INSTALLATION INSTRUCTIONS*
Template Sheet
1. Detach the camera's cover dome from the
camera's module by unscrewing the three cover
dome screws using the L-Wrench.
2. Use the camera or mounting template to mark
and drill the necessary holes in the wall or
ceiling.
3. Pull wires through and make connections.
4. Using three (3) included screws, mount and
secure the camera to the wall or ceiling.
5. Secure the camera's cover dome onto the
camera base and remove the protecting film to
complete the installation.
8
