Page 1: Ceiling Fan
The Celano ™ Ceiling Fan Net Weight 9.07 kg (20.0 lbs) Model No. FP5420PW OWNER’S MANUAL READ AND SAVE THESE INSTRUCTIONS... -
Page 2: Table Of Contents
Fanimation. 7. Fanimation reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty. 8. Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must ac- company authorized returns and must be sent freight prepaid to Fanimation. -
Page 3: Tools Needed For Assembly
Fanimation. Substitution of parts or accessories not designated for use with this product by Fanimation could result in personal injury or property damage. Contact your retail store for missing or damaged parts. -
Page 4: Energy Effi Cient Use Of Ceiling Fans
If ceiling height allows, install the fan 8 - 9 feet above the floor for optimal airflow. Consult your Fanimation Retailer for optional mounting accessories. Turn Off When Not in the Room Ceiling fans cool people, not rooms. If the room is unoccupied, turn off the ceiling fan to save energy. -
Page 5: How To Assemble Your Ceiling Fan
How to Assemble Your Ceiling Fan 1. Dis-assemble the Upper Housing Cover by loosening three screws (Fig 1a) and carefully twist-n-lift off the Cover (Fig 1b). 2. Attach blades to the motor hub using the provided washer head screws and fiber washers. Make sure the screws securing the blades to the motor hub are tight and are properly seated. - Page 6 How to Assemble Your Ceiling Fan (cont’d) 6. Loosen the two setscrews in the Downrod Support. Align the Clevis Pin holes in the Downrod with the holes in the Downrod Support. Install the Clevis Pin and secure with the Hairpin Clip. (Figure 5) Be sure to push the straight leg of the hairpin clip through the hole near the end of the clevis pin until the curved portion of the hairpin clip snaps around the clevis pin.
-
Page 7: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan ▲WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before hanging. NOTE: If you are not sure if the outlet box is grounded, contact a licensed electrician for advice, as it must be grounded for safe operation. -
Page 8: How To Wire Your Ceiling Fan - C24 Remote Control
How to Wire Your Ceiling Fan - C24 Remote Control If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician. ▲WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. -
Page 9: Installing The Canopy Housing
Installing the Canopy Housing NOTE: This step is applicable after the necessary wiring is completed. ▲WARNING To avoid possible fire or shock, make sure that the electrical wires are completely inside the canopy housing and not pinched between the housing and the ceiling. 1. - Page 10 Installing the Light Kit Assembly (cont’d) 4. Securely attach Downlight Socket Plate Assembly to the Adapter Plate by tightening three screws provided with the fan. (Figure 4) INSTALLATION NOTE If You Are NOT Installing The Light Kit, Go To Next Page Under “Installing The Lower Housing Assembly”...
-
Page 11: Installing The Lower Housing Cover
Installing the Lower Housing Cover CAUTION To avoid possible electrical shock, be sure electricity is turned off before installing Lower Housing assembly. 1. Do not install light bulbs. (Figure 1) 2. Carefully dis-assemble the glass from Support Frame and Indexing Plate by removing three screws. (Figure 2a) 3. -
Page 12: Maintenance
Periodic cleaning of your new ceiling fan is the only maintenance that is needed. When cleaning, use only a soft brush or lint free cloth to avoid scratching the fi nish. Abrasive cleaning agents are not required and should be avoided to prevent damage to fi... -
Page 13: Trouble Shooting
For your own safety turn off power at fuse box or circuit breaker before trouble shooting your fan. Trouble 1. Fuse or circuit breaker blown. 2. Loose power line connections to the fan, or loose switch wire connections in the switch housing. 1. -
Page 14: Parts List
Before discarding packaging materials, be certain all parts have been removed Contact your retail store for repair parts. When ordering repair parts, always give the following information. Parts List Model #FP5420PW Description How To Order Parts • Part Number • Part Description •... -
Page 15: Exploded-View Illustration
The Celano NOTE: The illustration shown is not to scale or its actual confi guration may vary ™ FP5420PW Exploded-View Figure 1 Reversing Switch... - Page 16 10983 Bennett Parkway Zionsville, IN 46077 (888) 567-2055 FAX (866) 482-5215 Outside U.S. call (317) 733-4113 Visit Our Website www.fanimation.com Copyright 2007 Fanimation 2007/11...
