER MANUAL Drawing, 2-Wire Connections 2830R-UM REV 5.0...

  • Page 18: Drawing, Full Duplex (4-Wire) Connections

    2830R THREE DIVER COMMUNICATOR USER MANUAL Drawing, Full Duplex (4-Wire) Connections 4.10 2830R-UM REV 5.0...

  • Page 19: Drawing, Push-To-Talk Microphone Connections

    2830R THREE DIVER COMMUNICATOR USER MANUAL Drawing, Push-To-Talk Microphone Connections 4.11 2830R-UM REV 5.0...

  • Page 20: Drawing, Operator Connections, Headset

    2830R THREE DIVER COMMUNICATOR USER MANUAL Drawing, Operator Connections, Headset 4.12 2830R-UM REV 5.0...

  • Page 21: Installation And Operation

    1kV! Such spikes can be high enough to cause the input fuses on the internal battery charger to blow and, in extreme cases, actually damage the charger circuitry. Amron has designed this battery charger to isolate such faults to ensure that they will not cause a safety issue for the diver or tender.
  • Page 22 In 2-wire mode the tender must press the Push-to-talk Switch to be heard. If you are using the Amron Remote Push-to-Talk, Model 2821-28, the tender may press the Push-to-talk Switch on the belt module.

  • Page 23: Volume Controls - 2-Wire

    2830R/24 by using the Amron Model 2822-28 Remote Walk-and-Talk Module. In this way, the PANEL SPEAKER can allow other members of the diving crew to monitor the dive operation or to communicate to the diver by pressing the PUSH-TO-TALK BUTTON and talking into the speaker.

  • Page 24: Other Diver Controls - 2-Wire

    2830R THREE DIVER COMMUNICATOR USER MANUAL Diver To Tender 5.4.2 While diver is talking, tender adjust this volume control to a comfortable hearing level. Other Diver Controls – 2-Wire PTT All Divers Switch 5.5.1 Push-to-talk to All Divers switch is located on the left bottom corner below Power ON/OFF switch.

  • Page 25: Other Tender Controls

    Connect tender headset earphones to Headset (input), and headset microphone to Tender Microphone (input). Turn speaker off to avoid acoustic feedback. Operation with speaker is possible by extending tender's headset away from the speaker. Use Amron Model 2822-28 headset extension cable (25 foot).

  • Page 26: Options

    Amron’s advanced NOISE REDUCTION FILTER (NRF) incorporates a complex DSP algorithm which filters out background noise while allowing the diver’s speech to be clear and intelligible. Amron’s NRF automatically captures the frequency spectrum of applied background noise within the audio frequency bandwidth and reduces it without affecting the diver’s speech.
  • Page 27 2830R THREE DIVER COMMUNICATOR USER MANUAL At power-up, all the controls should be in the minimum (far left) position. Have the diver speak and adjust the DEPTH CONTROL as necessary to achieve the best speech quality. Then adjust the TREBLE BOOST as necessary to improve the quality.

  • Page 28: Maintenance And Troubleshooting

    The following are a series of step-by-step procedures to perform a functional check of your 2830R/24 series communicator using only a headset. These steps check all communication functions in both 2-Wire and Full Duplex (4-Wire) mode. If the communicator checks out using these procedures, then any communication problems are probably located somewhere else in the system.

  • Page 29: General Maintenance

    If that does not resolve the problem, then go to the troubleshooting section to determine the cause. 4. Identify the microphone and headset leads. When using an Amron headset, the microphone is the red banana plug and the headset is the black banana plug.

  • Page 30: Recommended Maintenance Schedule

    6.3.4 Yearly Check For maximum service life, it is recommended that the diver communicator be sent back to Amron for a yearly check. 6.3.5 Long Term Storage If the diver communicator is to be stored for a period greater than 30 days, it is recommended that it be stored in a cool dry location.

  • Page 31: Troubleshooting

    2830R THREE DIVER COMMUNICATOR USER MANUAL Troubleshooting Most problems are usually simple issues that can often be found by careful inspection of the diver communicator, diving umbilical, and diver helmet wiring. The following section will describe the troubleshooting procedure for several common issues. If these sections do not cover your particular issue, it is recommended that the diving umbilical be disconnected from the diver communicator and the check-out procedures in section 6.1 be conducted.
  • Page 32 If the fuse is open, replace with the same type: 3.15 Amp, 250V, Fast Acting. Close the lid; re-install the screws and re- test the communicator. If the communicator still appears dead, contact Amron per section 3.2 for further assistance.
  • Page 33 If this does not solve the problem and the umbilical cannot be immediately replaced, then operate in 2-Wire mode until a replacement umbilical can be used. Amron strongly recommends the use of the Amron CC1 communication cable. It has been specially designed for clear communications and long service life.
  • Page 34 Open the front panel and inspect as described in section 7.3. If that does not resolve the problem then contact Amron per section 2.2 for further assistance. 2830R-UM...

  • Page 35: Full Duplex (4-Wire) - What, Why And How

    2830R THREE DIVER COMMUNICATOR USER MANUAL FULL DUPLEX (4-WIRE) - WHAT, WHY AND HOW Amron has designed the AMCOM Full Duplex (4-WIRE) mode from the ground up, taking advantage of state-of-the-art electronics technology to provide a superior hard wire communication experience.

  • Page 36: What Is Full Duplex (4-Wire)

    On the surface, a tender using a headset may get some acoustic feedback via the PANEL SPEAKER. The solution is to put some distance between the tender and the PANEL SPEAKER by using the Amron Model 2822-28 Walk-and-Talk Module accessory. Alternatively, the PANEL SPEAKER can be turned off using the SPEAKER SWITCH located on the front panel.

  • Page 37: Why Full Duplex (4-Wire)

    Amron Diver Communicator uses an independent microphone amplifier for each diver circuit as well as for the tender. This allows Amron Diver Communicators to use the power of common-mode rejection to cancel any coupled noise for each microphone as well as providing less loading of the microphone than in 2-Wire mode.
  • Page 38 To revert back to 2-Wire mode, simply remove black banana plug from DIVER EARPHONE (black) jack and plug it on top of DIVER MICROPHONE (red) plug. Things to keep in mind when using Amron's AMCOM diver communicators: With the AMCOM diver communicators you can mix 2-Wire and Full Duplex (4-Wire) modes of operation.

  • Page 39: Drawings

    2830R THREE DIVER COMMUNICATOR USER MANUAL DRAWINGS The following drawings illustrate the electrical and mechanical details of the AMCOM III Diver Communications. The corresponding parts lists for each drawing are detailed in the parts lists section, or are included as part of the drawing. 2830R-UM REV 5.0...

  • Page 40: Parts Identifier, Front Panel Model 2830R/24

    2830R THREE DIVER COMMUNICATOR USER MANUAL Parts Identifier, Front Panel Model 2830R/24 2830R-UM REV 5.0...

  • Page 41: Parts Identifier, Options /26Dsp3, /28A, -4002

    2830R THREE DIVER COMMUNICATOR USER MANUAL Parts Identifier, Options /26DSP3, /28A, -4002 2830R-UM REV 5.0...

  • Page 42: Parts List General

    The parts lists in this manual are for the current model of diver communicator as of the printing date. To Order Replacement Parts Contact: Amron international, Inc. 1380 Aspen Way, Vista, California, 92081 U.S.A. Telephone: (760) 208-6500 Fax: (760) 599-3857 Email: sales@amronintl.com...

  • Page 43: Amcom Iii Rackmount Model 2830R/24

    2830R THREE DIVER COMMUNICATOR USER MANUAL Amcom III Rackmount Model 2830R/24 REFERENCE PART NUMBER DESCRIPTION 2832-203-03 PC CARD ASSEMBLY AMCOM III 2830R-400 AMCOM III RM FRONT PANEL ASSBY 2405-28 MICROPHONE PUSH TO TALK 2890-04 BATTERY RECHARGE 6V GEL 5AMP MS-3106A-28-16P MS CONN CABLE 20 PIN M MS-3057-16A MS CABLE CLAMP 24/28 SHELLS...

  • Page 44: Sub Assembly 2830R/26-400M-Dsp3, Front Panel Assembly

    2830R THREE DIVER COMMUNICATOR USER MANUAL REFERENCE PART NUMBER DESCRIPTION 14002R 5-WAY BINDING POST (RED) 91A1AB24B15 POTENTIOMETER 10K LINEAR 1498-103 JACK BANANA BLACK 1498-102 JACK BANANA RED 1498-107 JACK BANANA YELLOW KLN-500B-1/4 KNOB BLACK AL .5DIA .25INSHAFT LEDGREEN LEDGREEN BRITE LT2462-24-D15 LED BI-COLOR RED/GREEN LEDHOLDER-BLK.25...

  • Page 45: 28Xxr-Fs-01 Spares Kit For 2830R/24

    2830R THREE DIVER COMMUNICATOR USER MANUAL 28XXR-FS-01 Spares Kit For 2830R/24 PART # DESCRIPTION KLN-500B-1/4 KNOB BLACK AL .5DIA .25IN SHAFT 1498-102 JACK BANANA RED 1498-103 JACK BANANA BLACK 1498-107 JACK BANANA YELLOW 14002B 5-WAY BINDING POST (BLACK) 14002R 5-WAY BINDING POST (RED) 91A1AB24B15 POTENTIOMETER 10K LINEAR M-2786...
