Summit24e3 Switch Overview
Table 3: Summit24e3 Switch LED Behavior (continued)
10/100 Mbps Port Status LEDs
Color
Green
Green blinking
Off
Mini-GBIC Port Status LEDs
Color
Amber
Amber blinking
Green
Green blinking
Off

Port Connections

The Summit24e3 switch uses a combination of 10BASE-T/100BASE-TX ports using RJ-45 connectors and
Small Form Factor Plugable (SFP) Gigabit Interface Connectors (GBICs), also known as mini-GBICs,
using LC connectors and supports 1000BASE-SX.

Full-Duplex

The Summit24e3 switch provides full-duplex support for all ports. Full-duplex allows frames to be
transmitted and received simultaneously and, in effect, doubles the bandwidth available on a link. All
10/100 Mbps ports on the Summit24e3 switch autonegotiates for half- or full-duplex operation.

Mini-GBIC Type and Hardware/Software Support

The Summit24e3 switch supports the SFP GBIC, also known as the mini-GBIC. The system uses
identifier bits to determine the media type of the mini-GBIC that is installed. The Summit24e3 supports
only the mini-GBIC.
This section describes the mini-GBIC type and specifications.

Mini-GBIC Type and Specifications

Table 4 describes the mini-GBIC type and distances for the Summit24e3 switch.
22
Indicates
Link is present; port is enabled.
Link is present; there is activity.
Link is not present or the port is disabled.
Indicates
Frames are being transmitted/received on this port.
A non-supported GBIC is installed on this port.
Link is present; port is enabled; full-duplex operation.
Link is present; port is disabled.
Link is not present.
