Configuring VPN
4

PPTP Configuration

To complete the PPTP configuration, follow these steps:
1) Configure the VPN IP pool.
2) Configure PPTP globally.
3) Configure the PPTP server/client.
4) (Optional) Configure the PPTP users.
5) Verify the connectivity of the PPTP VPN tunnel.
Configuration Guidelines
 When the network mode is configured as Client-to-LAN and the router acts as the PPTP
server, you don't need to configure a PPTP client on the router.
 When the network mode is configured as LAN-to-LAN and the router acts as the PPTP
client gateway, you don't need to configure PPTP users on the router.

4.1 Configuring the VPN IP Pool

Choose the menu Preferences> VPN IP Pool > VPN IP Pool and click Add to load the
following page.
Figure 4-1 Configuring the VPN IP Pool
Follow these steps to configure the VPN IP Pool:
1) Specify the name of the IP Pool.
2) Specify the starting IP address and ending IP address for the IP Pool.
