DREAMS Calvert Bed Double Assembly Instructions

011-00136(solid slats), 011-00066 (sprung slats)

Assembly Instructions

Before you

Start, here

are some

helpful

advices.

Revision number 1/1

Calvert Bed Double

1. We suggest you spend a short time reading through this leaflet and then follow

the simple step by step instructions.

2. If you follow the instructions carefully the end result should be worth the effort.

3. Do not discard any of the packaging until you have checked that you

have all the parts and the pack of fittings.

4. Assemble this product on a carpet.

5. To ensure an easier assembly, we strongly advise that all fittings are only

finger tightened during initial assembly. Only upon completion of the assembly

should all fixing points be fully tightened.

6. We recommend a periodic check on all fixing points to make sure they remain

fully tightened.

7. Keep glue and fittings out of children's reach.

In the unlikely event that this product has missing or damaged parts, please call

0344 292 0000 to obtain spares

spare

011-00136(Solid slats)

011-00066 (Sprung slats)

Table of Contents

Need help?

Do you have a question about the Calvert Bed Double and is the answer not in the manual?

Page 1 011-00136(Solid slats) Calvert Bed Double 011-00066 (Sprung slats) Assembly Instructions Before you 1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. Start, here 2. If you follow the instructions carefully the end result should be worth the effort.
