7-DISMANTLING
SIDE PANEL C
Proceed as follows to remove the side panels "C":
•
Lift the tank cover "A"
•
remove the front cover "B" (as instructed on previous page)
•
open the firebox door "C"
•
Remove the two upper screws ''x'' and the three side screws ''y''
x
a
Technical Dept. - All rights reserved - Reproduction is prohibited
C
x
C
y
A
27
