IntesisBox
ASCII Server - KNX
Dimensions
External dimensions.
58 mm
107 mm
Free space recommended to install the device, with spacing enough for external connections.
100 mm
This information is subject to change without notice.
ASCII EIA232
port
Console
port
115 mm
URL
http://www.intesis.com
email
info@intesis.com
tel
+34 938047134
Installation Manual
Power
KNX
port
105 mm
130 mm
Doc. Rev. 2
5 / 5
