Bin Master C-100MB Operator's Manual page 21

Smartbob console with modbus interface
Table of Contents

Advertisement

Circular
Body Height
Body Radius
No
Hopper Present
Hopper Height
Outlet Radius
I/O Assignment
This is a menu for assigning SmartBob sensors to the onboard I/O port. The operator must use
Add/Remove or Auto Add/Remove prior to making this selection. With this menu, the operator
simply selects the address of any single SmartBob to assign to the onboard I/O (external start
input and 4-20mA output). It will default to the first address available in the list.
4-20mA Output
This is a menu for setting what the 4-20mA Output will represent; the operator can choose
between Product and Headroom. The default setting is Product.
925-0301 Rev C
Select Vessel(s)
to Edit
Vessel Shape
Rectangular
Hopper Present
Yes
Hopper Height
Outlet Width 1
Outlet Width 2
Sensor
Offset
Product
Density
Body Height
Body Width 1
Body Width 2
No
Yes
21
