Hitless Failover and
Hitless Upgrade User Guide
This guide describes hitless failover and hitless upgrade, including:
T-sync is a term used to describe the hitless failover and hitless upgrade features available on the
BlackDiamond
®
Management Switch Module 3 (MSM-3). In simple terms, hitless failover transfers switch
management control from the master MSM-3 to the slave MSM-3 without causing traffic to be dropped.
Hitless upgrade allows an ExtremeWare
®
software upgrade on a BlackDiamond 6800 series chassis
without taking it out of service or losing traffic.
To configure hitless failover or hitless upgrade, you must install MSM-3 modules in your BlackDiamond
chassis; MSM64i modules do not support hitless failover or hitless upgrade.
If you enable T-sync and normally use scripts to configure your switch, Extreme Networks recommends
using the
command instead.
download configuration incremental
NOTE
To use the T-sync features available on the MSM-3 modules, you must install and run ExtremeWare
7.1.1 or later and BootROM 8.1 or later.

Causes and Behaviors of MSM Failover

This section describes the events that cause an MSM failover and the behavior of the system after
failover occurs.
The following events cause an MSM failover:
• Operator command
Part Number: 121071-00 Rev 01
1
