OWNER'S/OPERATOR'S MANUAL
MANUAL DEL PROPIETARIO U OPERADOR
Mister
Atomizadore
MD830-1
L i s e z e t a s s i m i l e z l a t o t a l i t é d e c e m a n u e l a v a n t d ' u t i l i s e r c e t a p p a r e i l .
L e a y e n t i e n d a e s t e m a n u a l a f o n d o , a n t e s d e u s a r e s t e a p a r a t o .

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD830-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maruyama MD830-1

Summary of Contents for Maruyama MD830-1

  • Page 1 Atomizadore MD830-1 L i s e z e t a s s i m i l e z l a t o t a l i t é d e c e m a n u e l a v a n t d ' u t i l i s e r c e t a p p a r e i l .
  • Page 2 Important safety instructions will be identified by the following safety symbol: Failure to comply with the instructions in this manual may result in serious injury or death. For additional assistance, contact any local authorized Maruyama dealer or Maruyama U.S., Inc., 4770 Mercantile Drive, suite100, Fort Worth, TX 76137 U.S.A.
  • Page 3 Maruyama Mfg. Co., Inc. is liable for damages to other engine components caused by the failure of a warranted part still under warranty.
  • Page 4 This warranty provides you with specific legal rights, which may vary from state to state. It is the Owner's and Dealer's responsibility to make sure the Warranty Registration Card is properly filled out and mailed to Maruyama U.S., Inc. Proof of purchase and registration will be required in order to obtain warranty service.
  • Page 5 This warranty statement outlines the emission warranty coverage provided by Maruyama., U.S. INC. (hereinafter “Maruyama”) for small off-road engines sold in the U.S. and its territories, as well as the 13 provinces and territories of Canada. This warranty statement is divided into two parts. Part I warrants that a new Maruyama small off-road engine complies with U.S.
  • Page 6 You must, at your own expense, take your Maruyama small off-road engine or the product on which it is installed, along with proof of original purchase date, to any Maruyama Dealer who is authorized by Maruyama to sell and service that Maruyama product during the Dealer’s normal business hours. Claims for repair or adjustments found to be caused solely by defects in material or workmanship will not be denied because the engine was not properly maintained and used.
  • Page 7 Air Resources Board may not be used. The use of any non-exempted add-on or modified parts by the ultimate purchaser will be grounds for disallowing a warranty claim made in accordance with this article. Maruyama will not be liable under this article to warrant failures of warranted parts caused by the use of a non-exempted add-on or modified part.
  • Page 8 (1) The repair or replacement of any warranted part otherwise eligible for warranty coverage as stated above may be excluded from such warranty coverage if Maruyama demonstrates that the engine has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.
  • Page 9 MANUFACTURER'S WARRANTY COVERAGE: The 1997 and later model year small off-road engines are warranted for two years. If any emission-related part on your engine is defective, the part will be repaired or replaced by Maruyama Manufacturing Company, Inc. free of charge.
  • Page 10 MAINTENANCE REQUIREMENTS The owner is responsible for the performance of the required maintenance as defined by the Maruyama Manufacturing Company, Inc. in the owner's manual. LIMITATIONS This Emission Control System Warranty shall not cover any of the following: (a) repair or replacement required because of misuse or neglect, lack of required maintenance, repairs improperly performed or replacements not conforming to Maruyama Manufacturing Company, Inc.
  • Page 11 WARNING Read and understand this Owner's/Operator's Manual before using this product. Be thoroughly familiar with the proper use of this product. Do not allow children to operate this product. It is not a toy. Never allow adults to operate the unit without first reading the Owner's / Operator's Manual.
  • Page 12 Sound power level, guaranteed, LWAG dB(A) 109 Safety Inclination Degree is within 10°. SERIAL NIMBER The MARUYAMA MIST BLOWER comes with an Owner's / Operator's Manual and a Warranty Registration Card. Assembly and attachment of the throttle lever bracket and blower pipes are required.
  • Page 13 NAME OF EACH PART CHEMICAL TANK RECOIL STARTER THROTTLE LEVER AIR CLEANER ENGINE BLOWER HOUSING SWIVEL PIPE BAND MIST PIPE STRAIGHT PIPE FLEXIBLE PIPE HOSE BAND FUEL TANK PRIMER BULB HOSE BAND SHOULDER STRAP BACK PAD MIST HOSE SERIAL NUMBER MIST PIPE ASSEMBLE MIST COCK MIST COCK SETTING PROCEDURE...
  • Page 14 Failure to add oil to the gasoline or failure to mix oil with the gasoline at the appropriate ratio will cause major engine damage which will void your warranty. For your fuel premix, only use Maruyama 50:1 2-Stroke Oil or a quality oil designed for 2-stroke air- cooled engine.
  • Page 15 Be sure the mist blower is correctly assembled and all fasteners and fittings are properly secured. THROTTLE LEVER THROTTLE LEVER Before operating the mist blower, release the knob, knob the throttle grip to the position in the illustration, and tighten knob to secure in place. When the mist blower is strapped to the back of the operator, the throttle lever of is located on the tube.
  • Page 16 "CHOKE LEVER" fully upward to the RETURN LINE". open position. Allow the engine to "WARM-UP" at less than 1/2 speed. If a MARUYAMA engine fails to start after following the above procedures, contact an authorized MARUYAMA dealer. English — 15 —...
  • Page 17 OPERATION When the engine has warmed-up, the mist blower can be positioned on the back of the operator. When the mist blower is positioned and ready for operation, adjust the throttle to a speed required to accomplish the task. INTAKE GRILLE OF THE BLOWER HOUSING OPERATING POSITION...
  • Page 18 WARNING • Never operate a mist blower when you are fatigued. • Never operate a mist blower without proper guards or other protective safety devices in place. WARNING To prevent overheating and engine seizure, cooling air comes from the intake grille of the fan housing and is pushed by the blower fan through an opening in the fan housing over the cylinder fin area, taking away combustion heat.
  • Page 19 MUFFLER AND EXHAUST PORTS The muffler should be removed and serviced after each one fifty (50) hours of use. At the same time, the exhaust ports should be cleaned and inspected. An AUTHORIZED MARUYAMA DEALER should be contacted for this service.
  • Page 20 GENERAL CLEANING AND TIGHTENING The MARUYAMA mist blower will provide maximum performance for many hours, if it is maintained properly. Good maintenance includes regular checking of all fasteners for correct tightness, and cleaning the entire machine. Contact an authorized MARUYAMA dealer for additional maintenance suggestions.
  • Page 21 TAMPERING WITH EMISSION CONTROL SYSTEM PROHIBITED Federal law and California State law prohibit the following acts or the causing there of: (1) the removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement, of any device or element of design incorporated into any new engine for the purposes of emission control prior to its sale or delivery to the ultimate purchaser or while it is in use, or (2) the use of the engine after such device or element of design has been removed or rendered inoperative by any person.
  • Page 22 2. Do not tamper with the carburetor setting to increase the maximum engine speed. 3. If adjustment is needed, have it performed by your authorized MARUYAMA service dealer. Carburetor adjustments are made at the factory and are not adjustable without disassembling the carburetor.
  • Page 23 El no observar las instrucciones de este manual, puede producir lesiones graves o incluso la muerte. Para asistencia adicional, póngase en contacto con cualquier distribuidor local autorizado de Maruyama o con Maruyama U.S., Inc. 4770 Mercantile Drive, suite100, Fort Worth, TX 76137 U.S.A. Teléfono: 940-383-7400 Página de Internet: www.maruyama-us.com SIMBOLOS DE SEGURIDAD DEL MANUAL En este manual y en el producto mismo, usted encontrará...
  • Page 24 2 tiempos Premium de Maruyama. Después del período de optimización, el motor siempre debe ser operado con aceite de 2 tiempos Premium de Maruyama o equivalente a aceite de 2 tiempos ISO-L-EGD y JASO FC 2.
  • Page 25 ADVERTENCIA Antes de usar el atomizador, lea cuidadosamente y entienda a cabalidad este Manual del Propietario u Operador. Familiarícese a fondo con el uso adecuado del atomizador. Nunca permita que los niños utilicen este atomizador. No es un juguete. Nunca permita que los adultos utilicen el aparato sin haber leído antes el Manual del Propietario u Operador.
  • Page 26 2,1 galones (2,0 litros) 50:1 Mezcla de combustible Utilizando aceite de motor de 2 ciclos 50:1 de Maruyama o cualquier otro aceite de motor de 2 ciclos diseñado para uso en motores de 2 ciclos de alto rendimiento, enfriados a aire. Accesorios (Estándar)
  • Page 27 NOMBRES DE LAS PARTES ESTANQUE QUÍMICO ARRANCADOR DE REBOBINADO PALANCA DEL ESTRANGULADOR FILTRO DE AIRE MOTOR ALOJAMIENTO DEL SOPLADOR TUBO GIRATORIO BANDA TUBO DE ROCÍO TUBO RECTO TUBO FLEXIBLE BANDA DE MANGUERA ESTANQUE DE COMBUSTIBLE BULBO DE IMPRIMADOR TAPA BANDA CORREA DE HOMBRO COJÍN POSTERIOR MANGUERA DE ROCÍO...
  • Page 28 COMBUSTIBLE: MEZCLA DE GASOLINA Y ACEITE PRECAUCION! Si no usa aceite marca Gasolina Aceite 50:1 para 2 Ciclos Maruyama, nunca use una proporción de 1 galón (3,78 litros) 2.6 onzas (76 ml) mezcla menor de 50:1, sin importar las instrucciones de mezcla del empaque del 2-1/2 galones (9,46 litros) 6.4 onzas (189 ml)
  • Page 29 Asegúrese de que el atomizador esté correctamente armado y de que todos los sujetadores y acoples estén bien asegurados. PALANCA DE PALANCA DE ACELERACIÓN ACELERACIÓN Antes de utilizar el atomizador, suelte la perilla, haga girar el brazo del acelerador hasta la posición que se muestra en la ilustración, y apriete la perilla. PERILLA ¡PRECAUCIÓN! ALTA VELOCIDAD...
  • Page 30 Permita que el motor "SE CALIENTE" a menos que 1/2 velocidad. Si un motor MARUYAMA no arranca después de seguir los procedimientos precedentes, póngase en contacto con un distribuidor MARUYAMA autorizado. Spanish — 29 —...
  • Page 31 OPERACIÓN Una vez que el motor esté calentado, se puede posicionar el atomizador en la espalda del operador. Cuando el atomizador está posicionado y listo para funcionamiento, ajuste el acelerador a la velocidad necesaria para cumplir la tarea deseada. REJA DE ADMISIÓN DEL ALTA VELOCIDAD COMPARTIMIENTO DEL MARCHA LENTA...
  • Page 32 ADVERTENCIA • Nunca opere un atomizador cuando esté fatigado. • Nunca opere un atomizador sin los protectores apropiados u otros dispositivos de seguridad en posición. ADVERTENCIA Para prevenir el sobrecalentamiento y agarrotamiento del motor, el aire de enfriamiento sale de la reja de admisión del compartimiento del ventilador y se impulsa por el ventilador centrífugo a través de una abertura en el compartimiento del ventilador sobre el área de las aletas del cilindro, descargando el calor de combustión.
  • Page 33 Se debe quitar y reparar el silencioso después de cada cincuenta (50) horas de uso. Al mismo tiempo, se debe limpiar e inspeccionar los orificios de escape. Póngase en contacto con un DISTRIBUIDOR MARUYAMA AUTORIZADO para este servicio. — 32 —...
  • Page 34 LIMPIEZA Y APRIETE GENERAL El atomizador MARUYAMA ofrecerá su rendimiento máximo durante muchas horas, si se realiza el mantenimiento adecuado. El buen mantenimiento incluye la verificación regular del apriete correcto de todos los sujetadores y la limpieza de toda la máquina. Póngase en contacto con un distribuidor MARUYAMA autorizado para sugerencias de mantenimiento adicionales.
  • Page 35 Manual del Propietario u Operador. La Garantía Limitada Maruyama del Sistema de Control de Emisiones, exige que usted devuelva su uniddad (Soplador, Recortadora de Césped, Podadora de Seto) a un distribuidor autorizado Maruyama para que se remedie cualquier defecto bajo garantía.
  • Page 36 2. No manipule indebidamente la graduación del carburador para aumentar la velocidad máxima del motor. 3. Si necesita ajustarlo, hágalo a su comerciante autorizado de servicios de MARUYAMA. El carburador es ajustado en la fábrica; por lo tanto, no puede hacerlo sin desarmar.
  • Page 37 Nota: Los intervalos de servicio indicados son para usarse como guía. Se puede dar servicio con más frecuencia según la necesidad indicada por las condiciones de operación. M: El servicio lo debe realizar un distribuidor autorizado de motores Maruyama. ★ : Servicio más frecuente bajo condiciones polvorientas.
  • Page 40 Maruyama U.S., Inc. 4770 Mercantile Drive, suite100, Fort Worth, TX 76137 U.S.A. Phone 940-383-7400 Fax 940-383-7466 ® www.maruyama-us.com P/N 275255-01 15.05 TAP/F...
