Page 1
128-8115
1 of 19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prestige 128-8115 and is the answer not in the manual?

Questions and answers

Summary of Contents for Prestige Prestige 128-8115

  • Page 1 Page 1 128-8115 1 of 19...
  • Page 2 To program these selectable features; Action Turn ignition on Press and release the valet switch 3 times Within 3 seconds, turn ignition Off Then On This Action Accesses Feature Bank 2 Alarm Selectable Features First Press and release the valet switch 1 time Press transmitter Lock button to change Press transmitter Lock button to change Press transmitter Lock button to change...
  • Page 3 Page 3 128-8115 3 of 19...
  • Page 4 Action Turn ignition on Press and release the valet switch 3 times Within 3 seconds, turn ignition Off, On, Off, On This Action Accesses Feature Bank 3 Remote Start Selectable Features First Press the valet switch one time Press transmitter Lock button to change Second Press and release the valet switch Press transmitter Lock button to change...
  • Page 5: Installation Of The Major Components

    This Remote Start System is designed for use with Automatic Transmission Vehicles Only! The unit provides wait to start input for glow plug pre-heat which will be used for all diesel applications. If this wire is not connected, then the unit will remain in the Gasoline mode setting, which will crank the car when the RF signal is received with no delay.
  • Page 6: Wiring The 6 Pin Main Power Harness

    DO NOT PLUG THE SIX PIN MAIN POWER HARNESS OR THE MULTI PIN INPUT / OUTPUT HARNESS INTO THE CONTROL MODULE UNTIL ALL CONNECTIONS TO THE VEHICLE HAVE BEEN MADE. AFTER SELECTING YOUR TARGET WIRES AS DEFINED BELOW, DISCONNECT THE NEGATIVE BATTERY CABLE FROM THE VE- HICLE BATTERY PRIOR TO MAKING ANY CONNECTIONS.
  • Page 7 SEE NEUTRAL START SAFETY TEST FOR FURTHER DETAILS. BLUE WIRE: Ignition 1 Output Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 volts when the ignition key is turned to the to the "ON" or "RUN" and the "START" or CRANK" positions and will have 0 volts when the key is turned to the "OFF"...
  • Page 8 Black wire; see Brown w/ Black tracer wire. BROWN WIRE: Positive Inhibit Input 1 Any time + 12 Volts is applied to the Brown wire, the Remote Starter will stop operating, even if the signal is received from the transmitter.
  • Page 9 This wire provides a + 12 Volt output when the ignition key is turned to the “ON” position, and 0 Volts when the ignition key is “OFF” and when the vehicle is running under the control of the remote starter.
  • Page 10 5. Connect the previously selected resistor from terminal #87 to the second (#2) wire (as shown). NOTE: The above information and following diagram is for the GM VATS system only. For GM PASS LOCK System you will require the Audiovox AS-PASS II Module. General Motors VATS By-Pass Diagram GREEN/ORANGE Wire: Tach Sensor Input This wire will continually monitor the engine tach rate while the unit is under power of the Remote Start module.
  • Page 11: Wiring The 4 Pin Auxiliary Output Harness

    cases will operate properly from one multi coil pack regardless of the number of cylinders. If the vehicle has a single coil unit for each cylinder, it may be necessary to connect this wire to more than one cylinder for proper tach reference.
  • Page 12 2 Pin Transponder Control Output: (Yellow Connector) This output is intended to allow the control of a transponder bypass interface module or transponder bypass relay. The system also allows software selections to control the way in which this output oper- ates, see remote start feature # 10 for setting this output.
  • Page 13: Hood Pin Safety Shut Down

    3. Raise the hood and confirm that the remote start unit shuts down. If the unit fails this test, recheck your pin switch connection to the Gray/Black wire of the Audiovox Remote Start Unit. DO NOT RELEASE THIS VEHICLE TO THE CONSUMER UNTIL YOU CONFIRM THE OPERATION OF THE HOOD PIN SAFETY SHUT DOWN FEATURE.
  • Page 14: Mechanical Neutral Safety Switch Considerations

    The installation required for this application (shown below), indicates the slight reconfiguration of the control switch wiring and the addition of a 4000 series diode. Shown is a typical GM Park/Neutral ECM input circuit. To connect the Audiovox remote start unit to the GM Park / Neutral ECM input: 1.
  • Page 15 E. Connect the cathode (striped) side of a 4002 series diode to this same wire, and connect the (non striped) side to the negative shut down safety wire (Gray / Black) of the Audiovox Remote Start Unit. F. Connect terminal #86 of the relay to a fused +12 volt constant battery source.
  • Page 16 4 Pin Upgrade Data Bus/Flash Logic Module: If you are using an Audiovox Flash Logic module, it can be connected directly to the Alarm/Remote Start's control module. Using the Blue 4 pin blue, red, black, & white harness and connect to the mating connector on the Alarm/Remote Start control module.
  • Page 17: Completing The Installation

    COMPLETING THE INSTALLATION: After you have confirmed the operation of the Audiovox Remote Start unit and tested all the safety features of the system: 1. If you have not done so already, place the red rubber handle cover over the handle of the control switch for ease of identification.
  • Page 18 THIS PAGE LEFT BLANK INTENTIONALLY Page 18 128-8115 18 of 19...
  • Page 19 Page 19 128-8115 19 of 19...
  • Page 20 © 2007 Audiovox Electronics Corp., Hauppauge, NY 11788 128-8115 Page 20 128-8115 20 of 19...
