Chapter 1: Product Introduction
Hardware Installation
1. Remove the lens cover.
2. Attach the camera lens (purchased separately) onto the focus ring and
connect it to the iris connector.
3. After adjusting the lens focus, use the supplied hex wrench to tighten the
two set screws into the set screw holes on the focus ring to secure the
lens. (Please refer to the figure below)
Lens (purchased separately)
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
4
NCb-211 User Manual
