When weight calculations are disabled, this output is a percentage of the headroom height or
product height.
headroom weight or product weight.
4-20mA Error
This is a menu for setting what the 4-20mA output error level will be, the operator can choose
between 2mA and 22mA. This error level will be programmed to the output whenever the last
measurement produced an error condition such as a communications error or Bob is stuck. The
default setting is 22mA.
Interval Timer
The interval timer allows the operator to enable and configure the console to take multiple
automatic timed measurements. The selections are On/Set and Off. The default setting is Off.
After selection of On/Set, a setup screen appears for entering the
timer value in hours and minutes. Enter any amount of time from
0 minutes (continuous) to 49 hours and 59 minutes in the format:
HH:MM. One minute would be 00:01 and 24 hours would be
24:00. The timer is adjusted one digit at a time. Use the
keys to select a digit by repositioning the cursor and the
to adjust the selected digit. Once all four digits have been entered, press the
After the interval time has been set, a menu appears for assigning SmartBobs to the automatic
measurement process.
configured may be assigned. Use the
SmartBob address' from the list to the interval timer. After all desired SmartBob sensors are
assigned, press the
CAUTION: Setting the interval timer value to 00:00 (continuous) may decrease the life cycle of
the SmartBob sensors assigned to the interval timer.
Measurement Format
This is a menu for selecting the measurement format displayed under the Measure/View menu.
When weight calculations are disabled, only Percent and Height are available. When weight
calculations are enabled, the operator can select between the following:
Percent
Height
Cubic Units
U.S. Gallons
U.S. Bushel
Liters
Pounds
Tons
Kilograms
Metric Tons
Height and Cubic Units will be dependent on the setting in Units of Measure, with units in either
feet (ft) or meters (m).
Note that this setting effects what is displayed in Measure/View and Measure/View Details.
925-0301 Rev C
When weight calculations are enabled, this output is a percentage of the
At least one must be assigned and up to all SmartBob sensors
key to exit.
22
/
/
keys
,
and
keys to select and accept one or more
key.
