Submersible effluent & sewage pumps

Advertisement

SAFETY WARNINGS
BEFORE OPERATING OR
INSTALLING THIS PUMP,
READ THIS MANUAL AND
FOLLOW ALL SAFETY
RULES AND OPERATING
INSTRUCTIONS.
SAFETY
CAREFULLY READ THESE
SAFETY MESSAGES
MANUAL AND ON PUMP.
CAUTION
Review instructions before operating.
WARNING - ELECTRICAL PRECAU-
TIONS
All wiring, electrical connections, and system
grounding must comply with the National Electri-
cal Code (NEC) and with any local codes and
ordinances. Employ a licensed electrician.
WARNING -
RISK OF ELECTRICAL
SHOCK
Have an electrician provide electrical power to
motor.
A ground fault interrupter (GFI) protected circuit is
recommended for use with any electrical device
operating near water.
A ground fault interrupter (GFI) protected circuit is rec-
ommended for use with any electrical device operating
in or near water.
Have a licensed and qualifi ed electrician provide
electrical power to the pump.
Make sure the line voltage and frequency of the
electrical current supply matches the specifi cations
printed on the pump nameplate.
Ensure the pump and electrical supply system
are properly grounded. Never install or test a
pump without proper electrical grounding of the
system.
200560triR03
0608
SUBMERSIBLE
EFFLUENT & SEWAGE PUMPS
RL SERIES
Power cord with grounded
plug,
IN
THIS
Float switch for single
phase automatic
models only! Switch
cord with piggyback
grounded plug.
Always disconnect pump from power source before handling
or servicing.
This product is furnished with a 3-prong plug for grounding;
connect only to properly grounded receptacle.
NEVER UNDER ANY CIRCUMSTANCES REMOVE OR
DISABLE THE GROUND PLUG.
Keep electrical plug dry - do not lift pump using cord.
Not investigated for use in swimming pools.
Grounded plug
115 volt confi gu-
ration.
Pump and motor
assembly.
NOTE:
For automatic built-in fl oat
switch models, both the
power and switch cords use
the same grounded plug.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Franklin Electric RL Series

  • Page 1 SUBMERSIBLE EFFLUENT & SEWAGE PUMPS RL SERIES SAFETY WARNINGS Grounded plug BEFORE OPERATING OR 115 volt confi gu- Power cord with grounded INSTALLING THIS PUMP, plug, ration. READ THIS MANUAL AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. SAFETY CAREFULLY READ THESE...
  • Page 2: Table Of Contents

    EFFLUENT & SEWAGE APPLICATIONS - UP TO 3/4" & 2" SOLIDS HANDLING CAPABILITY These pumps are for use in effl uent or raw sewage ap- Additionally, the maximum solids size, as shown in plications where the total head required (including pipe Fig.1, must not be exceeded.
  • Page 3 INSTALLATION WARNING - 2. LOCATION: ELECTRICAL PRECAUTIONS Installation of the pump must be made in a location that: Before installation, check the national and local electrical and plumbing codes/ordinances..A pump a) Has adequate room for servicing and is of adequate intended for use in a septic tank/sump or sewage size (see page 5).
  • Page 4: Installation Information And Typical Installation Drawings

    INSTALLATION a) Gas tight and properly vented with national & local 3. SEPTIC TANK/SUMP PREPARATION AND electrical and plumbing codes. REQUIREMENTS: WARNING - ELECTRICAL PRECAUTIONS b) Level bottom of sump. DO NOT SET PUMP DI- A SEPTIC SUMP CONDITION MAY EXIST. IF RECTLY ON BOTTOM OF SUMP IF IT IS NOT ENTRY INTO SUMP IS NECESSARY, then fi...
  • Page 5 INSTALLATION TABLE 1 5. MOUNTING THE FLOAT SWITCH: AUTOMATIC OPERATION MODELS ONLY Approximate 'pumpable volume' (gallons) for various combinations of basin diameters and fl oat switch tether All automatic models; Single Phase 115 volt lengths..models come supplied with a fl oat switch for mount- ing to the pump's discharge pipe and requires fi...
  • Page 6: Start Up And Operational Check

    START UP AND OPERATIONAL CHECK 7. AUTOMATIC MODELS (WITH FLOAT SWITCH) 8. MANUAL MODELS: SINGLE PHASE 115 VAC MODELS: SINGLE PHASE 115 VAC MODELS a) Connect the 3-prong grounded piggyback plug on a) Manually fi ll the tank/basin with water to check the the fl...
  • Page 7: Troubleshooting

    11. TROUBLESHOOTING: FOLLOW ALL SAFETY TIPS, PROCEDURES AND WARNINGS PREVI- OUSLY IDENTIFIED IN THIS MANUAL BEFORE TROUBLESHOOTING THE SYSTEM. TROUBLESHOOTING TROUBLE PROBABLE CAUSE CORRECTIVE ACTION Blown fuse Replace Motor does not run Tripped circuit Reset Disconnected plug Reinstall Corroded plug Clean prongs Tripped overload Allow pump to cool, investigate cause (jammed impeller)
  • Page 8: Warranty

    LIMITED WARRANTY For warranty consideration, Franklin Electric Company, Inc. and its subsidiaries (hereafter “the Company”) warrants that the products specified in this war- ranty are free from defects in material or workmanship of the Company. During the time periods and subject to the terms and conditions hereinafter set forth, the Company will repair or replace to the original user or consumer any portion of this product which proves defective due to materials or workmanship of the Company.
