Bin Master C-100MB Operator's Manual page 26

Smartbob console with modbus interface
Table of Contents

Advertisement

Register
Access
4x0011
RO
Measurement Status – One hundred twenty registers, each one containing the
to
measurement status for a SmartBob. Any value other than 0 (idle) indicates a
4x0130
measurement is in progress.
Use the following to determine the register address corresponding to a known
SmartBob address:
Measurement Status values are as follows:
4x0131
RO
Results/SmartBob Status – One hundred twenty registers, each one representing a
to
SmartBob. The high byte provides the status of the results from the last
4x0250
measurement and the low byte defines whether the SmartBob is enabled.
Use the following to determine the register address corresponding to a known
SmartBob address:
Results Status (high byte):
SmartBob Status (low byte):
4x0251
RO
Drop Measurement – One hundred twenty registers, each containing the drop
to
distance from its last successful measurement. This should only be considered
4x0370
valid when the Results Status for the corresponding SmartBob reads 101 (65h).
This is the raw measurement value taken from the SmartBob with a resolution of
0.0125 foot (0.15 inch) per count. Divide this value by 80 for a distance in feet.
Use the following to determine the register address corresponding to a known
SmartBob address:
925-0301 Rev C
Name and Description
register_addr = 4x0010 + smartbob_addr
0 = Idle (ready for measurement)
1 = Pending (waiting for SB-485 traffic to clear)
2 = Pending (initiating or waiting to initiate a measurement)
3 = Pending (waiting for status)
4 = Dropping (measuring)
5 = Retracting (measuring)
6 = Retrieving Results
7 = Pending (setting SmartBob maximum drop)
register_addr = 4x0130 + smartbob_addr
100 (64h) = No Data or Invalid
101 (65h) = Valid Data
102 (66h) = Override
103 (67h) = Comm Error
104 (68h) = Bob Stuck
105 (69h) = Did Not Drop
106 (6Ah) = Measurement Error
Any other value should be considered an unknown error.
0 = Disabled (will NOT respond to measurement requests)
1 = Enabled
register_addr = 4x0250 + smartbob_addr
