Owner's Guide
For Models:
PE1BTWZ
APSRS
RF Upgrade Kit
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
2019 Voxx Electronics Corporation. All rights reserved.
1
Advertisement
Table of Contents
Related Manuals for Prestige PE1BTWZ
Summary of Contents for Prestige PE1BTWZ
- Page 1 Owner’s Guide For Models: PE1BTWZ APSRS RF Upgrade Kit IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR SAFETY PRECAUTIONS may not apply.
-
Page 2: Table Of Contents
Cancelling Remote Start Ready Mode ..........7 Using the “Quick-Stop” Feature ............7 Turbo Timer Mode (optional) ............. 7 Status LED, Light Flashes and Siren/Horn Indications ....... 8 Replacing Remote Control Batteries ............. 9 Warranty Information ................10 APSRS PE1BTWZ Owners revB... -
Page 3: Using Your Remote Control
Using Your Remote Control Door Lock To lock the vehicle doors press and release the button. Arming the Security System (Optional) To arm the system, exit the vehicle, close all doors, then press the button. The parking lights will flash 1 time, indicating the system is armed, has locked the doors (if equipped and connected) and activated the starter disable feature. -
Page 4: User Selectable Led
Turn the ignition key to the ON position. Within 10 seconds, press and release the valet push button switch. The alarm system will stop sounding and enter the (by-passed) mode. You can now start and operate the vehicle normally. APSRS PE1BTWZ Owners revB... -
Page 5: Using Your Remote Vehicle Starter
Using Your Remote Starter Remote Starting Your Vehicle To activate the remote start function, press and hold the button for 3 seconds. The system will sound, the parking lights will flash 1 time and the system will check the vehicle to ensure it is safe to start. If all safety parameters are correct, the vehicle will start. -
Page 6: Remote Start Ready Mode
2 short/1 long tone and light flash pattern indicating Manual Transmission Ready Mode is active. Note: If the 2 short/1 long tone is not heard then Ready Mode has not been set. APSRS PE1BTWZ Owners revB... -
Page 7: Cancelling Remote Start Ready Mode
Cancelling Remote Start Ready Mode - Manual Transmission Vehicles Only The system will exit remote start ready mode if any of the following occur: Open any door Open the hood or trunk (if connected) Press the brake Release the parking brake Turn the ignition ON Using the “Quick-stop”... -
Page 8: Status Led, Light Flashes And Siren/Horn Indications
2 Flashes Remote Shutdown 3 Flashes Brake ON 4 Flashes Manual Transmission Ready Mode 5 Flashes Hood Open 6 Flashes Low Tach Signal 7 Flashes Tach / Crank Average not learned 8 Flashes High Tach Signal APSRS PE1BTWZ Owners revB... -
Page 9: Replacing Remote Control Batteries
2 Way Remote Control Notifications FUNCTION BEEPS / LED FLASHES Lock 1 Beep / Flash Unlock 2 Beeps / Flashes Remote Start Activation RS Activation Melody Confirm Remote Start 4 Beeps / Flashes Remote Start Running 1 Flash per 5 seconds for duration run time Remote Start Shutdown RS Shutdown Melody Alarm Trigger Event... -
Page 10: Warranty Information
NOTE: This system has 1 button programming which programs all channels of the system. NOTE: The system will hold up to 4 transmitters in memory, programming a 5th transmitter will erase the oldest transmitter in memory. APSRS PE1BTWZ Owners revB... - Page 11 LIMITED LIFETIME WARRANTY Applies to Prestige Series Control Modules, Sirens, Sensors, and Relays. Voxx Electronics Corporation (the Company) warrants to the original purchaser of this product that should this product or any part thereof, (other than transmitters) under nor- mal use and conditions, be proven defective in material or workmanship during the life-...
- Page 12 2. This device must accept any interference received, including any interference that may cause undesired operation. Warning! Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. PATENTED: www.voxxintl.com/company/patents APSRS PE1BTWZ Owners revB...
