The
Legacy 1000
is an easy to
use detector. The most difficult aspects of
metal detecting have been automated.
However if you are new to the hobby, we
strongly recommend that you:
1) Adjust the Sensitivity to a low setting in the
event of false signals. The detector powers on a
3/4 sensitivity; increase to full sensitivity after you
have become familiar with the detector.
2) Do not use indoors. This detector is for outdoor use only. Many
household appliances emit electromagnetic energy, which can
interfere with the detector. If conducting an indoor demonstration,
turn the sensitivity down and keep the search coil away from
appliances such as computers, televisions and microwave ovens.
If your detector beeps erratically, turn off appliances and lights.
Also keep the search coil away from objects containing metal, such as
floors and walls.
3) Read this manual. Most importantly, review the Quick-Start Demo
(p.6) and Basic Operation (p. 8-12).
4) Use 9-volt ALKALINE batteries only.
Do not use Heavy Duty or ordinary Zinc-carbon Batteries.
OWNER'S M NU L

Advertisement

Table of Contents
loading

Related Manuals for Bounty Hunter Legacy 1000

Summary of Contents for Bounty Hunter Legacy 1000

  • Page 1 OWNER’S M NU L Legacy 1000 is an easy to use detector. The most difficult aspects of metal detecting have been automated. However if you are new to the hobby, we strongly recommend that you: 1) Adjust the Sensitivity to a low setting in the event of false signals.

  • Page 2: Table Of Contents

    Warranty ..... . .Back Cover The BOUNTY HUNTER LEGACY 1000 series of metal detectors is not associated or connected in any way with Pilot Corporation or its...

  • Page 3: Terminology

    TERMINOLOGY The following terms are used throughout the manual, and are standard terminology among detectorists. ELIMIN TION Reference to a metal being "eliminated" means that the detector will not emit a tone, nor light up an indicator, when a specified object passes through the coil’s detection field.

  • Page 4: Assembly

    SSEMBLY Assembly is easy and requires no tools. Position the lower stem with the silver button toward the back. Using the bolt and knurled knob, attach the search coil to the plastic extension protruding from the lower stem. If your model is equipped with a 3-piece stem, open the plastic locking nut on the upper tube by...

  • Page 5: Batteries

    You may notice erratic beeping if using with LOW BATTERY illuminated. IMPORT NT: Your Legacy 1000 metal detector requires two 9-Volt ALKALINE batteries. Follow these steps to install the batteries. Carefully remove the battery compartment door by pressing the release clip on the right side of the door.

  • Page 6: Quick-Start Demo

    Q UICK-ST RT DEMONSTR TION I. Supplies Needed • A Medium-Size Nail • A Quarter • A Nickel • A Zinc Penny (dated after 1982) II. Position the Detector a. Place the detector on a table, with the search coil hanging over the edge.
  • Page 7 Q UICK-ST RT DEMONSTR TION (continued) V. Press the TARGET REJECT touchpad a. An “X” will appear under the IRON segment. b. The “X” tell us that Iron has been eliminated from detection. VI. Wave the Nail over the Search Coil a.

  • Page 8: Powering Up

    B SIC OPER TION POWERING UP Press the ON touch pad. All display indicators will illuminate momentarily The inverted-pyramid depth-selection indicator on the right of the display will stay illuminated. UNDERST NDING THE DISPL Y DEPTH SELECT The detector default to 3/4 sensitivity, indicated by two illuminated segments.
  • Page 9 B SIC OPER TION continued will begin to beep erratically and operate unreliably if continuing use with discharged batteries. To save on batteries, check each battery individually, as the two batteries can discharge at different rates. When LOW BATTERY illuminates, it is possible that only one of the batteries requires replacement.
  • Page 10 B SIC OPER TION continued Commonly-found object are classified into the four categories as follows: IRON ------------------------------------------------ Ferrous objects Metals composed mostly or entirely of iron Most very small metals objects Small foil pieces; small gold pieces. AL ZN ------------------------------------------------ Post-1982 pennies (are made of zinc, some zinc pennies will register as coins within 1”...

  • Page 11: Operating Controls

    B SIC OPER TION continued OPER TING CONTROLS The Legacy 1000 is the most automated, easy-to-operate, professional metal detector ever designed. It is designed for those who are new to the hobby providing maximum basic target discrimination, while requiring minimal operator adjustment.

  • Page 12: Environmental Conditions

    If you receive constant false signals, reduce the sensitivity or move to another area. SAND: Dry beach sands are no problem for the Legacy 1000. if the sand is damp with saltwater, however, follow the precautions outlined under saltwater above.

  • Page 13: Audio Target Identification

    UDIO T RGET IDENTIFIC TION While the LCD (Liquid Crystal Display) is very accurate in identifying buried objects, the user in the field does not always maintain the display screen in his field of vision. Therefore, we have incorporated an audio feedback mechanism to alert the user to the nature of buried objects.

  • Page 14: Depth Select (Sensitivity Adjustment)

    SEVERE GROUND CONDITIONS A secondary use for the Sensitivity Control is to reduce false detection signals caused by severe ground conditions. While your Legacy 1000 contains circuitry to eliminate the signals caused by most naturally occurring ground minerals, 100% of all ground conditions cannot be anticipated.

  • Page 15: In The Field Techniques

    IN THE FIELD TECHNIQUES PINPOINTING COIL MOVEMENT When swinging the coil, be Accurate pinpointing takes practice careful to keep it level with the and is best accomplished by ground about 1/2 inch from the “X-ing” the target area. surface. Never swing the coil like a pendulum.
  • Page 16 IN THE FIELD TECHNIQUES (continued) Swing the search coil slowly, sweeping the coil directly over the overlapping each sweep as you suspected target a few times, it is move forward. It is important to more than likely trash metal. sweep the coil at a consistent speed over the ground as you Crossing the target zone with search.
  • Page 17 IN THE FIELD TECHNIQUES (continued) You may encounter some false lost valuables. To make searching signals as you proceed. False easier in very trashy areas, signals occur when the detector consider purchasing the Bounty beeps, but no metal target is Hunter 4-inch Search Coil.

  • Page 18: Trouble Shooting

    TROUBLE SHOOTING TROUBLE SHOOTING GUIDE SYMPTOM CAUSE SOLUTION Detector chatters • Using detector • Use detector or beeps erratically indoors outdoors only • Using detector near • Move away power lines from power lines • Using 2 detectors in • Keep 2 detectors close proximity at least 20’...

  • Page 19: Metal Detecting Applications

    MET L DETECTING PPLIC TIONS COIN SHOOTING: The most popular metal detecting activity. Find coins where people congregate frequently. Many detectorists revisit the same areas again and again to find a never-ending treasure trove as people continue to lose valuables every day. Parks, fairgrounds, and play ares are good choices.

  • Page 20: Warranty

    FIRST TEXAS PRODUCTS, LLC 5-YEAR LIMITED WARRANTY The Bounty Hunter Legacy 1000 is warranted against defects in workmanship or materials under normal use for five years from date of purchase to the original user. Liability in all events is limited to the purchase price paid.
